12
STR-K7000
SECTION 4
DIAGRAMS
4-1. CIRCUIT BOARDS LOCATION
MAIN board
DISPLAY board
POWER board
ADCC board
HEADPHONE board
VIDEO3 board
SPEAKER B board
STANDBY board
SPEAKER C/SB board
HDMI SW board
VIDEO board
XM board
DIGITAL board
