68
STR-DG910
IC3511 SII9011CLU (HDMI RX) (HDMI RE BOARD (1/4))
Pin No. Pin Name I/O Pin Description
1 VSYNC O Vertical synchronize signal output for HDMI TX.
2 to 5 QO23 to QO20 — Not used. (Open)
6 IOGND — Ground
7IOVCC — Power supply terminal (+3.3 V)
8 to 11 QO19 to QO16 — Not used. (Open)
12 CVCC18 — Power supply terminal (+1.8 V)
13 CGND — Ground
14 to 17 QO15 to QO12 — Not used. (Open)
18 IOGND — Ground
19 IOVCC — Power supply terminal (+3.3 V)
20 to 23 QO11 to QO8 — Not used. (Open)
24 CVCC18 — Power supply terminal (+1.8 V)
25 CGND — Ground
26 to 29 QO7 to QO4 — Not used. (Open)
30 IOGND — Ground
31 IOVCC — Power supply terminal (+3.3 V)
32 to 35 QO3 to QO0 — Not used. (Open)
36 CVCC18 — Power supply terminal (+1.8 V)
37 CGND — Ground
38 CI2CA — Not used. (Fixed at L)
39 CSDA I/O I2C two-way data bus with HDMI section.
40 CSCL I I2C clock signal input from HDMI controller.
41 DSDA I/O I2C two-way data bus with HDMI input select.
42 DSDL I I2C clock signal input from HDMI input select.
43 NC — Not used. (Open)
44 PWR5V I HDMI DVD IN, VIDEO 2/BD IN, OUT connector detect signal input
45 CVCC18 — Power supply terminal (+1.8 V)
46 PGND — Ground
47 PVCC — Power supply terminal (+3.3 V)
48 RSVD — Not used. (Open)
49 AVCC — Power supply terminal (+3.3 V)
50 RXC– I TMDS clock signal input from HDMI DVD IN, VIDEO 2/BD IN, OUT connector.
51 RXC+ I TMDS clock signal input from HDMI DVD IN, VIDEO 2/BD IN, OUT connector.
52 AGND — Ground
53 AVCC — Power supply terminal (+3.3 V)
54 RX0– I TMDS data input 0 from HDMI DVD IN, VIDEO 2/BD IN, OUT connector.
55 RX0+ I TMDS data input 0 from HDMI DVD IN, VIDEO 2/BD IN, OUT connector.
56 AGND — Ground
57 AVCC — Power supply terminal (+3.3 V)
58 RX1– I TMDS data input 1 from HDMI DVD IN, VIDEO 2/BD IN, OUT connector.
59 RX1+ I TMDS data input 1 from HDMI DVD IN, VIDEO 2/BD IN, OUT connector.
60 AGND — Ground
61 AVCC — Power supply terminal (+3.3 V)
62 RX2– I TMDS data input 2 from HDMI DVD IN, VIDEO 2/BD IN, OUT connector.
63 RX2+ I TMDS data input 2 from HDMI DVD IN, VIDEO 2/BD IN, OUT connector.
64 AGND — Ground
65 DGND — Ground
66 DVCC18 — Power supply terminal (+1.8 V)
67 MUTE O Audio muting signal output
68 IOVCC — Power supply terminal (+3.3 V)
69 IOGND — Ground
70 SPDIF O SPDIF signal output for digital audio interface and HDMI TX.
