Sony STR-DE845 - Printed Wiring Boards -AC;SP Boards

4040
STR-DE845/DE945
4-30. PRINTED WIRING BOARDS – AC/SP Boards –• See page 14 for Circuit Boards Location.
• Semiconductor
Location
Ref. No. Location
D901 B-1
D902 B-1
D903 B-1
D904 B-1
D905 B-1
D906 B-1
D907 C-1
Q901 C-1
(Page 38)
(Page 34)
(Page 38)
(Page 30)
(Page 30)
(Page 30)
