Sony STR-K650P - Electrical Parts List: Main Board Transistors and ICs

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
35
STR-K650P
MAIN
D733 8-719-911-19 DIODE 1SS133T-72
D734 8-719-911-19 DIODE 1SS133T-72
D740 8-719-911-19 DIODE 1SS133T-72
D750 8-719-911-19 DIODE 1SS133T-72
D765 8-719-911-19 DIODE 1SS133T-72
D791 8-719-911-19 DIODE 1SS133T-72
D801 8-719-934-21 DIODE HZS30-1LTA
D802 8-719-072-05 DIODE D5SBA20-4003
D804 8-719-118-63 DIODE RD5.6F-T7B2
D896 8-719-043-76 DIODE AK04V1
D902 8-719-024-99 DIODE 11ES2-NTA2B
D903 8-719-024-99 DIODE 11ES2-NTA2B
D904 8-719-024-99 DIODE 11ES2-NTA2B
D905 8-719-024-99 DIODE 11ES2-NTA2B
< IC >
IC201 6-703-501-01 IC M61527FP
IC401 8-759-636-74 IC NJM4565DD
IC501 8-749-011-16 IC STK350-230
IC601 8-759-636-74 IC NJM4565DD
IC701 6-700-943-01 IC uPC2581V-S
IC702 6-700-943-01 IC uPC2581V-S
IC801 8-759-649-68 IC uPC78M07AHF
IC802 8-759-604-95 IC M5F79M07L
< JACK >
J402 1-794-981-11 JACK, PIN 4P (MD/TAPE,CD)
J403 1-794-981-11 JACK, PIN 4P (DVD,MD/TAPE)
J404 1-774-411-11 JACK, PIN 6P (VIDEO1,VIDEO2)
J405 1-770-377-21 JACK, PIN 1P (SUB WOOFER)
< COIL >
L521 1-422-009-13 COIL, AIR-CORE
L601 1-422-009-13 COIL, AIR-CORE
L651 1-422-009-13 COIL, AIR-CORE
L701 1-422-009-13 COIL, AIR-CORE
L751 1-422-009-13 COIL, AIR-CORE
< TRANSISTOR >
Q361 8-729-823-22 TRANSISTOR 2SC3576-AC
Q362 8-729-823-22 TRANSISTOR 2SC3576-AC
Q363 8-729-823-22 TRANSISTOR 2SC3576-AC
Q364 8-729-823-22 TRANSISTOR 2SC3576-AC
Q365 8-729-823-22 TRANSISTOR 2SC3576-AC
Q366 8-729-823-22 TRANSISTOR 2SC3576-AC
Q379 8-729-900-63 TRANSISTOR BN1F4M-TP
Q471 8-729-823-22 TRANSISTOR 2SC3576-AC
Q501 8-729-119-76 TRANSISTOR 2SA1115TP-EF
Q502 8-729-141-30 TRANSISTOR 2SC3623ATP-LK
Q505 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q506 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q540 8-729-281-53 TRANSISTOR 2SC1815GR-TPE2
Q550 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
Q560 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
Q601 8-729-119-76 TRANSISTOR 2SA1115TP-EF
Q602 8-729-141-30 TRANSISTOR 2SC3623ATP-LK
Q605 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q606 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q610 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
Q640 8-729-281-53 TRANSISTOR 2SC1815GR-TPE2
Q651 8-729-119-76 TRANSISTOR 2SA1115TP-EF
Q652 8-729-141-30 TRANSISTOR 2SC3623ATP-LK
Q655 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q656 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q680 8-729-281-53 TRANSISTOR 2SC1815GR-TPE2
Q691 8-729-281-53 TRANSISTOR 2SC1815GR-TPE2
Q692 8-729-900-63 TRANSISTOR BN1F4M-TP
Q701 8-729-119-76 TRANSISTOR 2SA1115TP-EF
Q702 8-729-141-30 TRANSISTOR 2SC3623ATP-LK
Q705 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q706 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q710 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
Q722 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q723 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
Q725 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q740 8-729-281-53 TRANSISTOR 2SC1815GR-TPE2
Q747 8-729-900-63 TRANSISTOR BN1F4M-TP
Q748 8-729-900-36 TRANSISTOR BA1F4M-TP
Q750 8-729-281-53 TRANSISTOR 2SC1815GR-TPE2
Q751 8-729-119-76 TRANSISTOR 2SA1115TP-EF
Q752 8-729-141-30 TRANSISTOR 2SC3623ATP-LK
Q755 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q756 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q790 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
Q801 8-729-140-97 TRANSISTOR 2SB734-T-34
< RESISTOR >
R360 1-249-441-11 CARBON 100K 5% 1/4W
R361 1-249-425-11 CARBON 4.7K 5% 1/4W F
R362 1-249-425-11 CARBON 4.7K 5% 1/4W F
R363 1-249-441-11 CARBON 100K 5% 1/4W
R366 1-249-429-11 CARBON 10K 5% 1/4W
R367 1-249-441-11 CARBON 100K 5% 1/4W
R368 1-249-437-11 CARBON 47K 5% 1/4W
R369 1-249-425-11 CARBON 4.7K 5% 1/4W F
R370 1-249-425-11 CARBON 4.7K 5% 1/4W F
R371 1-249-441-11 CARBON 100K 5% 1/4W
R372 1-249-441-11 CARBON 100K 5% 1/4W
R373 1-249-417-11 CARBON 1K 5% 1/4W F
R374 1-249-417-11 CARBON 1K 5% 1/4W F
R375 1-249-417-11 CARBON 1K 5% 1/4W F
R376 1-249-417-11 CARBON 1K 5% 1/4W F
R377 1-249-417-11 CARBON 1K 5% 1/4W F
R378 1-249-417-11 CARBON 1K 5% 1/4W F
R379 1-249-425-11 CARBON 4.7K 5% 1/4W F
R380 1-249-441-11 CARBON 100K 5% 1/4W
R381 1-249-429-11 CARBON 10K 5% 1/4W
R402 1-249-417-11 CARBON 1K 5% 1/4W F
R404 1-249-417-11 CARBON 1K 5% 1/4W F
R405 1-249-417-11 CARBON 1K 5% 1/4W F
R406 1-249-417-11 CARBON 1K 5% 1/4W F
R407 1-249-417-11 CARBON 1K 5% 1/4W F
