Sony STR-DE845 - Page 7

7
VIDEO/OSD/JOINT (1) (H)/OSD JOINT (H)/
S-VIDEO/DIGITAL BOARD
HEAT SINK
1 wire (flat type) (15 core
)
(CN51)
5 bracket (digital)
1 wire (flat type) (21 core)
(CN55)
4 DIGITAL board
8 VIDEO board (DE845)/OSD board (DE945),
JOINT (1) (H) board (DE845)/OSD JOINT (H) board (DE945)
S-VIDEO board
3 screw
(BVTP 3X8 )
2 three screws
(BVTP 3X8 )
7 seven screws
(BVTP 3X8 )
6 connector
(CNS213)
DE945
1 five connectors
(CNP511, 611, 561, 711, 761)
3 two screws
(BVTP 3X6)
4 screw
(BVTP 3X8 )
4 screw
(BVTP 3X8 )
2 ten screws
5 heat sink
