Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
42
STR-K660P
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
STANDBY
R921 1-247-871-91 CARBON 47K 5% 1/4W
R922 1-249-435-11 CARBON 33K 5% 1/4W
R923 1-249-429-11 CARBON 10K 5% 1/4W
< RELAY >
0 RY901 1-755-276-11 RELAY, POWER
< TRANSFORMER >
0 T902 1-435-281-11 TRANSFORMER, POWER (US, MX)
0 T902 1-435-283-11 TRANSFORMER, POWER (E51)
0 T902 1-435-435-11 TRANSFORMER, POWER (SP)
************************************************************
A-4750-417-A SUB WOOFER BOARD, COMPLETE
****************************
< CAPACITOR >
C561 1-126-963-11 ELECT 4.7uF 20.00% 50V
C562 1-128-809-11 CERAMIC 100PF 5% 50V
C563 1-106-359-00 MYLAR 4700PF 5% 200V
C564 1-102-233-00 CERAMIC 33PF 10.00% 500V
C565 1-107-583-11 CERAMIC 3PF 0.25PF 500V
C566 1-104-658-91 ELECT 100uF 20.00% 10V
C571 1-126-947-11 ELECT 47uF 20.00% 25V
C573 1-162-815-11 CERAMIC 47PF 5.00% 500V
C575 1-162-815-11 CERAMIC 47PF 5.00% 500V
C578 1-128-813-11 CERAMIC 220PF 5% 50V
C581 1-136-157-00 FILM 0.022uF 5.00% 50V
C590 1-137-190-91 FILM 0.22uF 5.00% 50V
C592 1-136-175-00 FILM 0.68uF 5.00% 50V
C593 1-136-159-00 FILM 0.033uF 5.00% 50V
C594 1-137-190-91 FILM 0.22uF 5.00% 50V
< CONNECTOR >
* CNP505 1-564-104-00 PIN, CONNECTOR (3.96mm PITCH) 3P
< DIODE >
D576 8-719-991-33 DIODE 1SS133T-72
< IC >
IC502 8-759-167-88 IC NJM4565D
IC503 8-749-011-16 IC STK350-230
< COIL >
L561 1-420-872-52 COIL, AIR-CORE
< TRANSISTOR >
Q575 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q576 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
< RESISTOR >
R560 1-249-411-11 CARBON 330 5% 1/4W
R561 1-247-831-91 CARBON 1K 5% 1/4W
R562 1-249-439-11 CARBON 68K 5% 1/4W
R565 1-249-439-11 CARBON 68K 5% 1/4W
R566 1-247-831-91 CARBON 1K 5% 1/4W
R567 1-247-863-81
RES, CARBON (SMALL)
22K 5% 1/4W
R568 1-247-863-81
RES, CARBON (SMALL)
22K 5% 1/4W
R571 1-249-428-11 CARBON 8.2K 5% 1/4W F
R572 1-247-847-91 CARBON 4.7K 5% 1/4W
R574 1-247-831-91 CARBON 1K 5% 1/4W
0 R575 1-249-405-11 CARBON 100 5% 1/4W F
R576 1-247-850-11 CARBON 6.2K 5% 1/4W
R577 1-247-847-91 CARBON 4.7K 5% 1/4W
0 R578 1-234-182-11 ENCAPSULATED COMPONENT
R579 1-249-419-11 CARBON 1.5K 5% 1/4W F
R580 1-249-439-11 CARBON 68K 5% 1/4W
0 R581 1-249-393-11 CARBON 10 5% 1/4W F
0 R582 1-249-405-11 CARBON 100 5% 1/4W F
R583 1-249-431-11 CARBON 15K 5% 1/4W
R587 1-247-871-91 CARBON 47K 5% 1/4W
0 R588 1-249-389-11 CARBON 4.7 5% 1/4W F
R591 1-249-426-11 CARBON 5.6K 5% 1/4W
R593 1-247-871-91 CARBON 47K 5% 1/4W
R595 1-249-427-11 CARBON 6.8K 5% 1/4W F
R596 1-249-427-11 CARBON 6.8K 5% 1/4W F
R597 1-247-879-91 CARBON 100K 5% 1/4W
************************************************************
1-861-044-11 TUNING BOARD
*************
R132 1-247-831-91 CARBON 1K 5% 1/4W
R133 1-249-421-11 CARBON 2.2K 5% 1/4W F
R134 1-249-421-11 CARBON 2.2K 5% 1/4W F
R135 1-247-847-91 CARBON 4.7K 5% 1/4W
R136 1-249-429-11 CARBON 10K 5% 1/4W
< SWITCH >
S131 1-771-410-21 SWITCH, TACTILE (-(TUNING))
S132 1-771-410-21 SWITCH, TACTILE (FM MODE)
S133 1-771-410-21 SWITCH, TACTILE (MEMORY)
S134 1-771-410-21 SWITCH, TACTILE (−(PRESET TUNING))
S135 1-771-410-21 SWITCH, TACTILE (+(PRESET TUNING))
S151 1-771-410-21 SWITCH, TACTILE (+(TUNING))
************************************************************
MISCELLANEOUS
**************
8 1-773-114-11 WIRE (FLAT TYPE)(19 CORE)
0 59 1-777-071-23 CORD, POWER (E51, SP)
0 59 1-783-532-11 CORD, POWER (US, MX)
61 1-769-937-11 WIRE (FLAT TYPE)(11 CORE)
62 1-575-662-31 WIRE (FLAT TYPE)(5 CORE)
0 F901 1-532-464-32 FUSE T2.5AL/250V (E51)
0 F901 1-532-503-32 FUSE T1.6AL/250V (SP)
0 F901 1-533-452-11 FUSE, GLASS TUBE (DIA. 5) T4.0AL/125V
(US, MX)
Q503 8-749-010-25 IC MN2488-OPY-M
Q504 8-749-010-26 IC MP1620-OPY-M
Q572 8-729-026-08 TRANSISTOR 2SC4495
Q573 8-749-010-25 IC MN2488-OPY-M
Q574 8-749-010-26 IC MP1620-OPY-M
Q603 8-749-010-25 IC MN2488-OPY-M
Q604 8-749-010-26 IC MP1620-OPY-M
Q653 8-749-010-25 IC MN2488-OPY-M
