Sony STR-DE185 - Disassembly and Servicing; Case Removal Instructions

6
STR-DE185
Note : This set can be disassemble according to the following sequence.
SECTION 2
DISASSEMBLY
2-1. CASE
2-1. CASE
(Page 6)
2-2. FRONT PANEL SECTION
(Page 7)
2-3. BACK PANEL
(Page 7)
SET
2-4. MAIN BOARD
(Page 8)
Note : Follow the disassembly procedure in the numerical order given.
1 two screws
(case 3 TP2)
2 two screws
(case 3 TP2)
3 two screws
(case 3 TP2)
4 cas
e
