Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
37
STR-K660P
DISPLAY HEADPHONE
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
MAIN
R121 1-247-831-91 CARBON 1K 5% 1/4W
R122 1-249-421-11 CARBON 2.2K 5% 1/4W F
R123 1-249-421-11 CARBON 2.2K 5% 1/4W F
R150 1-249-440-11 CARBON 82K 5% 1/4W
R153 1-247-807-31 CARBON 100 5% 1/4W
0 R154 1-249-393-11 CARBON 10 5% 1/4W F
R161 1-249-409-11 CARBON 220 5% 1/4W F
0 R175 1-249-393-11 CARBON 10 5% 1/4W F
0 R198 1-249-381-11 CARBON 1 5% 1/4W F
0 R199 1-249-381-11 CARBON 1 5% 1/4W F
< VARIABLE RESISTOR >
RV102 1-418-725-41 ENCODER, ROTARY (12 TYPE)
(MASTER VOLUME)
< SWITCH >
S100 1-771-410-21 SWITCH, TACTILE (INPUT MODE)
S101 1-771-410-21 SWITCH, TACTILE (>)
S102 1-771-410-21 SWITCH, TACTILE (-)
S103 1-771-410-21 SWITCH, TACTILE (+)
S104 1-771-410-21 SWITCH, TACTILE (<)
S108 1-771-410-21 SWITCH, TACTILE (AM)
S110 1-771-410-21 SWITCH, TACTILE (MUSIC)
S111 1-771-410-21 SWITCH, TACTILE (MOVIE)
S112 1-771-410-21 SWITCH, TACTILE (A.F.D.)
S113 1-771-410-21 SWITCH, TACTILE (2CH)
S114 1-771-410-21 SWITCH, TACTILE (ENTER)
S115 1-771-410-21 SWITCH, TACTILE (MAIN MENU)
S126 1-771-410-21 SWITCH, TACTILE (VIDEO)
S127 1-771-410-21 SWITCH, TACTILE (DVD)
S128 1-771-410-21 SWITCH, TACTILE (FM)
************************************************************
HEADPHONE BOARD
*****************
< CONNECTOR >
CNP791 1-691-766-11 PLUG (MICRO CONNECTOR) 4P
< JACK >
J791 1-815-314-21 JACK (PHONES)
************************************************************
A-4750-415-A MAIN BOARD, COMPLETE (US)
*************************
A-4752-121-A MAIN BOARD, COMPLETE (E51, MX, SP)
*********************************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C371 1-161-494-00 CERAMIC 0.022uF 25V
C372 1-161-494-00 CERAMIC 0.022uF 25V
C373 1-161-494-00 CERAMIC 0.022uF 25V
C374 1-164-159-11 CERAMIC 0.1uF 50V
C375 1-161-494-00 CERAMIC 0.022uF 25V
C376 1-161-494-00 CERAMIC 0.022uF 25V
C413 1-126-961-11 ELECT 2.2uF 20.00% 50V
C414 1-126-961-11 ELECT 2.2uF 20.00% 50V
C415 1-126-961-11 ELECT 2.2uF 20.00% 50V
C416 1-126-961-11 ELECT 2.2uF 20.00% 50V
C417 1-126-961-11 ELECT 2.2uF 20.00% 50V
C418 1-126-961-11 ELECT 2.2uF 20.00% 50V
C419 1-126-961-11 ELECT 2.2uF 20.00% 50V
C433 1-126-961-11 ELECT 2.2uF 20.00% 50V
C464 1-164-159-11 CERAMIC 0.1uF 50V
C465 1-126-934-11 ELECT 220uF 20.00% 16V
C467 1-164-159-11 CERAMIC 0.1uF 50V
C475 1-126-964-11 ELECT 10uF 20.00% 50V
C481 1-126-963-11 ELECT 4.7uF 20.00% 50V
C482 1-126-963-11 ELECT 4.7uF 20.00% 50V
C483 1-126-963-11 ELECT 4.7uF 20.00% 50V
C484 1-126-963-11 ELECT 4.7uF 20.00% 50V
C485 1-126-964-11 ELECT 10uF 20.00% 50V
C486 1-126-963-11 ELECT 4.7uF 20.00% 50V
C487 1-126-964-11 ELECT 10uF 20.00% 50V
C488 1-164-159-11 CERAMIC 0.1uF 50V
C489 1-128-809-11 CERAMIC 100PF 5% 50V
C490 1-128-809-11 CERAMIC 100PF 5% 50V
C491 1-126-963-11 ELECT 4.7uF 20.00% 50V
C492 1-126-963-11 ELECT 4.7uF 20.00% 50V
C493 1-126-963-11 ELECT 4.7uF 20.00% 50V
C494 1-126-963-11 ELECT 4.7uF 20.00% 50V
C495 1-126-963-11 ELECT 4.7uF 20.00% 50V
C496 1-126-963-11 ELECT 4.7uF 20.00% 50V
C497 1-128-809-11 CERAMIC 100PF 5% 50V
C501 1-126-963-11 ELECT 4.7uF 20.00% 50V
C503 1-104-658-91 ELECT 100uF 20.00% 10V
C504 1-107-583-11 CERAMIC 3PF 0.25PF 500V
C505 1-106-359-00 MYLAR 4700PF 5% 200V
C506 1-102-233-00 CERAMIC 33PF 10.00% 500V
C507 1-128-809-11 CERAMIC 100PF 5% 50V
C508 1-128-809-11 CERAMIC 100PF 5% 50V
C510 1-126-947-11 ELECT 47uF 20.00% 25V
C511 1-136-157-00 FILM 0.022uF 5.00% 50V
C516 1-162-815-11 CERAMIC 47PF 5.00% 500V
C517 1-162-815-11 CERAMIC 47PF 5.00% 500V
C519 1-128-813-11 CERAMIC 220PF 5% 50V
C540 1-126-964-11 ELECT 10uF 20.00% 50V
C541 1-127-876-11 CERAMIC 0.01uF 10% 50V
C601 1-126-963-11 ELECT 4.7uF 20.00% 50V
C603 1-104-658-91 ELECT 100uF 20.00% 10V
C604 1-107-583-11 CERAMIC 3PF 0.25PF 500V
C605 1-102-233-00 CERAMIC 33PF 10.00% 500V
C606 1-128-813-11 CERAMIC 220PF 5% 50V
C607 1-128-809-11 CERAMIC 100PF 5% 50V
C610 1-126-947-11 ELECT 47uF 20.00% 25V
C611 1-136-157-00 FILM 0.022uF 5.00% 50V
C619 1-128-813-11 CERAMIC 220PF 5% 50V
C620 1-162-815-11 CERAMIC 47PF 5.00% 500V
C621 1-162-815-11 CERAMIC 47PF 5.00% 500V
C640 1-126-964-11 ELECT 10uF 20.00% 50V
C642 1-127-876-11 CERAMIC 0.01uF 10% 50V
C643 1-128-579-11 ELECT 2.2uF 20.00% 100V
