Sony STR-DK5 - Page 54

54
STR-DK5
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R803 1-249-389-11 CARBON 4.7 5% 1/4W F
R804 1-249-429-11 CARBON 10K 5% 1/4W
R806 1-247-863-11 CARBON 22K 5% 1/4W
R815 1-249-381-11 CARBON 1 5% 1/4W F
R816 1-249-381-11 CARBON 1 5% 1/4W F
R840 1-249-427-11 CARBON 6.8K 5% 1/4W
(RU)
R844 1-247-863-11 CARBON 22K 5% 1/4W
R851 1-249-429-11 CARBON 10K 5% 1/4W
R852 1-249-429-11 CARBON 10K 5% 1/4W
R853 1-249-429-11 CARBON 10K 5% 1/4W
R854 1-249-435-11 CARBON 33K 5% 1/4W
R855 1-247-887-00 CARBON 220K 5% 1/4W
R856 1-247-895-00 CARBON 470K 5% 1/4W
R857 1-249-429-11 CARBON 10K 5% 1/4W
0R858 1-216-453-00 METAL OXIDE 270 5% 2W F
0R859 1-215-888-00 METAL OXIDE 220 5% 2W F
R881 1-247-871-11 CARBON 47K 5% 1/4W
R882 1-249-429-11 CARBON 10K 5% 1/4W
R883 1-249-427-11 CARBON 6.8K 5% 1/4W
R884 1-249-436-11 CARBON 39K 5% 1/4W
R885 1-247-831-11 CARBON 1K 5% 1/4W
0R910 1-243-635-11 FUSIBLE 0.33 5% 1/2W F
RR11 1-249-393-11 CARBON 10 5% 1/4W F
(RU)
RR12 1-249-393-11 CARBON 10 5% 1/4W F
(RU)
< RELAY >
RY501 1-755-416-12 RELAY
RY601 1-755-416-12 RELAY
RY701 1-755-416-12 RELAY
RY702 1-755-267-11 RELAY
< TERMINAL BOARD >
TM600 1-694-805-11 TERMINAL BOARD (2P) (SPEAKERS
CENTER,FRONT)
TM602 1-694-785-11 TERMINAL BOARD (2P) (SPEAKERS
SURROUND)
*************************************************************
A-1148-080-A MIC AMP BOARD, COMPLETE
************************
< CAPACITOR >
C2000 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C2001 1-124-257-00 ELECT 2.2uF 20% 50V
C2002 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C2003 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C2004 1-124-464-11 ELECT 0.22uF 20% 50V
C2005 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C2006 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C2007 1-124-463-00 ELECT 0.1uF 20% 50V
C2008 1-164-217-11 CERAMIC CHIP 150PF 5% 50V
C2026 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C2027 1-124-584-00 ELECT 100uF 20% 10V
C2030 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C2031 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C2032 1-124-261-00 ELECT 10uF 20% 25V
C2050 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C2051 1-124-257-00 ELECT 2.2uF 20% 50V
C2052 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C2053 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C2054 1-124-464-11 ELECT 0.22uF 20% 50V
C2055 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C2056 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C2057 1-124-463-00 ELECT 0.1uF 20% 50V
C2058 1-164-217-11 CERAMIC CHIP 150PF 5% 50V
C2095 1-162-974-11 CERAMIC CHIP 0.01uF 50V
< CONNECTOR >
CNP100 1-784-922-11 PIN, CONNECTOR 5P
< IC >
IC2001 8-759-710-97 IC NJM4565M-D
IC2002 8-759-710-97 IC NJM4565M-D
< JACK >
J2000 1-815-313-21 JACK (MIC 1 (KARAOKE))
J2050 1-815-313-21 JACK (MIC 2 (KARAOKE))
< RESISTOR >
R2000 1-216-864-11 SHORT CHIP 0
R2001 1-216-845-11 METAL CHIP 100K 5% 1/10W
R2002 1-216-821-11 METAL CHIP 1K 5% 1/10W
R2003 1-216-845-11 METAL CHIP 100K 5% 1/10W
R2004 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2005 1-216-837-11 METAL CHIP 22K 5% 1/10W
R2006 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2007 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2016 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R2017 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R2050 1-216-864-11 SHORT CHIP 0
R2051 1-216-845-11 METAL CHIP 100K 5% 1/10W
R2052 1-216-821-11 METAL CHIP 1K 5% 1/10W
R2053 1-216-845-11 METAL CHIP 100K 5% 1/10W
R2054 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2055 1-216-837-11 METAL CHIP 22K 5% 1/10W
R2056 1-216-833-11 METAL CHIP 10K 5% 1/10W
R2057 1-216-833-11 METAL CHIP 10K 5% 1/10W
*************************************************************
A-1148-079-A MIC TONE BOARD, COMPLETE
*************************
< CAPACITOR >
C2009 1-124-257-00 ELECT 2.2uF 20% 50V
C2010 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C2011 1-124-257-00 ELECT 2.2uF 20% 50V
C2012 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C2013 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C2014 1-164-217-11 CERAMIC CHIP 150PF 5% 50V
C2015 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C2016 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C2017 1-124-257-00 ELECT 2.2uF 20% 50V
C2018 1-124-257-00 ELECT 2.2uF 20% 50V
C2019 1-124-257-00 ELECT 2.2uF 20% 50V
C2020 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
MIC AMP MIC TONE
Ver. 1.1
MAIN
