Sony STR-DE845 - Page 66

66
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
C102 1-164-222-11 CERAMIC CHIP 0.22uF 25V
C103 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C104 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C105 1-104-905-11 CAPACITOR 0.22F 5.5V
C106 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C107 1-126-786-11 ELECT 47uF 20% 16V
C108 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C109 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C110 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C111 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C113 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C114 1-126-967-11 ELECT 47uF 20% 50V
C115 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C116 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C117 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C118 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C120 1-104-664-11 ELECT 47uF 20% 16V
C121 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C122 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C124 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C125 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C152 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C153 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C154 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C155 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C158 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C159 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C160 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
CC11 1-165-319-11 CERAMIC CHIP 0.1uF 50V
(DE945)
CC12 1-165-319-11 CERAMIC CHIP 0.1uF 50V
(DE945)
CC13 1-165-319-11 CERAMIC CHIP 0.1uF 50V
(DE945)
CC14 1-136-153-00 FILM 0.01uF 5% 50V
(DE945)
CC15 1-136-153-00 FILM 0.01uF 5% 50V
(DE945)
CC16 1-126-916-11 ELECT 1000uF 20% 6.3V
(DE945)
< CONNECTOR >
CNP104 1-785-796-11 PIN, BOARD TO BOARD 5P
* CNP105 1-564-719-11 PIN, CONNECTOR (SMALL TYPE) 3P
CNP106 1-785-796-11 PIN, BOARD TO BOARD 5P
CNS102 1-568-850-11 CONNECTOR, FFC 7P (DE945)
CNS101 1-784-778-11 CONNECTOR, FFC 17P (E, AUS, CH, PX)
CNS101 1-784-782-11 CONNECTOR, FFC 21P (US, CND)
CNS103 1-770-397-11 HOUSING, CONNECTOR (PC BOARD) 4P
< DIODE >
D100 8-719-072-82 LED SELU5E20C-STP15
(MULTI CHANNEL DECODING)
D102 8-719-053-18 DIODE 1SR154-400TE-25
D103 8-719-016-74 DIODE 1SS352-TPH3
D104 8-719-075-59 LED SELS5B23CTP15
(DIGITAL CINEMA SOUND)
D105 8-719-313-45 LED SEL6810A-TH10 (EQUALIZER)
D106 8-719-313-45 LED SEL6810A-TH10 (BASS BOOST)
D107 8-719-016-74 DIODE 1SS352-TPH3
D108 8-719-016-74 DIODE 1SS352-TPH3 (DE945)
D114 8-719-016-74 DIODE 1SS352-TPH3 (E, PX)
D116 8-719-016-74 DIODE 1SS352-TPH3 (MY, SP, AUS, CH)
D118 8-719-016-74 DIODE 1SS352-TPH3
D119 8-719-046-39 LED SEL5821A-TP15 (LEVEL)
D122 8-719-046-39 LED SEL5821A-TP15 (SUR)
D123 8-719-046-39 LED SEL5821A-TP15 (EQ)
D124 8-719-046-39 LED SEL5821A-TP15 (-/+)
D151 8-719-046-39 LED SEL5821A-TP15 (NAME)
D152 8-719-046-39 LED SEL5821A-TP15 (SET UP)
D157 8-719-046-39 LED SEL5821A-TP15 (2CH)
D158 8-719-046-39 LED SEL5821A-TP15 (MODE)
D160 8-719-078-96 LED SEL5855ATP15 (TAPE)
D161 8-719-078-96 LED SEL5855ATP15 (MD/DAT)
D162 8-719-078-96 LED SEL5855ATP15 (CD)
D163 8-719-078-96 LED SEL5855ATP15 (TUNER)
D164 8-719-078-96 LED SEL5855ATP15 (DVD/LD)
D165 8-719-078-96 LED SEL5855ATP15 (VIDEO 3)
D166 8-719-078-96 LED SEL5855ATP15 (TV/SAT) (DE945)
D167 8-719-078-96 LED SEL5855ATP15 (VIDEO 1)
D168 8-719-078-96 LED SEL5855ATP15 (VIDEO 2)
D169 8-719-046-39 LED SEL5821A-TP15 (A.F.D)
D170 8-719-313-45 LED SEL6810A-TH10 (5.1CH INPUT) (DE945)
D171 8-719-078-96 LED SEL5855ATP15 (5.1CH INPUT) (DE845)
D172 8-719-078-96 LED SEL5855ATP15 (PHONO) (DE945)
D180 8-719-016-74 DIODE 1SS352-TPH3
DD11 8-719-016-74 DIODE 1SS352-TPH3 (DE945)
DD12 8-719-016-74 DIODE 1SS352-TPH3 (DE945)
DD13 8-719-016-74 DIODE 1SS352-TPH3 (DE945)
DD14 8-719-059-14 LED SID313BP-TP19 (SIRCS) (DE945)
DD15 8-719-075-86 LED SID307BRTP19 (SIRCS) (DE945)
DD16 8-719-075-86 LED SID307BRTP19 (SIRCS) (DE945)
< FLUORESCENT INDICATOR TUBE >
FL101 1-517-962-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC11 8-759-925-76 IC SN74HC08ANSR (DE945)
IC12 8-759-666-99 IC TMP87C447U-1F23 (DE945)
IC101 8-759-459-86 IC NJL64H400A ( )
IC102 8-759-666-30 IC MB90553ABPF-G-169-BND
IC103 8-759-679-75 IC ML9261MBZ060
IC105 8-759-589-67 IC BA6208F-E2
IC106 8-759-373-50 IC NJU3719L
< SHORT >
JW1 1-216-295-00 SHORT 0 (DE945)
< TRANSISTOR >
Q102 8-729-027-23 TRANSISTOR RT1P141C-TP-1
Q108 8-729-027-43 TRANSISTOR RT1N141C-TP-1
Q109 8-729-230-49 TRANSISTOR 2SC2712-YG-TE85L
QQ11 8-729-230-49 TRANSISTOR 2SC2712-YG-TE85L
(DE945)
QQ13 8-729-801-93 TRANSISTOR 2SD1387-34-TP (DE945)
QQ14 8-729-801-93 TRANSISTOR 2SD1387-34-TP (DE945)
