Sony STR-K650P - Electrical Parts List: Main Board Components

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
33
STR-K650P
DISPLAY
R115 1-249-429-11 CARBON 10K 5% 1/4W
R118 1-249-433-11 CARBON 22K 5% 1/4W
R121 1-249-417-11 CARBON 1K 5% 1/4W F
R122 1-249-421-11 CARBON 2.2K 5% 1/4W F
R123 1-249-421-11 CARBON 2.2K 5% 1/4W F
R124 1-249-425-11 CARBON 4.7K 5% 1/4W F
R125 1-249-429-11 CARBON 10K 5% 1/4W
R131 1-249-417-11 CARBON 1K 5% 1/4W F
R132 1-249-421-11 CARBON 2.2K 5% 1/4W F
R133 1-249-421-11 CARBON 2.2K 5% 1/4W F
R134 1-249-425-11 CARBON 4.7K 5% 1/4W F
R135 1-249-429-11 CARBON 10K 5% 1/4W
R136 1-249-433-11 CARBON 22K 5% 1/4W
R150 1-249-440-11 CARBON 82K 5% 1/4W
R153 1-247-807-31 CARBON 100 5% 1/4W
0 R154 1-249-393-11 CARBON 10 5% 1/4W F
R155 1-249-441-11 CARBON 100K 5% 1/4W
R161 1-249-409-11 CARBON 220 5% 1/4W F
0 R175 1-249-393-11 CARBON 10 5% 1/4W F
0 R198 1-249-381-11 CARBON 1 5% 1/4W F
0 R199 1-249-381-11 CARBON 1 5% 1/4W F
< SWITCH >
S100 1-771-410-21 SWITCH, TACTILE (MENU <)
S101 1-771-410-21 SWITCH, TACTILE (MENU >)
S102 1-771-410-21 SWITCH, TACTILE (MAIN MENU)
S103 1-771-410-21 SWITCH, TACTILE (ENTER)
S104 1-771-410-21 SWITCH, TACTILE (INPUT MODE)
S105 1-771-410-21 SWITCH, TACTILE (MENU -)
S106 1-771-410-21 SWITCH, TACTILE (MENU +)
S110 1-771-410-21 SWITCH, TACTILE (TUNER FM/AM)
S111 1-771-410-21 SWITCH, TACTILE (CD)
S112 1-771-410-21 SWITCH, TACTILE (MD/TAPE)
S113 1-771-410-21 SWITCH, TACTILE (DVD)
S114 1-771-410-21 SWITCH, TACTILE (MOVIE)
S115 1-771-410-21 SWITCH, TACTILE (MUSIC)
S120 1-771-410-21 SWITCH, TACTILE (A. F. D.)
S121 1-771-410-21 SWITCH, TACTILE (TUNING -)
S122 1-771-410-21 SWITCH, TACTILE (FM MODE)
S123 1-771-410-21 SWITCH, TACTILE (TUNING +)
S124 1-771-410-21 SWITCH, TACTILE (2CH)
S125 1-771-410-21 SWITCH, TACTILE (PRESET TUNING +)
S130 1-771-410-21 SWITCH, TACTILE (VIDEO 2)
S131 1-771-410-21 SWITCH, TACTILE (VIDEO 1)
S132 1-771-410-21 SWITCH, TACTILE (PRESET TUNING -)
S133 1-771-410-21 SWITCH, TACTILE (MEMORY)
S134 1-771-410-21 SWITCH, TACTILE (DISPLAY)
S135 1-771-410-21 SWITCH, TACTILE (DIMMER)
************************************************************
HEADPHONE BOARD
*****************
< CAPACITOR >
C790 1-164-159-11 CERAMIC 0.1uF 50V
C792 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CNP791 1-691-767-11 PLUG (MICRO CONNECTOR) 5P
< JACK >
J791 1-815-314-21 JACK (PHONES)
************************************************************
A-4732-919-A MAIN BOARD, COMPLETE
*********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C371 1-127-880-11 CERAMIC 0.022uF 10% 50V
C372 1-127-880-11 CERAMIC 0.022uF 10% 50V
C373 1-127-880-11 CERAMIC 0.022uF 10% 50V
C374 1-164-159-11 CERAMIC 0.1uF 50V
C375 1-127-880-11 CERAMIC 0.022uF 10% 50V
C376 1-127-880-11 CERAMIC 0.022uF 10% 50V
C400 1-164-159-21 CERAMIC 0.1uF 50V
C402 1-126-961-11 ELECT 2.2uF 20.00% 50V
C404 1-126-961-11 ELECT 2.2uF 20.00% 50V
C405 1-126-961-11 ELECT 2.2uF 20.00% 50V
C406 1-126-961-11 ELECT 2.2uF 20.00% 50V
C407 1-126-961-11 ELECT 2.2uF 20.00% 50V
C408 1-126-961-11 ELECT 2.2uF 20.00% 50V
C409 1-126-963-11 ELECT 4.7uF 20.00% 50V
C413 1-124-257-00 ELECT 2.2uF 20% 50V
C414 1-124-257-00 ELECT 2.2uF 20% 50V
C415 1-124-257-00 ELECT 2.2uF 20% 50V
C416 1-126-961-11 ELECT 2.2uF 20.00% 50V
C417 1-124-257-00 ELECT 2.2uF 20% 50V
C418 1-126-961-11 ELECT 2.2uF 20.00% 50V
C419 1-124-257-00 ELECT 2.2uF 20% 50V
C433 1-126-961-11 ELECT 2.2uF 20.00% 50V
C452 1-126-961-11 ELECT 2.2uF 20.00% 50V
C454 1-126-961-11 ELECT 2.2uF 20.00% 50V
C455 1-126-961-11 ELECT 2.2uF 20.00% 50V
C456 1-126-961-11 ELECT 2.2uF 20.00% 50V
C457 1-126-961-11 ELECT 2.2uF 20.00% 50V
C458 1-126-961-11 ELECT 2.2uF 20.00% 50V
C459 1-126-963-11 ELECT 4.7uF 20.00% 50V
C464 1-164-159-11 CERAMIC 0.1uF 50V
C465 1-126-934-11 ELECT 220uF 20.00% 16V
C466 1-126-934-11 ELECT 220uF 20.00% 16V
C467 1-164-159-11 CERAMIC 0.1uF 50V
C471 1-126-963-11 ELECT 4.7uF 20.00% 50V
C472 1-126-963-11 ELECT 4.7uF 20.00% 50V
C481 1-126-963-11 ELECT 4.7uF 20.00% 50V
C482 1-126-963-11 ELECT 4.7uF 20.00% 50V
C483 1-126-963-11 ELECT 4.7uF 20.00% 50V
C484 1-126-963-11 ELECT 4.7uF 20.00% 50V
C485 1-126-963-11 ELECT 4.7uF 20.00% 50V
C486 1-126-963-11 ELECT 4.7uF 20.00% 50V
C487 1-126-964-11 ELECT 10uF 20.00% 50V
C488 1-164-159-11 CERAMIC 0.1uF 50V
C489 1-128-809-11 CERAMIC 100PF 5% 50V
C490 1-128-809-11 CERAMIC 100PF 5% 50V
C491 1-126-963-11 ELECT 4.7uF 20.00% 50V
C492 1-126-963-11 ELECT 4.7uF 20.00% 50V
HEADPHONE
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
MAIN
