50
STR-DK5
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< CONNECTOR >
CN2506 1-820-048-11 CONNECTOR (LIGHTING) 5P
(D-LIGHT SYNC OUTPUT)
CNP200 1-784-925-11 PIN, CONNECTOR 10P
CNP551 1-779-799-11 PIN, CONNECTOR 9P
CNS553 1-568-826-11 CONNECTOR, FFC 7P
< DIODE >
D2350 8-719-947-16 DIODE MTZJ-T-72-5.1A
D2400 8-719-991-33 DIODE 1SS133T-77
< IC >
IC2300 6-709-162-01 IC M65851FP
IC2301 8-759-243-51 IC TC74ACT08P
IC2302 8-759-701-59 IC NJM78M09FA
IC2303 6-703-547-01 IC TA7805LS
IC2350 8-759-636-74 IC M5218AP-22
IC2351 8-759-636-74 IC M5218AP-22
< JACK >
J400 1-770-272-11 JACK, PIN 2P (MIC OUTPUT)
< TRANSISTOR >
Q2000 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q2350 8-729-281-53 TRANSISTOR 2SC1815-GR
< RESISTOR >
R400 1-247-831-11 CARBON 1K 5% 1/4W
R450 1-247-831-11 CARBON 1K 5% 1/4W
R1210 1-249-421-11 CARBON 2.2K 5% 1/4W
R1211 1-249-421-11 CARBON 2.2K 5% 1/4W
R2300 1-249-431-11 CARBON 15K 5% 1/4W
R2301 1-249-424-11 CARBON 3.9K 5% 1/4W
R2302 1-249-434-11 CARBON 27K 5% 1/4W
R2303 1-249-426-11 CARBON 5.6K 5% 1/4W
R2304 1-249-429-11 CARBON 10K 5% 1/4W
R2305 1-247-847-11 CARBON 4.7K 5% 1/4W
R2306 1-249-429-11 CARBON 10K 5% 1/4W
R2307 1-249-431-11 CARBON 15K 5% 1/4W
R2308 1-249-429-11 CARBON 10K 5% 1/4W
R2309 1-247-831-11 CARBON 1K 5% 1/4W
R2310 1-247-807-31 CARBON 100 5% 1/4W
R2311 1-247-807-31 CARBON 100 5% 1/4W
R2312 1-247-807-31 CARBON 100 5% 1/4W
R2345 1-249-429-11 CARBON 10K 5% 1/4W
R2346 1-247-871-11 CARBON 47K 5% 1/4W
R2347 1-249-429-11 CARBON 10K 5% 1/4W
R2348 1-249-429-11 CARBON 10K 5% 1/4W
R2349 1-249-429-11 CARBON 10K 5% 1/4W
R2350 1-247-871-11 CARBON 47K 5% 1/4W
R2351 1-247-871-11 CARBON 47K 5% 1/4W
R2352 1-247-863-11 CARBON 22K 5% 1/4W
R2353 1-247-863-11 CARBON 22K 5% 1/4W
R2354 1-249-421-11 CARBON 2.2K 5% 1/4W
R2355 1-249-429-11 CARBON 10K 5% 1/4W
R2357 1-249-429-11 CARBON 10K 5% 1/4W
R2358 1-249-429-11 CARBON 10K 5% 1/4W
R2359 1-249-429-11 CARBON 10K 5% 1/4W
R2360 1-247-831-11 CARBON 1K 5% 1/4W
R2368 1-247-871-11 CARBON 47K 5% 1/4W
R2370 1-249-429-11 CARBON 10K 5% 1/4W
R2371 1-249-429-11 CARBON 10K 5% 1/4W
R2372 1-249-429-11 CARBON 10K 5% 1/4W
R2373 1-249-429-11 CARBON 10K 5% 1/4W
R2378 1-247-847-11 CARBON 4.7K 5% 1/4W
R2379 1-249-429-11 CARBON 10K 5% 1/4W
R2400 1-249-421-11 CARBON 2.2K 5% 1/4W
R2402 1-249-401-11 CARBON 47 5% 1/4W F
R2506 1-249-393-11 CARBON 10 5% 1/4W F
< RELAY >
RY2000 1-515-614-11 RELAY
*************************************************************
A-1148-070-A MAIN BOARD, COMPLETE (EXCEPT RU)
A-1192-325-A MAIN BOARD, COMPLETE (RU)
*********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C400 1-127-888-11 CERAMIC 0.1uF 10% 50V
C402 1-124-261-00 ELECT 10uF 20% 50V
C403 1-128-813-11 CERAMIC 220PF 5% 50V
C404 1-128-813-11 CERAMIC 220PF 5% 50V
C421 1-126-963-11 ELECT 4.7uF 20% 50V
C422 1-126-963-11 ELECT 4.7uF 20% 50V
C423 1-126-963-11 ELECT 4.7uF 20% 50V
C424 1-126-963-11 ELECT 4.7uF 20% 50V
C425 1-126-963-11 ELECT 4.7uF 20% 50V
C426 1-126-963-11 ELECT 4.7uF 20% 50V
C431 1-126-961-11 ELECT 2.2uF 20% 50V
C432 1-126-961-11 ELECT 2.2uF 20% 50V
C433 1-126-961-11 ELECT 2.2uF 20% 50V
C434 1-126-961-11 ELECT 2.2uF 20% 50V
C435 1-126-961-11 ELECT 2.2uF 20% 50V
C436 1-126-961-11 ELECT 2.2uF 20% 50V
C446 1-126-963-11 ELECT 4.7uF 20% 50V
C452 1-124-261-00 ELECT 10uF 20% 50V
C471 1-104-658-11 ELECT 100uF 20% 10V
C472 1-127-888-11 CERAMIC 0.1uF 10% 50V
C481 1-126-964-11 ELECT 10uF 20% 50V
C482 1-127-888-11 CERAMIC 0.1uF 10% 50V
C483 1-126-934-11 ELECT 220uF 20% 16V
C484 1-127-888-11 CERAMIC 0.1uF 10% 50V
C500 1-128-579-11 ELECT 2.2uF 20% 100V
C501 1-126-963-11 ELECT 4.7uF 20% 50V
C502 1-128-809-11 CERAMIC 100PF 5% 50V
C503 1-128-809-11 CERAMIC 100PF 5% 50V
C504 1-102-233-00 CERAMIC 33PF 10% 500V
C506 1-107-583-11 CERAMIC 3PF 0.25PF 500V
C507 1-104-658-11 ELECT 100uF 20% 10V
C508 1-126-947-11 ELECT 47uF 20% 35V
C511 1-162-815-11 CERAMIC 47PF 5% 500V
C512 1-162-815-11 CERAMIC 47PF 5% 500V
C513 1-128-813-11 CERAMIC 220PF 5% 50V
MAINKARAOKE
Ver. 1.1
