Sony STR-DE845 - Page 71

71
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
Q558 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q559 8-729-281-53 TRANSISTOR 2SC1815GR-TPE2
Q560 8-729-900-63 TRANSISTOR BN1F4M-TP
Q561 8-729-900-63 TRANSISTOR BN1F4M-TP
Q596 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
Q598 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q599 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q601 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
Q606 8-729-051-93 TRANSISTOR 2SB1647 (DE945)
Q606 8-749-010-26 IC MP1620-OPY-M (DE845)
Q607 8-729-051-92 TRANSISTOR 2SD2560 (DE945)
Q607 8-749-010-25 IC MN2488-OPY-M (DE845)
Q608 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q609 8-729-281-53 TRANSISTOR 2SC1815GR-TPE2
Q610 8-729-900-63 TRANSISTOR BN1F4M-TP
Q611 8-729-900-63 TRANSISTOR BN1F4M-TP
Q613 8-729-281-53 TRANSISTOR 2SC1815GR-TPE2
Q645 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
Q681 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
Q698 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q706 8-729-051-93 TRANSISTOR 2SB1647 (DE945)
Q706 8-749-010-26 IC MP1620-OPY-M (DE845)
Q707 8-729-051-92 TRANSISTOR 2SD2560 (DE945)
Q707 8-749-010-25 IC MN2488-OPY-M (DE845)
Q708 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q709 8-729-281-53 TRANSISTOR 2SC1815GR-TPE2
Q710 8-729-900-63 TRANSISTOR BN1F4M-TP
Q745 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
Q756 8-729-051-93 TRANSISTOR 2SB1647 (DE945)
Q756 8-749-010-26 IC MP1620-OPY-M (DE845)
Q757 8-729-051-92 TRANSISTOR 2SD2560 (DE945)
Q757 8-749-010-25 IC MN2488-OPY-M (DE845)
Q758 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q798 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q799 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
< RESISTOR >
R301 1-249-421-11 CARBON 2.2K 5% 1/4W
(EXCEPT US, CND)
R302 1-249-441-11 CARBON 100K 5% 1/4W
R303 1-249-440-11 CARBON 82K 5% 1/4W
R304 1-249-408-11 CARBON 180 5% 1/4W
R305 1-249-428-11 CARBON 8.2K 5% 1/4W
R306 1-249-441-11 CARBON 100K 5% 1/4W
R307 1-247-807-31 CARBON 100 5% 1/4W
R308 1-249-441-11 CARBON 100K 5% 1/4W
R309 1-249-413-11 CARBON 470 5% 1/4W
R310 1-249-417-11 CARBON 1K 5% 1/4W
R311 1-249-421-11 CARBON 2.2K 5% 1/4W
R312 1-249-417-11 CARBON 1K 5% 1/4W
R313 1-249-421-11 CARBON 2.2K 5% 1/4W
(DE945)
R314 1-249-417-11 CARBON 1K 5% 1/4W
(DE945)
0 R315 1-249-393-11 CARBON 10 5% 1/4W F
(DE945)
R316 1-249-421-11 CARBON 2.2K 5% 1/4W
R317 1-249-417-11 CARBON 1K 5% 1/4W
R318 1-249-421-11 CARBON 2.2K 5% 1/4W
R319 1-249-417-11 CARBON 1K 5% 1/4W
R320 1-249-417-11 CARBON 1K 5% 1/4W
R321 1-247-807-31 CARBON 100 5% 1/4W
(DE945)
R322 1-249-417-11 CARBON 1K 5% 1/4W
(DE945)
R326 1-249-417-11 CARBON 1K 5% 1/4W
R330 1-247-887-00 CARBON 220K 5% 1/4W
(DE945)
R331 1-247-887-00 CARBON 220K 5% 1/4W
R335 1-247-887-00 CARBON 220K 5% 1/4W
R336 1-249-429-11 CARBON 10K 5% 1/4W
(DE945)
R337 1-249-425-11 CARBON 4.7K 5% 1/4W
(DE945)
R338 1-249-441-11 CARBON 100K 5% 1/4W
(DE945)
R341 1-249-437-11 CARBON 47K 5% 1/4W
R342 1-249-425-11 CARBON 4.7K 5% 1/4W
(DE945)
R351 1-249-421-11 CARBON 2.2K 5% 1/4W
(EXCEPT US, CND)
R352 1-249-441-11 CARBON 100K 5% 1/4W
R353 1-249-440-11 CARBON 82K 5% 1/4W
R354 1-249-408-11 CARBON 180 5% 1/4W
R355 1-249-428-11 CARBON 8.2K 5% 1/4W
R356 1-249-441-11 CARBON 100K 5% 1/4W
R357 1-247-807-31 CARBON 100 5% 1/4W
R358 1-249-441-11 CARBON 100K 5% 1/4W
R359 1-249-413-11 CARBON 470 5% 1/4W
R360 1-249-417-11 CARBON 1K 5% 1/4W
R361 1-249-421-11 CARBON 2.2K 5% 1/4W
R362 1-249-417-11 CARBON 1K 5% 1/4W
R363 1-249-421-11 CARBON 2.2K 5% 1/4W
(DE945)
R364 1-249-417-11 CARBON 1K 5% 1/4W
(DE945)
R366 1-249-421-11 CARBON 2.2K 5% 1/4W
R367 1-249-417-11 CARBON 1K 5% 1/4W
R368 1-249-421-11 CARBON 2.2K 5% 1/4W
R369 1-249-417-11 CARBON 1K 5% 1/4W
R370 1-249-417-11 CARBON 1K 5% 1/4W
R371 1-247-807-31 CARBON 100 5% 1/4W
(DE945)
R376 1-249-417-11 CARBON 1K 5% 1/4W
R380 1-247-887-00 CARBON 220K 5% 1/4W
(DE945)
R381 1-247-887-00 CARBON 220K 5% 1/4W
R385 1-247-887-00 CARBON 220K 5% 1/4W
R388 1-249-441-11 CARBON 100K 5% 1/4W
(DE945)
R391 1-249-437-11 CARBON 47K 5% 1/4W
R392 1-249-425-11 CARBON 4.7K 5% 1/4W
(DE945)
R396 1-249-417-11 CARBON 1K 5% 1/4W
R398 1-249-417-11 CARBON 1K 5% 1/4W
R401 1-249-417-11 CARBON 1K 5% 1/4W
R402 1-249-417-11 CARBON 1K 5% 1/4W
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
MAIN
