68
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
RR33 1-216-073-00 METAL CHIP 10K 5% 1/10W
(DE945)
RR34 1-216-073-00 METAL CHIP 10K 5% 1/10W
(DE945)
RR35 1-216-073-00 METAL CHIP 10K 5% 1/10W
(DE945)
RR36 1-216-049-11 RES-CHIP 1K 5% 1/10W
(DE945)
RR37 1-216-049-11 RES-CHIP 1K 5% 1/10W
(DE945)
RR51 1-216-029-00 METAL CHIP 150 5% 1/10W
RR52 1-216-029-00 METAL CHIP 150 5% 1/10W
RR53 1-216-029-00 METAL CHIP 150 5% 1/10W
RR54 1-216-037-00 METAL CHIP 330 5% 1/10W
RR61 1-216-029-00 METAL CHIP 150 5% 1/10W
RR62 1-216-029-00 METAL CHIP 150 5% 1/10W
RR63 1-216-029-00 METAL CHIP 150 5% 1/10W
RR74 1-216-037-00 METAL CHIP 330 5% 1/10W
RR75 1-216-029-00 METAL CHIP 150 5% 1/10W
RR76 1-216-029-00 METAL CHIP 150 5% 1/10W
< SWITCH >
S111 1-771-349-21 SWITCH, KEYBOARD (<)
S112 1-771-349-21 SWITCH, KEYBOARD (>)
S113 1-771-349-21 SWITCH, KEYBOARD (LEVEL)
S114 1-771-349-21 SWITCH, KEYBOARD (SUR)
S115 1-771-349-21 SWITCH, KEYBOARD (EQ)
S116 1-771-349-21 SWITCH, KEYBOARD (ENTER)
S117 1-771-349-21 SWITCH, KEYBOARD (NAME)
S118 1-771-349-21 SWITCH, KEYBOARD (SET UP)
S121 1-771-349-21 SWITCH, KEYBOARD (C)
S122 1-771-349-21 SWITCH, KEYBOARD (B)
S123 1-771-349-21 SWITCH, KEYBOARD (A)
S124 1-771-349-21 SWITCH, KEYBOARD (2CH)
S125 1-771-349-21 SWITCH, KEYBOARD (MODE)
S131 1-771-349-21 SWITCH, KEYBOARD (DVD/LD)
S132 1-771-349-21 SWITCH, KEYBOARD (VIDEO 3)
S133 1-771-349-21 SWITCH, KEYBOARD (CD)
S134 1-771-349-21 SWITCH, KEYBOARD (TUNER)
S135 1-771-349-21 SWITCH, KEYBOARD (A.F.D)
S136 1-771-349-21 SWITCH, KEYBOARD (PHONO) (DE945)
S137 1-771-349-21 SWITCH, KEYBOARD (TV/SAT) (DE945)
S141 1-771-349-21 SWITCH, KEYBOARD (MD/DAT)
S142 1-771-349-21 SWITCH, KEYBOARD (VIDEO 2)
S143 1-771-349-21 SWITCH, KEYBOARD (INPUT MODE)
S144 1-771-349-21 SWITCH, KEYBOARD (5.1CH INPUT) (DE945)
S145 1-771-349-21 SWITCH, KEYBOARD (DISPLAY)
S146 1-771-349-21 SWITCH, KEYBOARD (DIMMER)
S147 1-771-349-21 SWITCH, KEYBOARD (VUDEO 1)
S148 1-771-349-21 SWITCH, KEYBOARD (TAPE)
S149 1-771-349-21 SWITCH, KEYBOARD (5.1CH INPUT) (DE845)
< VIBRATOR >
X11 1-767-938-21 VIBRATOR, CERAMIC (7.28MHz) (DE945)
X101 1-781-356-21 VIBRATOR, CERAMIC (6MHz)
**************************************************************
1-677-002-11 H. P BOARD
**********
< CONNECTOR >
CNP751 1-779-978-11 PIN, CONNECTOR 3P
< TERMINAL >
* EB701 1-537-738-21 TERMINAL, EARTH
< JACK >
J701 1-750-735-11 JACK (LARGE TYPE) (PHONES)
**************************************************************
1-676-992-11 JOINT (1) (H) BOARD (DE845)
**************************
< CONNECTOR >
CNP211 1-695-089-11 PIN, CONNECTOR (PC BOARD) 11P
CNP212 1-695-089-11 PIN, CONNECTOR (PC BOARD) 11P
**************************************************************
A-4428-764-A MAIN BOARD, COMPLETE (DE845: US)
A-4428-793-A MAIN BOARD, COMPLETE (DE845: CND)
A-4428-794-A MAIN BOARD, COMPLETE (EXCEPT US, CND)
A-4428-813-A MAIN BOARD, COMPLETE (DE945: US)
A-4428-822-A MAIN BOARD, COMPLETE (DE945: CND)
*********************
7-685-872-09 SCREW +BVTT 3X8 (S)
< CAPACITOR >
C301 1-126-961-11 ELECT 2.2uF 20% 50V
C302 1-128-809-11 CERAMIC 100PF 5% 50V
(EXCEPT US, CND)
C303 1-126-934-11 ELECT 220uF 20% 10V
C304 1-125-896-91 MYLAR 0.0091uF 5% 50V
C305 1-136-159-00 MYLAR 0.033uF 5% 50V
C306 1-126-961-11 ELECT 2.2uF 20% 50V
C307 1-128-809-11 CERAMIC 100PF 5% 50V
(EXCEPT US, CND)
C308 1-128-813-11 CERAMIC 220PF 5% 50V
(EXCEPT US, CND)
C309 1-128-809-11 CERAMIC 100PF 5% 50V
(DE945)
C311 1-126-965-11 ELECT 22uF 20% 50V
C312 1-127-868-11 CERAMIC 2200PF 10% 50V
C313 1-127-868-11 CERAMIC 2200PF 10% 50V
C314 1-128-825-11 CERAMIC 2200PF 5% 50V
(DE945)
C315 1-127-868-11 CERAMIC 2200PF 10% 50V
C320 1-126-965-11 ELECT 22uF 20% 50V
(DE945)
C330 1-126-965-11 ELECT 22uF 20% 50V
(DE945)
C331 1-126-965-11 ELECT 22uF 20% 50V
C340 1-127-880-11 CERAMIC 0.022uF 10% 50V
(DE945)
C350 1-127-880-11 CERAMIC 0.022uF 10% 50V
(DE945)
C351 1-126-961-11 ELECT 2.2uF 20% 50V
DISPLAY H. P JOINT (1) (H) MAIN
