Sony STR-K660P - Front Panel Section Diagrams

2424
STR-K660P
• See page 10 for Circuit Boards Location.
3-14. PRINTED WIRING BOARD – FRONT PANEL SECTION –
• : Uses unleaded solder.
Ref. No. Location
D102 B-6
D103 B-3
D104 B-4
D105 B-5
IC100 B-13
IC101 D-11
IC102 B-17
• Semiconductor
Location
IC101
IC100
IC102
TUNING BOARD
PRESET TUNING
TUNING
MEMORY
FM MODE
DIMMERDISPLAY
`/1
13
MUSIC MOVIE A.F.D. 2CH
ENTER
MAIN
MENU
>
>
INPUT
MODE
MASTER
VOLUME
AM FM DVD VIDEO
71
814
13
K
DIGITAL BOARD
CNS4
(Page 15)
