32
STR-K660P
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
4-2. CHASSIS SECTION
51
5253
64
60
54
56
Q574
Q604
Q603
Q754
Q753
Q654
Q653
Q703
Q504
Q503
Q704
Q573
Q572
57
58
59
61
62
63
T901
F901
51
52
53
not
supplied
not
supplied
not
supplied
not
supplied
not
supplied
not
supplied
not
supplied
not
supplied
not
supplied
not
supplied
not
supplied
not
supplied
55
57
#2
#2
#2
#1
#1
#1
#1
#1
not
supplied
#1
#1
#1
#1
#1
#1
#1
#1
#1
#1
#1
#1
#1
#1
51 4-232-237-01 FOOT (DIA. 30)
52 4-977-358-01 CUSHION
53 X-4953-448-1 FOOT ASSY
54 A-4750-409-A STANDBY BOARD, COMPLETE (SP)
54 A-4750-423-A STANDBY BOARD, COMPLETE (E51)
54 A-4750-608-A STANDBY BOARD, COMPLETE (US)
54 A-4750-427-A STANDBY BOARD, COMPLETE (MX)
55 4-249-675-01 +BV SUMITITE S 4X6 ROUND
56 A-4750-417-A SUB WOOFER BOARD, COMPLETE
57 3-905-609-01 SCREW (TRANSISTOR)
* 58 3-703-244-00 BUSHING (2104), CORD
0 59 1-777-071-23 CORD, POWER (E51, SP)
0 59 1-783-532-11 CORD, POWER (US, MX)
60 A-4750-415-A MAIN BOARD, COMPLETE (US)
60 A-4752-121-A MAIN BOARD, COMPLETE (E51, MX, SP)
61 1-769-937-11 WIRE (FLAT TYPE)(11 CORE)
62 1-575-662-31 WIRE (FLAT TYPE)(5 CORE)
63 A-4750-421-A DIGITAL BOARD, COMPLETE (US)
63 A-4752-122-A DIGITAL BOARD, COMPLETE (E51)
63 A-4752-127-A DIGITAL BOARD, COMPLETE (SP)
63 A-4752-129-A DIGITAL BOARD, COMPLETE (MX)
64 3-701-748-00 CLAMP
0 F901 1-532-464-32 FUSE T2.5AL/250V (E51)
0 F901 1-532-503-32 FUSE T1.6AL/250V (SP)
0 F901 1-533-452-11
FUSE, GLASS TUBE (DIA. 5) T4.0AL/125V (US, MX)
Q503 8-749-010-25 IC MN2488-OPY-M
Q504 8-749-010-26 IC MP1620-OPY-M
Q572 8-729-026-08 TRANSISTOR 2SC4495
Q573 8-749-010-25 IC MN2488-OPY-M
Q574 8-749-010-26 IC MP1620-OPY-M
Q603 8-749-010-25 IC MN2488-OPY-M
Q604 8-749-010-26 IC MP1620-OPY-M
Q653 8-749-010-25 IC MN2488-OPY-M
Q654 8-749-010-26 IC MP1620-OPY-M
Q703 8-749-010-25 IC MN2488-OPY-M
Q704 8-749-010-26 IC MP1620-OPY-M
Q753 8-749-010-25 IC MN2488-OPY-M
Q754 8-749-010-26 IC MP1620-OPY-M
0 T901 1-443-185-11 POWER TRANSFORMER (US, MX)
0 T901 1-443-186-11 POWER TRANSFORMER (E51)
0 T901 1-443-211-11 POWER TRANSFORMER (SP)
#1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
#2 7-685-645-79 SCREW +BVTP 3X6 TYPE2 IT-3
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
