Pin No. Pin Name I/O Description
107
DIG-INB O
Digital input select B control signal output to the select switch (IC1005)
108
DIG-INA O
Dgital input select A control signal output to the select switch (IC1005)
109
XMODE O
Reset signal output to the digital audio interface receiver (IC1101)
110
CL O
Clock signal output to the digital audio interface receiver (IC1101)
111
CE O
Chip enable signal output to the digital audio interface receiver (IC1101)
112
DI O
Data output to the digital audio interface receiver (IC1101)
113
DO I
Data input from the digital audio interface receiver (IC1101)
114
ERROR I
Error signal input from the digital audio interface receiver (IC1101)
115 to
111
NC I
Not used (fixed at “L”)
118
XSTATE I
Clock status flag signal input from the digital audio interface receiver (IC1101)
119
VSS —
Ground terminal
120
NC I
Not used (fixed at “L”)
