Sony STR-K7000 - Main Power

67
STR-K7000
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R754 1-249-439-11 CARBON 68K 5% 1/4W
R755 1-247-847-11 CARBON 4.7K 5% 1/4W
R756 1-247-871-11 CARBON 47K 5% 1/4W
R757 1-249-431-11 CARBON 15K 5% 1/4W
R758 1-249-431-11 CARBON 15K 5% 1/4W
R759 1-247-879-11 CARBON 100K 5% 1/4W
R760 1-249-421-11 CARBON 2.2K 5% 1/4W
R761 1-249-440-11 CARBON 82K 5% 1/4W
R763 1-249-414-11 CARBON 560 5% 1/4W
R764 1-249-399-11 CARBON 33 5% 1/4W F
R765 1-249-399-11 CARBON 33 5% 1/4W F
R766 1-234-182-11 ENCAPSULATED COMPONENT 0.22X2 5W
R767 1-249-393-11 CARBON 10 5% 1/4W F
R768 1-249-389-11 CARBON 4.7 5% 1/4W F
R769 1-247-847-11 CARBON 4.7K 5% 1/4W
R771 1-240-855-81 CARBON 6.2K 5% 1/4W F
R772 1-249-419-11 CARBON 1.5K 5% 1/4W
R773 1-247-871-11 CARBON 47K 5% 1/4W
R775 1-249-439-11 CARBON 68K 5% 1/4W
R778 1-249-431-11 CARBON 15K 5% 1/4W
R780 1-249-429-11 CARBON 10K 5% 1/4W
R791 1-249-421-11 CARBON 2.2K 5% 1/4W
0 R792 1-215-868-00 METAL OXIDE 680 5% 1W F
R793 1-249-404-00 CARBON 82 5% 1/4W F
0 R794 1-215-868-00 METAL OXIDE 680 5% 1W F
R802 1-249-409-11 CARBON 220 5% 1/4W F
R803 1-249-389-11 CARBON 4.7 5% 1/4W F
R804 1-249-429-11 CARBON 10K 5% 1/4W
R806 1-247-863-11 CARBON 22K 5% 1/4W
R840 1-249-427-11 CARBON 6.8K 5% 1/4W
R843 1-247-863-11 CARBON 22K 5% 1/4W
R844 1-247-863-11 CARBON 22K 5% 1/4W
0 R910 1-240-877-11 FUSIBLE 0.15 5% 1/2W F
< RELAY >
RY560 1-755-267-11 RELAY
RY601 1-755-170-11 RELAY (12V)
RY701 1-755-170-11 RELAY (12V)
RY791 1-755-170-11 RELAY (12V)
< TERMINAL BOARD >
TM601 1-780-364-11 TERMINAL BOARD (8P) (SPEAKERS
SURROUND,FRONT A)
*************************************************************
POWER BOARD
*************
< RESISTOR >
R114 1-247-831-11 CARBON 1K 5% 1/4W
< SWITCH >
S100 1-771-410-21 SWITCH, TACTILE (?/1)
S115 1-771-410-21 SWITCH, TACTILE (SPEAKERS (OFF/A/B/A+B))
*************************************************************
SPEAKER B BOARD
****************
< CONNECTOR >
CNP600 1-785-103-11 PIN, CONNECTOR (3.96mm PITCH) 5P
CNP601 1-784-921-11 PIN, CONNECTOR 4P
* CNP807 1-564-242-00 PIN, CONNECTOR (3.96mm PITCH) 5P
< DIODE >
D800 8-719-991-33 DIODE 1SS133T-77
D818 8-719-991-33 DIODE 1SS133T-77
< TRANSISTOR >
Q800 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q809 8-729-119-78 TRANSISTOR 2SC2785-HFE
< RESISTOR >
R800 1-249-404-00 CARBON 82 5% 1/4W F
R812 1-249-421-11 CARBON 2.2K 5% 1/4W
R824 1-249-421-11 CARBON 2.2K 5% 1/4W
R831 1-249-404-00 CARBON 82 5% 1/4W F
< RELAY >
RY600 1-755-170-11 RELAY (12V)
RY801 1-755-013-11 RELAY
< TERMINAL BOARD >
TM602 1-537-240-11 TERMINAL BOARD (CHECKER PIN) (4P)
(SPEAKERS FRONT B)
*************************************************************
SPEAKER C/SB BOARD
*******************
< CONNECTOR >
* CNP503 1-564-241-11 PIN, CONNECTOR (3.96mm PITCH) 4P
< DIODE >
D510 8-719-991-33 DIODE 1SS133T-77
< COIL >
L571 1-420-872-52 COIL, AIR-CORE
L751 1-420-872-52 COIL, AIR-CORE
< TRANSISTOR >
Q550 8-729-119-78 TRANSISTOR 2SC2785-HFE
< RESISTOR >
R531 1-249-421-11 CARBON 2.2K 5% 1/4W
R534 1-249-404-00 CARBON 82 5% 1/4W F
R578 1-249-389-11 CARBON 4.7 5% 1/4W F
R751 1-249-389-11 CARBON 4.7 5% 1/4W F
< RELAY >
RY501 1-755-170-11 RELAY (12V)
MAIN POWER SPEAKER C/SBSPEAKER B
