24
STR-DE185
SECTION 6
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified by
mark 0 or dotted line with mark.
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
A-4727-878-A DISPLAY BOARD, COMPLETE (US)
A-4727-882-A DISPLAY BOARD, COMPLETE (AEP,UK)
************************
* 4-921-941-01 CUSHION (FL)
4-943-107-11 HOLDER (FL TUBE)
< CAPACITOR >
C202 1-104-905-11 DOUBLE LAYERS 0.22F 5.5V
C203 1-164-159-21 CERAMIC 0.1uF 50V
C204 1-128-821-21 CERAMIC 0.001uF 5% 50V
C205 1-127-876-11 CERAMIC 0.01uF 10% 50V
(AEP,UK)
C206 1-127-876-21 CERAMIC 0.01uF 10% 50V
C207 1-128-821-21 CERAMIC 0.001uF 5% 50V
C208 1-128-821-21 CERAMIC 0.001uF 5% 50V
C209 1-128-821-21 CERAMIC 0.001uF 5% 50V
C210 1-128-821-21 CERAMIC 0.001uF 5% 50V
C211 1-127-876-21 CERAMIC 0.01uF 10% 50V
C212 1-127-876-21 CERAMIC 0.01uF 10% 50V
C213 1-127-876-21 CERAMIC 0.01uF 10% 50V
C214 1-164-159-21 CERAMIC 0.1uF 50V
C215 1-126-795-11 ELECT 10uF 20% 50V
C216 1-126-795-11 ELECT 10uF 20% 50V
C217 1-128-821-21 CERAMIC 0.001uF 5% 50V
C218 1-128-821-21 CERAMIC 0.001uF 5% 50V
C219 1-126-794-11 ELECT 4.7uF 20% 50V
C221 1-128-821-21 CERAMIC 0.001uF 5% 50V
C222 1-128-821-21 CERAMIC 0.001uF 5% 50V
C225 1-164-159-21 CERAMIC 0.1uF 50V
C226 1-164-159-21 CERAMIC 0.1uF 50V
< CONNECTOR >
CN1 1-568-440-11 SOCKET, CONNECTOR 17P (US)
CN1 1-569-323-11 SOCKET, CONNECTOR 19P (AEP,UK)
CN2 1-569-321-11 SOCKET, CONNECTOR 15P
CN6 1-779-977-11 PIN, CONNECTOR 6P
< DIODE >
D201 8-719-991-33 DIODE 1SS133T-77
D202 8-719-991-33 DIODE 1SS133T-77
D203 8-719-046-39 LED SEL5821A-TP15 (BASS BOOST)
D204 8-719-991-33 DIODE 1SS133T-77
< FLUORESCENT INDICATOR >
FL201 1-517-662-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC201 6-801-317-01 IC uPD78044FGF-200-3B9
IC202 6-600-055-01 IC GP1UD27SXK
< COIL >
L201 1-410-509-11 INDUCTOR 10uH
< TRANSISTOR >
Q201 8-729-900-63 TRANSISTOR DTA124ES
Q202 8-729-900-36 TRANSISTOR DTC124ES
Q206 8-729-900-36 TRANSISTOR DTC124ES
< RESISTOR >
R227 1-249-381-11 CARBON 1 5% 1/4W
(AEP,UK)
R227 1-249-389-11 CARBON 4.7 5% 1/4W
(US)
R228 1-249-381-11 CARBON 1 5% 1/4W
(AEP,UK)
R228 1-249-389-11 CARBON 4.7 5% 1/4W
(US)
R229 1-247-807-31 CARBON 100 5% 1/4W
R230 1-247-807-31 CARBON 100 5% 1/4W
R231 1-247-807-31 CARBON 100 5% 1/4W
R232 1-247-807-31 CARBON 100 5% 1/4W
R233 1-247-807-31 CARBON 100 5% 1/4W
R234 1-247-807-31 CARBON 100 5% 1/4W
R235 1-247-807-31 CARBON 100 5% 1/4W
R236 1-247-807-31 CARBON 100 5% 1/4W
R237 1-247-807-31 CARBON 100 5% 1/4W
(AEP,UK)
R238 1-249-429-11 CARBON 10K 5% 1/4W
R239 1-249-429-11 CARBON 10K 5% 1/4W
R240 1-249-429-11 CARBON 10K 5% 1/4W
R241 1-249-441-11 CARBON 100K 5% 1/4W
R242 1-247-807-31 CARBON 100 5% 1/4W
(AEP,UK)
R243 1-249-429-11 CARBON 10K 5% 1/4W
(US)
R244 1-249-429-11 CARBON 10K 5% 1/4W
(US)
DISPLAY
