Sony STR-K650P - Electrical Parts List: Display and Headphone Components

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
32
STR-K650P
DIGITAL
DISPLAY
R1657 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1658 1-216-809-11 METAL CHIP 100 5% 1/10W
R1659 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1660 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1662 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R1663 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R1664 1-216-809-11 METAL CHIP 100 5% 1/10W
R1665 1-216-809-11 METAL CHIP 100 5% 1/10W
R1667 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1668 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1669 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1670 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1671 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1672 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1673 1-216-809-11 METAL CHIP 100 5% 1/10W
R1674 1-216-809-11 METAL CHIP 100 5% 1/10W
R1676 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1677 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1678 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1679 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1681 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1682 1-216-845-11 METAL CHIP 100K 5% 1/10W
R1683 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1684 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1685 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1686 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1687 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1688 1-216-864-11 METAL CHIP 0 5% 1/10W
R1689 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1690 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1694 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1698 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1699 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1703 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1704 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1706 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1707 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1708 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1709 1-216-833-11 METAL CHIP 10K 5% 1/10W
< VIBRATOR >
X1101 1-781-465-21 VIBRATOR, CRYSTAL 12.288MHz
X1201 1-795-297-21 VIBRATOR, CERAMIC 13.59MHz
X1601 1-781-356-21 VIBRATOR, CERAMIC 16MHz
************************************************************
A-4731-177-A DISPLAY BOARD, COMPLETE
************************
* 3-386-245-13 HOLDER (FL)
* 4-921-941-01 CUSHION (FL)
< CAPACITOR >
C100 1-164-159-11 CERAMIC 0.1uF 50V
C101 1-164-159-11 CERAMIC 0.1uF 50V
C105 1-126-795-11 ELECT 10uF 20.00% 50V
C108 1-164-159-11 CERAMIC 0.1uF 50V
C109 1-164-159-11 CERAMIC 0.1uF 50V
C110 1-128-821-11 CERAMIC 1000PF 5% 50V
C111 1-128-813-11 CERAMIC 220PF 5% 50V
C112 1-128-813-11 CERAMIC 220PF 5% 50V
C114 1-164-159-11 CERAMIC 0.1uF 50V
C115 1-126-795-11 ELECT 10uF 20.00% 50V
C132 1-128-813-11 CERAMIC 220PF 5% 50V
C133 1-128-813-11 CERAMIC 220PF 5% 50V
C134 1-128-813-11 CERAMIC 220PF 5% 50V
C135 1-128-813-11 CERAMIC 220PF 5% 50V
C136 1-128-813-11 CERAMIC 220PF 5% 50V
C137 1-128-813-11 CERAMIC 220PF 5% 50V
C138 1-128-813-11 CERAMIC 220PF 5% 50V
C139 1-128-813-11 CERAMIC 220PF 5% 50V
C140 1-128-813-11 CERAMIC 220PF 5% 50V
C141 1-128-813-11 CERAMIC 220PF 5% 50V
C142 1-128-813-11 CERAMIC 220PF 5% 50V
C143 1-128-813-11 CERAMIC 220PF 5% 50V
C144 1-164-159-11 CERAMIC 0.1uF 50V
C150 1-164-159-11 CERAMIC 0.1uF 50V
C151 1-126-795-11 ELECT 10uF 20.00% 50V
C152 1-128-813-11 CERAMIC 220PF 5% 50V
C153 1-128-813-11 CERAMIC 220PF 5% 50V
C154 1-128-813-11 CERAMIC 220PF 5% 50V
C155 1-164-159-11 CERAMIC 0.1uF 50V
C156 1-164-159-11 CERAMIC 0.1uF 50V
C157 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR SOCKET >
CNS100 1-569-324-11 SOCKET, CONNECTOR 21P
< DIODE >
D102 8-719-046-39 DIODE SEL5821A-TP15 (MUSIC)
D103 8-719-046-39 DIODE SEL5821A-TP15 (MOVIE)
D104 8-719-046-39 DIODE SEL5821A-TP15 (A. F. D.)
D105 8-719-046-39 DIODE SEL5821A-TP15 (2CH)
< FILTER >
FL101 1-518-831-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC100 8-759-643-83 IC uPD16315GB-3BS
IC101 8-759-036-90 IC MC74ACT08N
IC102 6-600-055-01 IC GP1UD27SXK ( )
< COIL >
L101 1-412-473-21 INDUCTOR 0uH
L102 1-410-525-11 INDUCTOR 220uH
L103 1-410-525-11 INDUCTOR 220uH
< RESISTOR >
R101 1-249-417-11 CARBON 1K 5% 1/4W F
R102 1-249-421-11 CARBON 2.2K 5% 1/4W F
R103 1-249-421-11 CARBON 2.2K 5% 1/4W F
R104 1-249-425-11 CARBON 4.7K 5% 1/4W F
R105 1-249-429-11 CARBON 10K 5% 1/4W
R106 1-249-433-11 CARBON 22K 5% 1/4W
R111 1-249-417-11 CARBON 1K 5% 1/4W F
R112 1-249-421-11 CARBON 2.2K 5% 1/4W F
R113 1-249-421-11 CARBON 2.2K 5% 1/4W F
R114 1-249-425-11 CARBON 4.7K 5% 1/4W F
