77
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
1-677-004-11 V. SWITCH BOARD (E, PX)
***************
1-533-217-31 HOLDER, FUSE
< CONNECTOR >
CNV903 1-568-106-11 PIN, CONNECTOR 4P
< FUSE >
0 F904 1-532-504-51 FUSE T4AL 250V
< SWITCH >
0 VS901 1-571-437-21 SWITCH, POWER VOLTAGE CHANGE
(VOLTAGE SELECTOR)
**************************************************************
1-677-001-11 VOL BOARD
**********
< CONNECTOR >
CNP101 1-770-388-11 PIN, CONNECTOR (PC BOARD) 4P
CNS111 1-784-784-11 CONNECTOR, FFC 23P
< LEAD >
* CP101 1-690-880-31 LEAD (WITH CONNECTOR)
< VARIABLE RESISTOR >
RV401 1-225-446-12 RES, VAR, CARBON 100K/100KX5
(MASTER VOLUME)
************************************************************
MISCELLANEOUS
**************
5 1-773-054-11 WIRE (FLAT TYPE) (17 CORE)
(E, AUS, CH, PX)
5 1-773-160-11 WIRE (FLAT TYPE) (21 CORE) (US, CND)
7 1-769-888-11 WIRE (FLAT TYPE) (7 CORE) (DE945)
* 9 1-690-880-31 LEAD (WITH CONNECTOR)
55 1-773-150-11 WIRE (FLAT TYPE) (21 CORE)
0 57 1-696-847-11 CORD, POWER (AUS)
0 57 1-769-743-11 CORD, POWER (CND)
0 57 1-769-744-11 CORD, POWER (E, PX)
0 57 1-782-464-21 CORD, POWER (CH)
0 57 1-783-820-11 CORD, POWER (US)
0 61 1-569-008-21 ADAPTOR, CONVERSION 2P (E, PX)
62 1-773-004-11 WIRE (FLAT TYPE) (15 CORE)
64 1-773-001-11 WIRE (FLAT TYPE) (15 CORE)
117 1-773-182-11 WIRE (FLAT TYPE) (23 CORE)
* 120 1-537-738-21 TERMINAL, EARTH
Q506 8-729-051-93 TRANSISTOR 2SB1647 (DE945)
Q506 8-749-010-26 IC MP1620-OPY-M (DE845)
Q507 8-729-051-92 TRANSISTOR 2SD2560 (DE945)
Q507 8-749-010-25 IC MN2488-OPY-M (DE845)
Q556 8-729-051-93 TRANSISTOR 2SB1647 (DE945)
Q556 8-749-010-26 IC MP1620-OPY-M (DE845)
Q557 8-729-051-92 TRANSISTOR 2SD2560 (DE945)
Q557 8-749-010-25 IC MN2488-OPY-M (DE845)
Q606 8-729-051-93 TRANSISTOR 2SB1647 (DE945)
Q606 8-749-010-26 IC MP1620-OPY-M (DE845)
Q607 8-729-051-92 TRANSISTOR 2SD2560 (DE945)
Q607 8-749-010-25 IC MN2488-OPY-M (DE845)
Q706 8-729-051-93 TRANSISTOR 2SB1647 (DE945)
Q706 8-749-010-26 IC MP1620-OPY-M (DE845)
Q707 8-729-051-92 TRANSISTOR 2SD2560 (DE945)
Q707 8-749-010-25 IC MN2488-OPY-M (DE845)
Q756 8-729-051-93 TRANSISTOR 2SB1647 (DE945)
Q756 8-749-010-26 IC MP1620-OPY-M (DE845)
Q757 8-729-051-92 TRANSISTOR 2SD2560 (DE945)
Q757 8-749-010-25 IC MN2488-OPY-M (DE845)
0 T901 1-435-428-11 TRANSFORMER, POWER (E, PX)
0 T901 1-435-429-11 TRANSFORMER, POWER (AUS)
0 T901 1-435-430-11 TRANSFORMER, POWER (US)
0 T901 1-435-431-11 TRANSFORMER, POWER (CND)
0 T901 1-435-432-11 TRANSFORMER, POWER (MY, SP, CH)
TM301 1-693-407-23 TUNER (DE845: US, CND, E/DE945)
TM301 1-693-409-23 TUNER (MY, SP, AUS, CH)
************************************************************
ACCESSORIES & PACKING MATERIALS
*******************************
1-418-866-11 REMOTE COMMANDER RM-LJ304 (DE945)
1-418-875-11 REMOTE COMMANDER RM-LP204 (DE845)
4-210-990-01 LID, BATTERY CASE
1-501-594-11 ANTENNA (FM) (DE845: US, MY, SP, AUS, CH)
1-501-721-11 ANTENNA (LOOP)
0 1-776-258-11 CORD, AVC CONNECTION (DE845: CND/945)
0 1-777-172-11 CORD, CONNECTION (DE845: CND/DE945)
0 1-777-560-11 CORD, CONNECTION (DE845: CND/DE945)
0 1-793-184-21 CONNECTOR (F TYPE ADAPTOR)
(DE845: CND, E/DE945)
3-866-670-11 MANUAL, COMMONNESS INSTRUCTION
(ENGLISH) (DE845: US, AUS/DE945: US)
3-866-670-21 MANUAL, COMMONNESS INSTRUCTION
(ENGLISH, FRENCH, GERMAN, SPANISH,
DUTCH, PORTUGUESE, SWEDISH, ITALIAN,
CHINESE) (DE845: CND, E/DE945: CND)
3-866-670-41 MANUAL, COMMONNESS INSTRUCTION
(ENGLISH, ALABIC, CHINESE) (CH)
4-227-952-11 MANUAL, INSTRUCTION (ENGLISH) (DE945)
4-227-952-21 MANUAL, INSTRUCTION (FRENCH, SPANISH)
(DE945: CND)
4-227-953-11 MANUAL, INSTRUCTION (ENGLISH) (DE845)
4-227-953-21 MANUAL, INSTRUCTION (FRENCH, SPANISH)
(DE845: CND, E)
4-227-953-31 MANUAL, INSTRUCTION (CHINESE) (E, CH)
4-229-126-11 MANUAL, INSTRUCTION (ENGLISH)
(DE845: US, CND, E, AUS, CH/DE945)
4-229-126-21 MANUAL, INSTRUCTION (FRENCH)
(DE845: CND, E/DE945: CND)
4-229-126-31 MANUAL, INSTRUCTION (SPANISH, ITALIAN)
(E)
4-229-126-41 MANUAL, INSTRUCTION (CHINESE) (CH)
************************************************************
V. SWITCH VOL
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
