56
STR-DK5
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
S105 1-771-410-21 SWITCH, TACTILE (VOCAL SELECT (KARAOKE))
S106 1-771-410-21 SWITCH, TACTILE (KARAOKE ON/OFF
(KARAOKE))
*************************************************************
STANDBY BOARD
***************
1-533-217-41 HOLDER, FUSE
< CAPACITOR >
C901 1-135-798-11 CERAMIC 0.22uF 50V
C902 1-135-798-11 CERAMIC 0.22uF 50V
C911 1-135-798-11 CERAMIC 0.22uF 50V
C912 1-135-798-11 CERAMIC 0.22uF 50V
C913 1-126-959-11 ELECT 0.47uF 20% 50V
C914 1-126-936-11 ELECT 3300uF 20% 16V
C915 1-126-943-11 ELECT 2200uF 20% 25V
C916 1-126-942-61 ELECT 1000uF 20% 25V
< CONNECTOR >
CNP801 1-784-922-11 PIN, CONNECTOR 5P
CNP900 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
CNP903 1-564-506-11 PLUG, CONNECTOR 3P
CNP904 1-794-577-21 PIN, CONNECTOR (POWER) 2P
CNP906 1-766-203-11 PLUG, CONNECTOR PIN (PC BOARD) 5P
< DIODE >
D901 8-719-991-33 DIODE 1SS133T-77
D910 6-500-522-11 DIODE 10EDB40-TA2B5
D911 6-500-522-11 DIODE 10EDB40-TA2B5
D912 6-500-522-11 DIODE 10EDB40-TA2B5
D913 6-500-522-11 DIODE 10EDB40-TA2B5
D914 8-719-991-33 DIODE 1SS133T-77
D915 8-719-991-33 DIODE 1SS133T-77
D920 6-500-522-11 DIODE 10EDB40-TA2B5
D921 6-500-522-11 DIODE 10EDB40-TA2B5
D922 6-500-522-11 DIODE 10EDB40-TA2B5
D923 6-500-522-11 DIODE 10EDB40-TA2B5
< TRANSISTOR >
Q901 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q911 8-729-119-78 TRANSISTOR 2SC2785-HFE
< RESISTOR >
0R810 1-243-634-11 FUSIBLE 0.22 5% 1/2W F
0R812 1-243-634-11 FUSIBLE 0.22 5% 1/2W F
R903 1-247-871-11 CARBON 47K 5% 1/4W
R904 1-247-847-11 CARBON 4.7K 5% 1/4W
R905 1-249-381-11 CARBON 1 5% 1/4W F
R911 1-247-871-11 CARBON 47K 5% 1/4W
R912 1-249-435-11 CARBON 33K 5% 1/4W
R913 1-249-429-11 CARBON 10K 5% 1/4W
< RELAY >
0RY901 1-755-541-11 RELAY
< TRANSFORMER >
0 T902 1-443-517-11 TRANSFORMER, POWER (SUB)
*************************************************************
VOLUME BOARD
**************
< CONNECTOR >
* CN105 1-564-518-11 PLUG, CONNECTOR 3P
< ROTARY ENCODER >
RV102 1-418-725-41 ENCODER, ROTARY (12 TYPE)
(MASTER VOLUME)
*************************************************************
MISCELLANEOUS
***************
63 1-829-025-11 WIRE (FLAT TYPE) (23 CORE)
102 1-828-945-11 WIRE (FLAT TYPE) (7 CORE)
103 1-828-963-11 WIRE (FLAT TYPE) (11 CORE) (EXCEPT RU)
103 1-828-980-11 WIRE (FLAT TYPE) (15 CORE) (RU)
0 106 1-777-071-83 CORD, POWER
0 F901 1-532-464-33 FUSE (T2.5AL/250V)
Q503 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q504 6-702-391-01 TRANSISTOR MP1620-OPY-MK
Q553 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q554 6-702-391-01 TRANSISTOR MP1620-OPY-MK
Q603 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q604 6-702-391-01 TRANSISTOR MP1620-OPY-MK
Q653 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q654 6-702-391-01 TRANSISTOR MP1620-OPY-MK
Q703 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q704 6-702-391-01 TRANSISTOR MP1620-OPY-MK
0 T901 1-443-914-11 TRANSFORMER, POWER (MAIN)
TN1 1-693-676-11 TUNER (FM/AM) (ANTENNA) (RU)
TN1 1-693-678-11 TUNER (FM/AM) (ANTENNA) (EXCEPT RU)
*************************************************************
ACCESSORIES
************
1-479-148-11 COMMANDER, STANDARD (RM-AAU002)
(including BATTERY CASE LID)
1-501-374-12 ANTENNA, LOOP (AM)
1-501-807-12 ANTENNA (FM)
2-656-285-11 MANUAL, INSTRUCTION (ENGLISH)
2-656-285-21 MANUAL, INSTRUCTION (FRENCH) (SP,MY,TH)
2-656-285-31 MANUAL, INSTRUCTION (SPANISH)
(SP,MY,TH)
2-656-285-41 MANUAL, INSTRUCTION
(TRADITIONAL CHINESE)
(SP,MY,TH)
2-656-285-51 MANUAL, INSTRUCTION (MALAY) (SP,MY)
2-656-285-61 MANUAL, INSTRUCTION (RUSSIAN) (RU)
STANDBY VOLUME
Ver. 1.1
MIC TONE
