Sony STR-K660P - Diagrams

10
STR-K660P
SECTION 3
DIAGRAMS
3-1. CIRCUIT BOARD LOCATION
DIGITAL board
MAIN board
DISPLAY board
HEADPHONE board
POWER board
TUNING board
STANDBY board
SUB WOOFER board
AC SELECT board
(E51 model only)
