Sony STR-DE185 - Page 26

26
STR-DE185
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
S233 1-771-410-21 SWITCH, TACTILE (CD)
S234 1-771-410-21 SWITCH, TACTILE (MD/TAPE)
S235 1-771-410-21 SWITCH, TACTILE (VIDEO 2)
S236 1-771-410-21 SWITCH, TACTILE (VIDEO 1)
S237 1-771-410-21 SWITCH, TACTILE (MUTING)
S238 1-771-410-21 SWITCH, TACTILE (BASS BOOST)
S239 1-771-410-21 SWITCH, TACTILE (DISPLAY)
< VIBRATOR >
X201 1-577-101-11 VIBRATOR, CERAMIC (4.19MHz)
*************************************************************
1-683-816-11 HP BOARD
*********
< CONNECTOR >
CNP801 1-691-765-11 PLUG (MICRO CONNECTOR) 3P
< JACK >
J803 1-750-733-11 JACK (LARGE TYPE) (PHONES)
*************************************************************
A-4727-875-A MAIN BOARD, COMPLETE (US)
A-4727-881-A MAIN BOARD, COMPLETE (AEP,UK)
*********************
1-533-223-11 HOLDER, FUSE
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C402 1-126-964-11 ELECT 10uF 20% 50V
C404 1-126-964-11 ELECT 10uF 20% 50V
C406 1-126-964-11 ELECT 10uF 20% 50V
C408 1-126-964-11 ELECT 10uF 20% 50V
C410 1-126-964-11 ELECT 10uF 20% 50V
C412 1-126-964-11 ELECT 10uF 20% 50V
C413 1-126-794-11 ELECT 4.7uF 20% 50V
C414 1-136-167-00 FILM 0.15uF 5% 50V
C415 1-136-167-00 FILM 0.15uF 5% 50V
C416 1-136-169-00 FILM 0.22uF 5% 50V
C417 1-136-169-00 FILM 0.22uF 5% 50V
C418 1-137-368-11 MYLAR 0.0047uF 5% 50V
C419 1-126-964-11 ELECT 10uF 20% 50V
C420 1-126-794-11 ELECT 4.7uF 20% 50V
C421 1-164-159-21 CERAMIC 0.1uF 50V
C422 1-126-965-11 ELECT 22uF 20% 50V
C424 1-126-964-11 ELECT 10uF 20% 50V
C425 1-126-965-11 ELECT 22uF 20% 50V
C426 1-126-964-11 ELECT 10uF 20% 50V
C452 1-126-964-11 ELECT 10uF 20% 50V
C454 1-126-964-11 ELECT 10uF 20% 50V
C456 1-126-964-11 ELECT 10uF 20% 50V
C458 1-126-964-11 ELECT 10uF 20% 50V
C460 1-126-964-11 ELECT 10uF 20% 50V
C462 1-126-964-11 ELECT 10uF 20% 50V
C463 1-126-794-11 ELECT 4.7uF 20% 50V
C464 1-136-167-00 FILM 0.15uF 5% 50V
C465 1-136-167-00 FILM 0.15uF 5% 50V
C466 1-136-169-00 FILM 0.22uF 5% 50V
C467 1-136-169-00 FILM 0.22uF 5% 50V
C468 1-137-368-11 MYLAR 0.0047uF 5% 50V
C469 1-126-964-11 ELECT 10uF 20% 50V
C470 1-126-794-11 ELECT 4.7uF 20% 50V
C471 1-164-159-21 CERAMIC 0.1uF 50V
C472 1-126-965-11 ELECT 22uF 20% 50V
C474 1-126-964-11 ELECT 10uF 20% 50V
C475 1-126-965-11 ELECT 22uF 20% 50V
C476 1-126-964-11 ELECT 10uF 20% 50V
C483 1-126-965-11 ELECT 22uF 20% 50V
C484 1-126-964-11 ELECT 10uF 20% 50V
C485 1-164-159-21 CERAMIC 0.1uF 50V
C490 1-126-935-11 ELECT 470uF 20% 10V
C602 1-128-809-11 CERAMIC 100PF 5% 50V
C603 1-102-233-00 CERAMIC 33PF 10% 500V
C604 1-128-809-11 CERAMIC 100PF 5% 50V
C606 1-126-933-11 ELECT 100uF 20% 16V
C607 1-126-794-11 ELECT 4.7uF 20% 50V
C652 1-128-809-11 CERAMIC 100PF 5% 50V
C653 1-102-233-00 CERAMIC 33PF 10% 500V
C654 1-128-809-11 CERAMIC 100PF 5% 50V
C656 1-126-933-11 ELECT 100uF 20% 16V
C657 1-126-794-11 ELECT 4.7uF 20% 50V
C682 1-128-582-11 ELECT 10uF 20% 100V
C701 1-126-947-11 ELECT 47uF 20% 16V
C702 1-107-597-11 CERAMIC 22PF 10% 500V
C703 1-107-597-11 CERAMIC 22PF 10% 500V
C704 1-128-813-11 CERAMIC 220PF 5% 50V
C705 1-137-372-11 MYLAR 0.022uF 5% 50V
C751 1-126-947-11 ELECT 47uF 20% 16V
C752 1-107-597-11 CERAMIC 22PF 10% 500V
C753 1-107-597-11 CERAMIC 22PF 10% 500V
C754 1-128-813-11 CERAMIC 220PF 5% 50V
C755 1-137-372-11 MYLAR 0.022uF 5% 50V
C781 1-126-934-11 ELECT 220uF 20% 10V
C782 1-126-964-11 ELECT 10uF 20% 50V
C791 1-164-159-21 CERAMIC 0.1uF 50V
C901 1-164-159-21 CERAMIC 0.1uF 50V
C902 1-164-159-21 CERAMIC 0.1uF 50V
C903 1-164-159-21 CERAMIC 0.1uF 50V
C904 1-126-960-11 ELECT 1uF 20% 50V
C905 1-126-936-11 ELECT 3300uF 20% 16V
C906 1-164-159-21 CERAMIC 0.1uF 50V
C907 1-164-159-21 CERAMIC 0.1uF 50V
C908 1-126-964-11 ELECT 10uF 20% 50V
C909 1-126-957-11 ELECT 0.22uF 20% 50V
C910 1-164-159-21 CERAMIC 0.1uF 50V
C911 1-164-159-21 CERAMIC 0.1uF 50V
HP MAINDISPLAY
