Sony STR-DE445 - Electrical Parts List; AC SEL & Digital Board Parts

34
SECTION 5
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
AC SEL
1-676-788-11 AC SEL BOARD (E,PX)
*************
1-533-223-11 HOLDER, FUSE (E,PX)
< CONNECTOR >
* CNP910 1-580-445-11 PIN, CONNECTOR 3P(E,PX)
< FUSE >
0 F903 1-532-504-31 FUSE T4AL 250V(E,PX)
< SWITCH >
0 S901 1-571-437-11 SWITCH, POWER VOLTAGE CHANGE
(VOLTAGE SELECTOR)(E,PX)
**************************************************************
A-4424-456-A DIGITAL BOARD, COMPLETE (DE445)
************************
A-4424-459-A DIGITAL BOARD, COMPLETE (DE545,SE501)
************************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C1001 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1002 1-165-319-11 CERAMIC CHIP 0.1uF 50V
(DE545,SE501)
C1101 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1102 1-163-021-91 CERAMIC CHIP 0.01uF 10.00% 50V
C1103 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1104 1-104-664-11 ELECT 47uF 20.00% 16V
C1105 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1106 1-163-021-91 CERAMIC CHIP 0.01uF 10.00% 50V
C1107 1-104-664-11 ELECT 47uF 20.00% 16V
C1108 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1109 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1110 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1111 1-163-021-91 CERAMIC CHIP 0.01uF 10.00% 50V
C1112 1-163-233-11 CERAMIC CHIP 18PF 5.00% 50V
C1113 1-163-233-11 CERAMIC CHIP 18PF 5.00% 50V
C1114 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1115 1-104-664-11 ELECT 47uF 20.00% 16V
C1116 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C1201 1-126-965-11 ELECT 22uF 20.00% 50V
C1202 1-106-347-00 MYLAR 0.0015uF 5.00% 50V
C1221 1-126-965-11 ELECT 22uF 20.00% 50V
C1222 1-126-965-11 ELECT 22uF 20.00% 50V
C1223 1-126-965-11 ELECT 22uF 20.00% 50V
C1224 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1225 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1226 1-126-964-11 ELECT 10uF 20.00% 50V
C1228 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1229 1-104-664-11 ELECT 47uF 20.00% 16V
C1230 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1231 1-126-964-11 ELECT 10uF 20.00% 50V
C1232 1-126-935-11 ELECT 470uF 20.00% 6.3V
C1233 1-126-960-11 ELECT 1uF 20.00% 50V
C1251 1-126-965-11 ELECT 22uF 20.00% 50V
C1252 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1253 1-126-964-11 ELECT 10uF 20.00% 50V
C1254 1-106-347-00 MYLAR 0.0015uF 5.00% 50V
C1271 1-126-965-11 ELECT 22uF 20.00% 50V
C1272 1-126-965-11 ELECT 22uF 20.00% 50V
C1273 1-126-965-11 ELECT 22uF 20.00% 50V
C1301 1-126-935-11 ELECT 470uF 20.00% 6.3V
C1302 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1303 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1304 1-104-664-11 ELECT 47uF 20.00% 16V
C1305 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C1306 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1307 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1308 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1309 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1310 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1311 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1312 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1313 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1314 1-126-960-11 ELECT 1uF 20.00% 50V
C1315 1-126-935-11 ELECT 470uF 20.00% 6.3V
C1316 1-126-935-11 ELECT 470uF 20.00% 6.3V
C1317 1-126-960-11 ELECT 1uF 20.00% 50V
C1318 1-104-665-11 ELECT 100uF 20.00% 10V
C1319 1-104-665-11 ELECT 100uF 20.00% 10V
C1320 1-126-935-11 ELECT 470uF 20.00% 6.3V
C1321 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C1322 1-163-243-11 CERAMIC CHIP 47PF 5.00% 50V
C1323 1-163-217-11 CERAMIC CHIP 1PF 0.25PF 50V
C1324 1-126-965-11 ELECT 22uF 20.00% 50V
C1325 1-163-021-91 CERAMIC CHIP 0.01uF 10.00% 50V
C1329 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board name.
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
• Abbreviation
CND : Canadian
AUS : Australian
CH : Chinese
MY : Malaysia
SP : Singapore
TW : Taiwan
DIGITAL
