Sony STR-DE445 - Video Section Component List

47
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
C1611 1-126-965-11 ELECT 22uF 20.00% 50V
C1612 1-126-964-11 ELECT 10uF 20.00% 50V
< CONNECTOR >
CNS107 1-691-768-11 PLUG (MICRO CONNECTOR) 6P
* CNS500 1-564-506-11 PLUG, CONNECTOR 3P
< CONNECTOR >
CNP201 1-569-315-11 SOCKET, CONNECTOR 5P(DE545,SE501)
< DIODE >
D1001 8-719-921-48 DIODE MTZJ-T-72-5.6C(DE545,SE501)
< IC >
IC1014 8-759-701-65 IC NJM79M05FA
IC1015 8-759-333-84 IC NJM2279D
< JACK >
J1004 1-695-317-11 JACK, PIN 2P(VIDEO IN,MONITOR OUT)
J1006 1-766-199-11 JACK, PIN 3P(TV/SAT,DVD/LD,VIDEO OUT)
J1007 1-563-330-11 JACK(CTRL A1 II )(DE545,SE501)
< RESISTOR >
R1601 1-247-804-11 CARBON 75 5% 1/4W
R1602 1-247-804-11 CARBON 75 5% 1/4W
R1603 1-247-804-11 CARBON 75 5% 1/4W
R1604 1-247-804-11 CARBON 75 5% 1/4W
R1605 1-247-804-11 CARBON 75 5% 1/4W
**************************************************************
MISCELLANEOUS
***************
0 59 1-696-847-11 CORD, POWER(AUS)
0 59 1-777-070-21 CORD, POWER(CND)
0 59 1-777-071-21 CORD, POWER(AEP,UK,CIS,SP,MY,E,PX)
0 59 1-783-205-11 CORD, POWER(CH)
0 59 1-783-820-11 CORD, POWER(TW,US)
63 1-769-840-11 WIRE (FLAT TYPE) (5 CORE)(DE545,SE501)
66 1-693-407-41 TUNER(TW,US,CND,E,PX)
66 1-693-408-41 TUNER(CH,AEP,UK,CIS,SP,MY,AUS)
67 1-773-001-11 WIRE (FLAT TYPE) (15 CORE)
0 68 1-569-008-21 ADAPTOR, CONVERSION 2P(E,PX)
70 1-500-386-11 FILTER, CLAMP (FERRITE CORE)
FL101 1-517-929-11 TUBE, FLUORESCENT INDICATOR
0 T901 1-435-306-11 TRANSFORMER, POWER(DE545:US)
0 T901 1-435-306-21 TRANSFORMER, POWER(SE501)
0 T901 1-435-307-11 TRANSFORMER, POWER(DE545:CND)
0 T901 1-435-308-11 TRANSFORMER, POWER(DE545:AUS)
0 T901 1-435-309-11 TRANSFORMER, POWER
(DE545:CH,AEP,UK,CIS,SP,MY)
0 T901 1-435-310-11 TRANSFORMER, POWER(DE545:E,PX)
0 T901 1-435-312-11 TRANSFORMER, POWER(DE445:CND)
0 T901 1-435-313-11 TRANSFORMER, POWER(DE445:US)
0 T901 1-435-314-11 TRANSFORMER, POWER(DE445:AEP,UK,CIS)
0 T901 1-435-562-11 TRANSFORMER, POWER(DE545:TW)
**************************************************************
VIDEO
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
