Pin No. Pin Name I/O Description
44
DOSEL0 O
Data select 0 output terminal (fixed at “L” in this set)
45
DOSEL1 O
Data select 1 output terminal (fixed at “L” in this set)
46
CKSEL0 I
System clock select 0 input terminal (fixed at “L” in this set)
47
CKSEL1 I
System clock select 1 input terminal (fixed at “L” in this set)
48
XMODE I
Reset signal input from the system controller (IC1201)
