Sony STR-DE445 - Power Switch, STBY, Other Boards Parts

45
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< SWITCH >
S501 1-771-692-11 SWITCH, SLIDE(IMPEDANCE SELECTOR)
(DE545,SE501)
< TERMINAL >
TM601 1-537-923-11 TERMINAL BOARD (SPEAKER) (6P)
(REAR,CENTER)
TM602 1-694-652-11 TERMINAL BOARD (SP)(FRONT)(DE545,SE501)
TM602 1-537-925-61 TERMINAL BOARD(FRONT)(DE445)
< VIBRATOR >
X301 1-579-900-21 VIBRATOR, CRYSTAL 4.33MHz(AEP,UK,CIS)
**************************************************************
1-676-784-11 POWER SWITCH BOARD
********************
< CONNECTOR >
CNS100 1-573-105-11 CONNECTOR, PC BOARD 4P
< SWITCH >
S150 1-771-410-21 SWITCH, TACTILE(@/1)
S151 1-771-854-11 SWITCH, PUSH (1 KEY)(SPEAKER A)
S152 1-771-854-11 SWITCH, PUSH (1 KEY)(SPEAKER B)
(DE545,SE501)
**************************************************************
A-4428-435-A STBY BOARD, COMPLETE (US,CND)
*********************
A-4428-478-A STBY BOARD, COMPLETE (E,PX)
*********************
A-4428-481-A STBY BOARD, COMPLETE (AEP,UK,CIS,SP,MY)
*********************
A-4428-491-A STBY BOARD, COMPLETE (AUS)
*********************
A-4428-497-A STBY BOARD, COMPLETE (CH)
*********************
A-4473-334-A STBY BOARD, COMPLETE (TW)
*********************
1-533-293-11 FUSE HOLDER
1-533-223-11 HOLDER, FUSE
< CAPACITOR >
C922 1-164-159-11 CERAMIC 0.1uF 50V
C923 1-164-159-11 CERAMIC 0.1uF 50V
C950 1-126-936-11 ELECT 3300uF 20.00% 16V
C951 1-164-159-11 CERAMIC 0.1uF 50V
C952 1-126-960-11 ELECT 1uF 20.00% 50V
C953 1-126-957-11 ELECT 0.22uF 20.00% 50V
C954 1-126-964-11 ELECT 10uF 20.00% 50V
C955 1-164-159-11 CERAMIC 0.1uF 50V
C957 1-164-159-11 CERAMIC 0.1uF 50V
C958 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CNP901 1-564-321-00 PIN, CONNECTOR 2P
* CNP902 1-565-792-11 PIN, CONNECTOR 2P
CNP906 1-568-106-11 PIN, CONNECTOR 4P(E,PX)
CNP912 1-691-767-11 PLUG (MICRO CONNECTOR) 5P
< DIODE >
D901 8-719-911-19 DIODE 1SS133T-72
D910 8-719-024-99 DIODE 11ES2-NTA2B
D911 8-719-024-99 DIODE 11ES2-NTA2B
D912 8-719-024-99 DIODE 11ES2-NTA2B
D913 8-719-024-99 DIODE 11ES2-NTA2B
D914 8-719-911-19 DIODE 1SS133T-72
D915 8-719-911-19 DIODE 1SS133T-72
< FUSE >
0 F901 1-532-504-31 FUSE T4AL 250V(EXCEPT US,CND,TW)
0 F901 1-576-193-11 FUSE 6.3A/125V(US,CND,TW)
0 F902 1-532-464-31 FUSE T2.5AL 250V(EXCEPT US,CND,TW,E,PX)
< TERMINAL >
* G901 1-537-738-21 TERMINAL, EARTH
< IC >
IC950 8-759-333-83 IC NJM2103D
< JACK >
0 J911 1-785-285-11 OUTLET, AC (1P)(AC OUTLET)
(DE545:AEP,UK,CIS,SP,MY)
0 J911 1-251-417-11 OUTLET, A.C.(AC OUTLET)(DE545:AUS)
0 J911 1-785-834-11 OUTLET (1P)(AC OUTLET)
(DE545:US,CND,CH,TW,E,PX,SE501)
< TRANSISTOR >
Q901 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
Q951 8-729-045-21 TRANSISTOR 2SD1513TP-LK
< RESISTOR >
R901 1-202-725-00 SOLID 3.3M 10% 1/2W
(US,CND)
R902 1-249-437-11 CARBON 47K 5% 1/4W
R903 1-249-425-11 CARBON 4.7K 5% 1/4W F
R950 1-249-421-11 CARBON 2.2K 5% 1/4W F
R951 1-249-428-11 CARBON 8.2K 5% 1/4W F
R952 1-249-422-11 CARBON 2.7K 5% 1/4W F
R953 1-249-433-11 CARBON 22K 5% 1/4W
R954 1-249-437-11 CARBON 47K 5% 1/4W
R955 1-249-429-11 CARBON 10K 5% 1/4W
R956 1-247-843-11 CARBON 3.3K 5% 1/4W
R957 1-249-417-11 CARBON 1K 5% 1/4W F
R960 1-249-431-11 CARBON 15K 5% 1/4W
< RELAY >
RY901 1-755-298-11 RELAY
POWER SWITCH
MAIN STBY
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
