75
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< VIBRATOR >
X2002 1-781-821-21 VIBRATOR, CRYSTAL (14MHz)
**************************************************************
1-677-042-11 OSD JOINT (H) BOARD (DE945)
******************
< CONNECTOR >
CNP211 1-695-091-11 PIN, CONNECTOR (PC BOARD) 15P
CNP212 1-695-096-11 SOCKET, CONNECTOR 15P
**************************************************************
1-676-999-11 POWER BOARD
*************
< DIODE >
D120 8-719-016-74 DIODE 1SS352-TPH3
D121 8-719-016-74 DIODE 1SS352-TPH3
< SWITCH >
S101 1-762-268-11 SWITCH, ROTARY (SPEAKERS)
S150 1-771-349-21 SWITCH, KEYBOARD (`/1)
**************************************************************
1-677-041-11 ROTARY BOARD
*************
< VARIABLE RESISTOR >
RV101 1-418-817-11 ENCODER (ROTARY) (-/+)
**************************************************************
1-676-991-11 SP BOARD
*********
< CAPACITOR >
CC41 1-128-809-11 CERAMIC 100PF 5% 50V
CC42 1-128-809-11 CERAMIC 100PF 5% 50V
CC43 1-128-809-11 CERAMIC 100PF 5% 50V
CC46 1-128-809-11 CERAMIC 100PF 5% 50V
CC47 1-128-809-11 CERAMIC 100PF 5% 50V
CC48 1-128-817-11 CERAMIC 470PF 5% 50V
(E, AUS, CH, PX)
CC49 1-128-817-11 CERAMIC 470PF 5% 50V
(E, AUS, CH, PX)
CC96 1-128-809-11 CERAMIC 100PF 5% 50V
CC97 1-128-809-11 CERAMIC 100PF 5% 50V
CC98 1-128-817-11 CERAMIC 470PF 5% 50V
(E, AUS, CH, PX)
CC99 1-128-817-11 CERAMIC 470PF 5% 50V
(E, AUS, CH, PX)
< JACK >
JJ103 1-774-819-11 JACK, PIN 2P (SUB WOOFER)
< COIL >
L601 1-420-872-00 COIL, AIR-CORE
L701 1-420-872-00 COIL, AIR-CORE
L751 1-420-872-00 COIL, AIR-CORE
< RESISTOR >
0 R634 1-249-389-11 CARBON 4.7 5% 1/4W F
0 R734 1-249-389-11 CARBON 4.7 5% 1/4W F
0 R784 1-249-389-11 CARBON 4.7 5% 1/4W F
RR48 1-249-393-11 CARBON 10 5% 1/4W
(E, AUS, CH, PX)
RR49 1-249-393-11 CARBON 10 5% 1/4W
(E, AUS, CH, PX)
RR98 1-249-393-11 CARBON 10 5% 1/4W
(E, AUS, CH, PX)
RR99 1-249-393-11 CARBON 10 5% 1/4W
(E, AUS, CH, PX)
RR251 1-249-417-11 CARBON 1K 5% 1/4W
< TERMINAL >
* TM501 1-694-454-21 TERMINAL BOARD (SP) (FRONT SPEAKERS)
TM701 1-694-528-11 TERMINAL BOARD (SPEAKER) 6P
(REAR/CENTER SPEAKERS)
**************************************************************
A-4428-783-A S-VIDEO BOARD, COMPLETE
(DE845: US, CND)
A-4428-817-A S-VIDEO BOARD, COMPLETE (DE945)
*************************
< CAPACITOR >
C252 1-136-165-00 MYLAR 0.1uF 5% 50V
C253 1-126-964-11 ELECT 10uF 20% 50V
C255 1-136-165-00 MYLAR 0.1uF 5% 50V
C256 1-126-964-11 ELECT 10uF 20% 50V
C257 1-136-165-00 MYLAR 0.1uF 5% 50V
C258 1-126-964-11 ELECT 10uF 20% 50V
C259 1-126-964-11 ELECT 10uF 20% 50V
C260 1-136-165-00 MYLAR 0.1uF 5% 50V
C262 1-164-159-11 CERAMIC 0.1uF 50V
C263 1-164-159-11 CERAMIC 0.1uF 50V
C265 1-164-159-11 CERAMIC 0.1uF 50V
C266 1-164-159-11 CERAMIC 0.1uF 50V
C267 1-128-805-11 CERAMIC 47PF 5% 50V
C268 1-128-805-11 CERAMIC 47PF 5% 50V
C269 1-128-805-11 CERAMIC 47PF 5% 50V
C270 1-128-805-11 CERAMIC 47PF 5% 50V
C271 1-104-664-11 ELECT 47uF 20% 16V
C272 1-128-817-11 CERAMIC 470PF 5% 50V
C273 1-128-825-11 CERAMIC 2200PF 5% 50V
C274 1-128-825-11 CERAMIC 2200PF 5% 50V
C275 1-128-825-11 CERAMIC 2200PF 5% 50V
C276 1-128-817-11 CERAMIC 470PF 5% 50V
< CONNECTOR >
CNS211 1-695-094-11 SOCKET, CONNECTOR 11P (DE845: US, CND)
CNS211 1-695-096-11 SOCKET, CONNECTOR 15P (DE945)
CNS213 1-564-718-11 PIN, CONNECTOR (SMALL TYPE) 2P (DE945)
CNS215 1-784-776-11 CONNECTOR, FFC 15P
< DIODE >
D204 8-719-911-19 DIODE 1SS133T-72
D205 8-719-911-19 DIODE 1SS133T-72
OSD OSD JOINT (H) POWER ROTARY SP S-VIDEO
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
