STR-DE495/DE595
SECTION 6
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
BRIDGEABLE BOARD (DE595)
*****************
< CONNECTOR >
* CN906 1-564-214-11 PIN, CONNECTOR (3.96mm PITCH) 3P (DE595)
* CN908 1-564-242-00 PIN, CONNECTOR (3.96mm PITCH) 5P (DE595)
CNP904 1-691-765-11 PLUG (MICRO CONNECTOR) 3P (DE595)
< DIODE >
D818 8-719-911-19 DIODE 1SS119-25 (DE595)
< TRANSISTOR >
Q809 8-729-119-79 TRANSISTOR 2SC2785-FEK (DE595)
< RESISTOR >
R824 1-249-425-11 CARBON 4.7K 5% 1/4W
(DE595)
R830 1-249-401-11 CARBON 47 5% 1/4W
(CND)
R830 1-249-404-81 CARBON 82 5% 1/4W
(EXCEPT CND)
R831 1-249-401-11 CARBON 47 5% 1/4W
(CND)
< RELAY >
RY801 1-755-013-11 RELAY (EXCEPT CND)
RY802 1-755-494-11 RELAY (CND)
RY803 1-755-494-11 RELAY (CND)
*************************************************************
A-4732-412-A DIGITAL BOARD, COMPLETE (DE595:US,CND)
A-4732-431-A DIGITAL BOARD, COMPLETE (DE495:AEP,UK)
A-4732-594-A DIGITAL BOARD, COMPLETE (DE595:AUS)
A-4732-607-A DIGITAL BOARD, COMPLETE (DE595:MY,SP,KR)
A-4732-612-A DIGITAL BOARD, COMPLETE (DE595:E2)
A-4732-615-A DIGITAL BOARD, COMPLETE (DE595:MX,AR)
A-4732-625-A DIGITAL BOARD, COMPLETE (DE595:AEP,UK)
A-4732-631-A DIGITAL BOARD, COMPLETE (DE495:KR,SP,MY)
A-4734-333-A DIGITAL BOARD, COMPLETE (DE595:TW)
A-4734-359-A DIGITAL BOARD, COMPLETE (DE495:TW)
A-4734-763-A DIGITAL BOARD, COMPLETE (DE495:AUS)
***********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C1101 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1102 1-126-947-11 ELECT 47uF 20% 16V
C1103 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1104 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1105 1-126-947-11 ELECT 47uF 20% 16V
C1106 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1107 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1108 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1109 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
C1110 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
C1111 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1112 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1113 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1114 1-162-905-11 CERAMIC CHIP 1PF 0.25PF 50V
C1115 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C1116 1-126-916-11 ELECT 1000uF 20% 6.3V
C1117 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1118 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C1119 1-126-965-11 ELECT 22uF 20% 50V
C1121 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1123 1-164-156-11 CERAMIC CHIP 0.1uF 25V
(DE595)
C1124 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1129 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C1130 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1131 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1201 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1202 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1203 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1204 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1205 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1206 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1207 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1208 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1209 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1210 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1211 1-126-935-11 ELECT 470uF 20% 10V
C1212 1-126-935-11 ELECT 470uF 20% 10V
C1213 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1214 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1216 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1218 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1219 1-164-156-11 CERAMIC CHIP 0.1uF 25V
DIGITAL
•Abbreviation
CND : Canadian model
AUS: Australian model
MX : Mexican model
SP : Singapore model
E2 : AC 120 V area in E model
AR : Argentine model
KR : Korean model
TW : Taiwan model
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour
la sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
When indicating parts by reference
number, please include the board.
BRIDGEABLE
Ver 1.1
