Sony STR-K660P - DIGITAL Board (Side B)

1515
STR-K660P
IC1902
IC1901
IC1903
IC1904
IC1503
IC1104
3
1
1
13
1
1
3
3
3
45
18
1
1
3
13
15 14
111
210
1
3
FOR FLASH
PROGRAMMING
A
STANDBY BOARD
CNP912
(Page 22)
K
DISPLAY BOARD
CNS100
(Page 24)
I
MAIN BOARD
CNP502
(Page 18)
H
MAIN BOARD
CNP501
(Page 18)
B
STANDBY BOARD
CNP802
(Page 22)
J
MAIN BOARD
CNP911
(Page 18)
TUNER UNIT
AM
FM 75
COAXIAL
OPTICAL
VIDEO IN
OPTICAL
VIDEO IN
DIGITAL
• See page 10 for Circuit Boards Location.
3-4. PRINTED WIRING BOARD – DIGITAL BOARD (SIDE B) –
• : Uses unleaded solder.
Ref. No. Location
D1001 E-8
D1501 E-8
D1502 E-9
IC1104 C-10
IC1503 G-6
IC1901 C-3
IC1902 B-3
IC1903 D-3
IC1904 D-3
• Semiconductor
Location
