Sony STR-DE445 - Page 44

44
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R696 1-249-405-11 CARBON 100 5% 1/4W F
R697 1-249-441-11 CARBON 100K 5% 1/4W
R698 1-249-441-11 CARBON 100K 5% 1/4W
R699 1-215-888-00 METAL OXIDE 220 5% 2W
R701 1-249-417-11 CARBON 1K 5% 1/4W F
R702 1-249-439-11 CARBON 68K 5% 1/4W
R703 1-249-413-11 CARBON 470 5% 1/4W F
(DE545,SE501)
R703 1-249-415-11 CARBON 680 5% 1/4W F
(DE445)
R704 1-249-439-11 CARBON 68K 5% 1/4W
R705 1-249-441-11 CARBON 100K 5% 1/4W
R710 1-249-421-11 CARBON 2.2K 5% 1/4W F
R711 1-249-440-11 CARBON 82K 5% 1/4W
R713 1-249-414-11 CARBON 560 5% 1/4W F
R714 1-249-408-11 CARBON 180 5% 1/4W F
R715 1-249-408-11 CARBON 180 5% 1/4W F
R716 1-234-182-11 ENCAPSULATED COMPONENT
R717 1-249-393-11 CARBON 10 5% 1/4W F
R718 1-249-389-11 CARBON 4.7 5% 1/4W F
R719 1-249-425-11 CARBON 4.7K 5% 1/4W F
R721 1-247-850-11 CARBON 6.2K 5% 1/4W
R722 1-249-419-11 CARBON 1.5K 5% 1/4W F
R723 1-249-437-11 CARBON 47K 5% 1/4W
R724 1-247-881-00 CARBON 120K 5% 1/4W
R727 1-249-433-11 CARBON 22K 5% 1/4W
R730 1-249-425-11 CARBON 4.7K 5% 1/4W F
R731 1-249-425-11 CARBON 4.7K 5% 1/4W F
R732 1-249-381-11 CARBON 1 5% 1/4W F
R733 1-249-381-11 CARBON 1 5% 1/4W F
R735 1-249-427-11 CARBON 6.8K 5% 1/4W F
R736 1-249-417-11 CARBON 1K 5% 1/4W F
R737 1-249-436-11 CARBON 39K 5% 1/4W
R738 1-247-881-00 CARBON 120K 5% 1/4W
R739 1-249-431-11 CARBON 15K 5% 1/4W
R740 1-247-866-11 CARBON 30K 5% 1/4W
R741 1-249-425-11 CARBON 4.7K 5% 1/4W F
(DE545,SE501)
R743 1-249-433-11 CARBON 22K 5% 1/4W
R744 1-249-431-11 CARBON 15K 5% 1/4W
R745 1-249-422-11 CARBON 2.7K 5% 1/4W F
(AEP,UK,CIS)
R745 1-249-421-11 CARBON 2.2K 5% 1/4W F
(EXCEPT AEP,UK,CIS)
R746 1-249-433-11 CARBON 22K 5% 1/4W
R747 1-249-433-11 CARBON 22K 5% 1/4W
R748 1-249-437-11 CARBON 47K 5% 1/4W
R749 1-249-425-11 CARBON 4.7K 5% 1/4W F
(DE545,SE501)
R751 1-249-417-11 CARBON 1K 5% 1/4W F
R752 1-249-439-11 CARBON 68K 5% 1/4W
R753 1-249-413-11 CARBON 470 5% 1/4W F
(DE545,SE501)
R753 1-249-415-11 CARBON 680 5% 1/4W F
(DE445)
R754 1-249-439-11 CARBON 68K 5% 1/4W
R760 1-249-421-11 CARBON 2.2K 5% 1/4W F
R761 1-249-440-11 CARBON 82K 5% 1/4W
R763 1-249-414-11 CARBON 560 5% 1/4W F
R764 1-249-408-11 CARBON 180 5% 1/4W F
R765 1-249-408-11 CARBON 180 5% 1/4W F
R766 1-234-182-11 ENCAPSULATED COMPONENT
R767 1-249-393-11 CARBON 10 5% 1/4W F
R768 1-249-389-11 CARBON 4.7 5% 1/4W F
R770 1-249-425-11 CARBON 4.7K 5% 1/4W F
R771 1-247-850-11 CARBON 6.2K 5% 1/4W
R772 1-249-419-11 CARBON 1.5K 5% 1/4W F
R775 1-249-422-11 CARBON 2.7K 5% 1/4W F
(AEP,UK,CIS)
R775 1-249-421-11 CARBON 2.2K 5% 1/4W F
(EXCEPT AEP,UK,CIS)
R776 1-249-431-11 CARBON 15K 5% 1/4W
R777 1-247-866-11 CARBON 30K 5% 1/4W
R778 1-249-431-11 CARBON 15K 5% 1/4W
R779 1-249-437-11 CARBON 47K 5% 1/4W
R791 1-215-868-00 METAL OXIDE 680 5% 1W
R793 1-249-425-11 CARBON 4.7K 5% 1/4W F
R799 1-215-868-00 METAL OXIDE 680 5% 1W
R800 1-249-400-11 CARBON 39 5% 1/4W F
R801 1-249-381-11 CARBON 1 5% 1/4W F
R802 1-249-381-11 CARBON 1 5% 1/4W F
R803 1-249-400-11 CARBON 39 5% 1/4W F
R804 1-249-427-11 CARBON 6.8K 5% 1/4W F
R805 1-249-433-11 CARBON 22K 5% 1/4W
0 R810 1-240-877-11 FUSIBLE 0.15 5% 1/2W
0 R811 1-240-877-11 FUSIBLE 0.15 5% 1/2W
0 R812 1-243-635-91 FUSIBLE 0.33 5% 1/2W
0 R813 1-240-877-11 FUSIBLE 0.15 5% 1/2W
< RESISTOR >
RR11 1-249-393-11 CARBON 10 5% 1/4W F
(EXCEPT E,PX)
RR12 1-249-393-11 CARBON 10 5% 1/4W F
(EXCEPT E,PX)
RR13 1-249-393-11 CARBON 10 5% 1/4W F
(EXCEPT E,PX)
RR14 1-249-393-11 CARBON 10 5% 1/4W F
(EXCEPT E,PX)
RR15 1-249-393-11 CARBON 10 5% 1/4W F
(EXCEPT E,PX)
RR21 1-249-393-11 CARBON 10 5% 1/4W F
(EXCEPT DE445,E,PX)
RR22 1-249-393-11 CARBON 10 5% 1/4W F
(EXCEPT DE445,E,PX)
RR448 1-249-437-11 CARBON 47K 5% 1/4W
< RELAY >
RY550 1-755-170-11 RELAY (12V)
RY560 1-755-267-11 RELAY
RY601 1-755-170-11 RELAY (12V)
RY730 1-755-170-11 RELAY (12V)
RY740 1-755-170-11 RELAY (12V)(DE545,SE501)
RY791 1-515-614-11 RELAY
MAIN
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
