Sony STR-DE445 - S-Video, Tuner, Video Board Parts

46
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
S-VIDEO
< TRANSFORMER >
0 T902 1-435-435-11 TRANSFORMER, POWER
(CH,AEP,UK,CIS,SP,MY,AUS)
0 T902 1-435-563-11 TRANSFORMER, POWER(TW)
0 T902 1-435-434-11 TRANSFORMER, POWER(E,PX)
0 T902 1-435-436-11 TRANSFORMER, POWER
(DE445/DE545:US,CND,AEP,UK,CIS,SP,MY,SE501)
**************************************************************
1-676-782-11 S-VIDEO BOARD (DE545,SE501)
**************
< CAPACITOR >
C1501 1-126-964-11 ELECT 10uF 20.00% 50V
(DE545,SE501)
C1502 1-164-159-11 CERAMIC 0.1uF 50V
(DE545,SE501)
C1503 1-126-964-11 ELECT 10uF 20.00% 50V
(DE545,SE501)
C1504 1-164-159-11 CERAMIC 0.1uF 50V
(DE545,SE501)
C1505 1-136-165-00 MYLAR 0.1uF 5.00% 50V
(DE545,SE501)
C1506 1-126-960-11 ELECT 1uF 20.00% 50V
(DE545,SE501)
C1507 1-128-817-11 CERAMIC 470PF 5% 50V
(DE545,SE501)
C1508 1-128-817-11 CERAMIC 470PF 5% 50V
(DE545,SE501)
< CONNECTOR >
CNS200 1-569-315-11 SOCKET, CONNECTOR 5P(DE545,SE501)
< IC >
IC1016 8-759-333-84 IC NJM2279D(DE545,SE501)
< JACK >
J1002 1-537-943-11 TERMINAL, S(MONITOR S VIDEO OUT)
(DE545,SE501)
J1003 1-537-943-11 TERMINAL, S(DVD/LD S VIDEO IN)
(DE545,SE501)
< RESISTOR >
R1502 1-247-804-11 CARBON 75 5% 1/4W
(DE545,SE501)
R1503 1-247-804-11 CARBON 75 5% 1/4W
(DE545,SE501)
R1504 1-247-804-11 CARBON 75 5% 1/4W
(DE545,SE501)
R1505 1-247-804-11 CARBON 75 5% 1/4W
(DE545,SE501)
**************************************************************
1-676-785-11 TUNER SWITCH BOARD
********************
< CONNECTOR >
CNS110 1-573-105-11 CONNECTOR, PC BOARD 4P
< DIODE >
D001 8-719-046-39 DIODE SEL5821A-TP15(MUTING)
< RESISTOR >
R001 1-249-411-11 CARBON 330 5% 1/4W
R002 1-249-413-11 CARBON 470 5% 1/4W F
R003 1-249-415-11 CARBON 680 5% 1/4W F
R004 1-249-417-11 CARBON 1K 5% 1/4W F
R005 1-249-419-11 CARBON 1.5K 5% 1/4W F
R006 1-249-421-11 CARBON 2.2K 5% 1/4W F
R007 1-247-843-11 CARBON 3.3K 5% 1/4W
R008 1-249-425-11 CARBON 4.7K 5% 1/4W F
(AEP,UK,CIS)
R009 1-249-429-11 CARBON 10K 5% 1/4W
(AEP,UK,CIS)
R017 1-247-843-11 CARBON 3.3K 5% 1/4W
R018 1-249-425-11 CARBON 4.7K 5% 1/4W F
R019 1-249-429-11 CARBON 10K 5% 1/4W
R051 1-249-407-11 CARBON 150 5% 1/4W F
< SWITCH >
S100 1-771-410-21 SWITCH, TACTILE(SHIFT)
S101 1-771-410-21 SWITCH, TACTILE(BASS BOOST)
S102 1-771-410-21 SWITCH, TACTILE(MUTING)
S103 1-771-410-21 SWITCH, TACTILE(FM MODE)
S104 1-771-410-21 SWITCH, TACTILE(PRESET +)
S105 1-771-410-21 SWITCH, TACTILE(TUNING -)
S106 1-771-410-21 SWITCH, TACTILE(MEMORY)
S107 1-771-410-21 SWITCH, TACTILE(TONE)
S108 1-771-410-21 SWITCH, TACTILE(PTY)(AEP,UK,CIS)
S109 1-771-410-21 SWITCH, TACTILE(RDS EON)(AEP,UK,CIS)
S117 1-771-410-21 SWITCH, TACTILE(PRESET –)
S118 1-771-410-21 SWITCH, TACTILE(TUNING +)
S119 1-771-410-21 SWITCH, TACTILE(AM/FM)
**************************************************************
1-676-781-11 VIDEO BOARD
************
< CAPACITOR >
C1602 1-164-159-11 CERAMIC 0.1uF 50V
C1603 1-126-964-11 ELECT 10uF 20.00% 50V
C1604 1-164-159-11 CERAMIC 0.1uF 50V
C1605 1-128-805-11 CERAMIC 47PF 5% 50V
C1606 1-128-805-11 CERAMIC 47PF 5% 50V
C1607 1-126-960-11 ELECT 1uF 20.00% 50V
C1608 1-126-960-11 ELECT 1uF 20.00% 50V
C1609 1-126-960-11 ELECT 1uF 20.00% 50V
C1610 1-164-159-11 CERAMIC 0.1uF 50V
(DE545,SE501)
STBY
TUNER
VIDEO
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
