Sony STR-DE845 - Page 73

73
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R655 1-249-439-11 CARBON 68K 5% 1/4W
R657 1-249-429-11 CARBON 10K 5% 1/4W
0 R658 1-249-393-11 CARBON 10 5% 1/4W F
R680 1-249-429-11 CARBON 10K 5% 1/4W
R681 1-249-425-11 CARBON 4.7K 5% 1/4W
0 R682 1-249-393-11 CARBON 10 5% 1/4W F
R690 1-249-433-11 CARBON 22K 5% 1/4W
R695 1-249-420-11 CARBON 1.8K 5% 1/4W
R696 1-249-431-11 CARBON 15K 5% 1/4W
R701 1-249-417-11 CARBON 1K 5% 1/4W
R702 1-249-439-11 CARBON 68K 5% 1/4W
R703 1-249-439-11 CARBON 68K 5% 1/4W
R704 1-249-418-11 CARBON 1.2K 5% 1/4W
R705 1-249-439-11 CARBON 68K 5% 1/4W
0 R724 1-249-405-11 CARBON 100 5% 1/4W F
0 R725 1-249-405-11 CARBON 100 5% 1/4W F
0 R726 1-234-182-11 ENCAPSULATED COMPONENT 0.22 5W F
0 R727 1-240-855-91 CARBON 6.2K 5% 1/4W F
R728 1-249-425-11 CARBON 4.7K 5% 1/4W
R729 1-247-866-11 CARBON 30K 5% 1/4W
R730 1-249-421-11 CARBON 2.2K 5% 1/4W
R731 1-249-433-11 CARBON 22K 5% 1/4W
R732 1-249-437-11 CARBON 47K 5% 1/4W
0 R733 1-249-393-11 CARBON 10 5% 1/4W F
R735 1-249-431-11 CARBON 15K 5% 1/4W
0 R739 1-215-868-00 METAL OXIDE 680 5% 1W F
R747 1-249-429-11 CARBON 10K 5% 1/4W
R748 1-249-425-11 CARBON 4.7K 5% 1/4W
0 R749 1-249-393-11 CARBON 10 5% 1/4W F
R751 1-249-417-11 CARBON 1K 5% 1/4W
R752 1-249-439-11 CARBON 68K 5% 1/4W
R753 1-249-439-11 CARBON 68K 5% 1/4W
R754 1-249-418-11 CARBON 1.2K 5% 1/4W
R755 1-249-439-11 CARBON 68K 5% 1/4W
0 R774 1-249-405-11 CARBON 100 5% 1/4W F
0 R775 1-249-405-11 CARBON 100 5% 1/4W F
0 R776 1-234-182-11 ENCAPSULATED COMPONENT 0.22 5W F
0 R777 1-240-855-91 CARBON 6.2K 5% 1/4W F
R778 1-249-425-11 CARBON 4.7K 5% 1/4W
R782 1-249-437-11 CARBON 47K 5% 1/4W
0 R783 1-249-393-11 CARBON 10 5% 1/4W F
0 R789 1-215-868-00 METAL OXIDE 680 5% 1W F
R790 1-249-433-11 CARBON 22K 5% 1/4W
R791 1-249-431-11 CARBON 15K 5% 1/4W
R795 1-249-420-11 CARBON 1.8K 5% 1/4W
R796 1-249-420-11 CARBON 1.8K 5% 1/4W
R799 1-249-431-11 CARBON 15K 5% 1/4W
< RELAY >
RY301 1-515-793-11 RELAY 24V (DE945)
RY501 1-515-920-11 RELAY (24V)
RY502 1-515-920-11 RELAY (24V)
RY601 1-515-920-11 RELAY (24V)
RY602 1-515-793-11 RELAY
RY681 1-515-793-11 RELAY
RY701 1-515-920-11 RELAY (24V)
**************************************************************
1-677-000-11 MUTING BOARD
*************
< CAPACITOR >
C112 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C119 1-165-319-11 CERAMIC CHIP 0.1uF 50V
< DIODE >
D101 8-719-046-39 LED SEL5821A-TP15 (MUTING)
< RESISTOR >
R152 1-216-037-00 METAL CHIP 330 5% 1/10W
R153 1-216-041-00 METAL CHIP 470 5% 1/10W
R154 1-216-045-00 METAL CHIP 680 5% 1/10W
R155 1-216-049-11 RES-CHIP 1K 5% 1/10W
R156 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R157 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
(DE945)
R162 1-216-037-00 METAL CHIP 330 5% 1/10W
R163 1-216-041-00 METAL CHIP 470 5% 1/10W
R164 1-216-045-00 METAL CHIP 680 5% 1/10W
R165 1-216-049-11 RES-CHIP 1K 5% 1/10W
RR55 1-216-037-00 METAL CHIP 330 5% 1/10W
< SWITCH >
S151 1-771-349-21 SWITCH, KEYBOARD (PRESET -)
S152 1-771-349-21 SWITCH, KEYBOARD (TUNING -)
S153 1-771-349-21 SWITCH, KEYBOARD (TUNING +)
S154 1-771-349-21 SWITCH, KEYBOARD (SHIFT)
S155 1-771-349-21 SWITCH, KEYBOARD (PRESET +)
S156 1-771-349-21 SWITCH, KEYBOARD (MEMORY)
S157 1-771-349-21 SWITCH, KEYBOARD (2ND AUDIO) (DE945)
S161 1-771-349-21 SWITCH, KEYBOARD (FM/AM)
S162 1-771-349-21 SWITCH, KEYBOARD (FM MODE)
S163 1-771-349-21 SWITCH, KEYBOARD (EQUALIZER)
S164 1-771-349-21 SWITCH, KEYBOARD (BASS BOOST)
S165 1-771-349-21 SWITCH, KEYBOARD (MUTING)
**************************************************************
A-4428-818-A OSD BOARD, COMPLETE (DE945)
********************
< CAPACITOR >
C2001 1-126-925-11 ELECT 470uF 20% 10V
C2002 1-126-925-11 ELECT 470uF 20% 10V
C2003 1-164-159-11 CERAMIC 0.1uF 50V
C2004 1-164-159-11 CERAMIC 0.1uF 50V
C2005 1-126-960-11 ELECT 1uF 20% 50V
C2006 1-104-664-11 ELECT 47uF 20% 16V
C2009 1-128-801-11 CERAMIC 22PF 5% 50V
C2010 1-164-159-11 CERAMIC 0.1uF 50V
C2011 1-162-198-31 CERAMIC 8.2PF 10% 50V
C2012 1-104-664-11 ELECT 47uF 20% 16V
C2013 1-164-159-11 CERAMIC 0.1uF 50V
C2014 1-162-199-31 CERAMIC 10PF 5% 50V
C2015 1-128-803-11 CERAMIC 33PF 5% 50V
C2016 1-128-809-11 CERAMIC 100PF 5% 50V
C2017 1-104-656-11 ELECT 2200uF 20% 6.3V
MAIN MUTING OSD
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
