62
STR-DB900
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< JACK >
J701 1-766-400-11 JACK, PIN 2P (VIDEO IN DVD/VIDEO)
J702 1-766-400-11 JACK, PIN 2P
(VIDEO TV/SAT IN/MONITOR OUT)
< SHORT >
JR703 1-216-864-11 SHORT CHIP 0
JR704 1-216-864-11 SHORT CHIP 0
< JUMPER RESISTOR >
JW705 1-216-864-11 SHORT CHIP 0
< RESISTOR >
R701 1-218-285-11 METAL CHIP 75 5% 1/10W
R702 1-218-285-11 METAL CHIP 75 5% 1/10W
R703 1-218-285-11 METAL CHIP 75 5% 1/10W
R704 1-218-285-11 METAL CHIP 75 5% 1/10W
R705 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R706 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R708 1-216-845-11 METAL CHIP 100K 5% 1/10W
R781 1-216-864-11 SHORT CHIP 0
************************************************************
1-862-303-11 VOL BOARD
*********
< VARIABLE RESISTOR >
RV801 1-418-725-51 ENCODER, ROTARY (12 TYPE) (VOLUME)
************************************************************
MISCELLANEOUS
**************
59 1-773-060-11 WIRE (FLAT TYPE) (17 CORE)
102 1-469-969-11 CLAMP, FERRITE (AEP, UK)
0 106 1-829-626-11 CORD, POWER
110 1-769-939-11 WIRE (FLAT TYPE) (11 CORE) (SP, MY)
110 1-773-003-11 WIRE (FLAT TYPE) (15 CORE) (AEP, UK)
111 1-769-857-11 WIRE (FLAT TYPE) (5 CORE)
112 1-773-182-11 WIRE (FLAT TYPE) (23 CORE)
114 1-828-386-11 WIRE (FLAT TYPE) (25 CORE)
0 F901 1-576-230-12 FUSE (H.B.C.) (T3.15AL/250V)
FL801 1-518-993-11 INDICATOR TUBE, FLUORESCENT
TM101 1-693-578-41 TUNER (AEP, UK)
TM101 1-693-641-11 TUNER (SP, MY)
0 1-770-019-51 ADAPTOR, CONVERSION PLUG (UK)
************************************************************
ACCESSORIES
***********
1-478-656-11 COMMANDER, STANDARD (RM-PP450)
1-501-374-12 LOOP ANT (AM) (UK, SP, MY)
1-501-807-12 ANTENNA (FM)
1-754-149-11 LOOP ANT (AM) (AEP)
4-251-318-11 COVER, PROTECTION
4-255-065-11 MANUAL, INSTRUCTION (ENGLISH)
4-255-065-21 MANUAL, INSTRUCTION (FRENCH, SPANISH)
(AEP, SP, MY)
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
VOLVIDEO
4-255-065-31 MANUAL, INSTRUCTION
(GERMAN, ITALIAN, DUTCH) (AEP)
4-255-065-41 MANUAL, INSTRUCTION (SWEDISH, POLISH)
(AEP)
4-255-065-51 MANUAL, INSTRUCTION
(TRADITIONAL CHINESE) (SP, MY)
