45
STR-DE495/DE595
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R134 1-249-425-11 CARBON 4.7K 5% 1/4W
R135 1-249-429-11 CARBON 10K 5% 1/4W
R136 1-249-433-11 CARBON 22K 5% 1/4W
(DE595)
R141 1-249-421-11 CARBON 2.2K 5% 1/4W
(DE595)
R150 1-249-440-11 CARBON 82K 5% 1/4W
R153 1-247-807-31 CARBON 100 5% 1/4W
R154 1-249-393-11 CARBON 10 5% 1/4W
R155 1-249-441-11 CARBON 100K 5% 1/4W
R160 1-249-402-11 CARBON 56 5% 1/4W
(DE595)
R161 1-249-409-11 CARBON 220 5% 1/4W
R162 1-249-429-11 CARBON 10K 5% 1/4W
(DE595)
R175 1-249-393-11 CARBON 10 5% 1/4W
R198 1-249-381-11 CARBON 1 5% 1/4W
R199 1-249-381-11 CARBON 1 5% 1/4W
< SWITCH >
S100 1-771-410-21 SWITCH, TACTILE (MENU <)
S101 1-771-410-21 SWITCH, TACTILE (MENU >)
S102 1-771-410-21 SWITCH, TACTILE (MAIN MENU)
S103 1-771-410-21 SWITCH, TACTILE (ENTER)
S104 1-771-410-21 SWITCH, TACTILE (INPUT MODE)
S105 1-771-410-21 SWITCH, TACTILE (MENU –)
S106 1-771-410-21 SWITCH, TACTILE (MENU +)
S110 1-771-410-21 SWITCH, TACTILE (TUNER FM/AM)
S111 1-771-410-21 SWITCH, TACTILE (CD) (DE495)
S111 1-771-410-21 SWITCH, TACTILE (CD/SACD) (DE595)
S112 1-771-410-21 SWITCH, TACTILE (MD/TAPE)
S113 1-771-410-21 SWITCH, TACTILE (DVD)
S114 1-771-410-21 SWITCH, TACTILE (MOVIE)
S115 1-771-410-21 SWITCH, TACTILE (MUSIC)
S116 1-771-410-21 SWITCH, TACTILE (MULTI CH IN) (DE595)
S120 1-771-410-21 SWITCH, TACTILE (A.F.D.)
S121 1-771-410-21 SWITCH, TACTILE (TUNING –)
S122 1-771-410-21 SWITCH, TACTILE (FM MODE)
S123 1-771-410-21 SWITCH, TACTILE (TUNING +)
S124 1-771-410-21 SWITCH, TACTILE (2CH)
S125 1-771-410-21 SWITCH, TACTILE (PRESET TUNING +)
S130 1-771-410-21 SWITCH, TACTILE (VIDEO 2)
S131 1-771-410-21 SWITCH, TACTILE (VIDEO 1)
S132 1-771-410-21 SWITCH, TACTILE (PRESET TUNING –)
S133 1-771-410-21 SWITCH, TACTILE (MEMORY)
S134 1-771-410-21 SWITCH, TACTILE (DISPLAY)
S135 1-771-410-21 SWITCH, TACTILE (DIMMER)
*************************************************************
HEADPHONE BOARD
*****************
< CAPACITOR >
C790 1-164-159-11 CERAMIC 0.1uF 50V
C792 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CNP791 1-691-767-11 PLUG (MICRO CONNECTOR) 5P
< JACK >
J791 1-815-313-21 JACK (PHONES) (SP,MY,KR,TW)
J791 1-815-314-21 JACK (PHONES) (EXCEPT SP,MY,KR,TW)
*************************************************************
A-4731-280-A MAIN BOARD, COMPLETE
(DE495:AEP,UK,AUS,KR,TW)
A-4732-423-A MAIN BOARD, COMPLETE (DE595:US,CND)
A-4732-595-A MAIN BOARD, COMPLETE
(DE595:AEP,UK,AUS,KR,TW)
A-4732-608-A MAIN BOARD, COMPLETE
(DE595:E2,MX,SP,MY,AR)
A-4732-632-A MAIN BOARD, COMPLETE (DE495:SP,MY)
*********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C371 1-127-880-11 CERAMIC 0.022uF 10% 50V
C372 1-127-880-11 CERAMIC 0.022uF 10% 50V
C373 1-127-880-11 CERAMIC 0.022uF 10% 50V
C374 1-164-159-11 CERAMIC 0.1uF 50V
C375 1-127-880-11 CERAMIC 0.022uF 10% 50V
C376 1-127-880-11 CERAMIC 0.022uF 10% 50V
C400 1-164-159-11 CERAMIC 0.1uF 50V
C402 1-126-961-11 ELECT 2.2uF 20% 50V
C404 1-126-961-11 ELECT 2.2uF 20% 50V
C405 1-126-961-11 ELECT 2.2uF 20% 50V
C406 1-126-963-11 ELECT 4.7uF 20% 50V
C407 1-126-961-11 ELECT 2.2uF 20% 50V
C408 1-126-963-11 ELECT 4.7uF 20% 50V
C409 1-126-963-11 ELECT 4.7uF 20% 50V
C411 1-126-961-11 ELECT 2.2uF 20% 50V
(DE595)
C412 1-126-961-11 ELECT 2.2uF 20% 50V
(DE595)
C413 1-124-257-00 ELECT 2.2uF 20% 50V
C414 1-124-257-00 ELECT 2.2uF 20% 50V
C415 1-124-257-00 ELECT 2.2uF 20% 50V
C416 1-126-961-11 ELECT 2.2uF 20% 50V
C417 1-124-257-00 ELECT 2.2uF 20% 50V
C418 1-126-961-11 ELECT 2.2uF 20% 50V
C419 1-124-257-00 ELECT 2.2uF 20% 50V
C431 1-126-961-11 ELECT 2.2uF 20% 50V
(DE595)
C432 1-126-961-11 ELECT 2.2uF 20% 50V
(DE595)
C433 1-126-961-11 ELECT 2.2uF 20% 50V
C452 1-126-961-11 ELECT 2.2uF 20% 50V
C454 1-126-961-11 ELECT 2.2uF 20% 50V
C455 1-126-961-11 ELECT 2.2uF 20% 50V
C456 1-126-963-11 ELECT 4.7uF 20% 50V
C457 1-126-961-11 ELECT 2.2uF 20% 50V
C458 1-126-963-11 ELECT 4.7uF 20% 50V
C459 1-126-963-11 ELECT 4.7uF 20% 50V
C461 1-126-961-11 ELECT 2.2uF 20% 50V
(DE595)
C462 1-126-961-11 ELECT 2.2uF 20% 50V
(DE595)
C464 1-164-159-11 CERAMIC 0.1uF 50V
DISPLAY HEADPHONE MAIN
Ver 1.1
