Sony STR-K660P - Power Section Diagrams

2222
STR-K660P
• See page 10 for Circuit Boards Location.
3-12. PRINTED WIRING BOARD – POWER SECTION –
• : Uses unleaded solder.
1
3
13
1
5
16
CBE
E
E
US
E51
E51
E51
EXCEPT E51
EXCEPT E51
1
4
T902
POWER TRANSFORMER
F901
A
DIGITAL BOARD
CNP5
(Page 15)
C
MAIN BOARD
CNP915
(Page 18)
B
DIGITAL BOARD
CNP6
(Page 15)
VOLTAGE
SELECTOR
240V 220V 120V
D
MAIN BOARD
CNP801
(Page 18)
T901
POWER TRANSFORMER
E51
Ref. No. Location
D801 B-6
D804 C-6
D812 C-4
D813 C-5
D814 B-5
D815 C-5
D820 C-4
D821 C-4
D822 B-3
D823 B-3
D901 C-4
D910 E-2
D911 E-2
D912 E-2
D913 E-2
D914 D-2
D915 D-2
Q801 C-7
Q901 D-3
Q921 C-3
• Semiconductor
Location
