63
STR-K7000
Ref. No. Part No. Description Remark
< RESISTOR >
R5001 1-218-861-11 METAL CHIP 3.9K 0.5% 1/10W
R5002 1-218-844-11 METAL CHIP 750 0.5% 1/10W
R5003 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5004 1-216-864-11 SHORT CHIP 0
R5005 1-216-864-11 SHORT CHIP 0
R5006 1-216-864-11 SHORT CHIP 0
R5007 1-216-864-11 SHORT CHIP 0
R5008 1-216-864-11 SHORT CHIP 0
R5009 1-216-864-11 SHORT CHIP 0
R5010 1-216-864-11 SHORT CHIP 0
R5011 1-216-864-11 SHORT CHIP 0
R5014 1-216-864-11 SHORT CHIP 0
R5015 1-216-821-11 METAL CHIP 1K 5% 1/10W
R5016 1-216-864-11 SHORT CHIP 0
R5017 1-216-864-11 SHORT CHIP 0
R5018 1-216-821-11 METAL CHIP 1K 5% 1/10W
R5019 1-216-864-11 SHORT CHIP 0
R5020 1-216-864-11 SHORT CHIP 0
R5022 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5024 1-216-864-11 SHORT CHIP 0
R5025 1-216-864-11 SHORT CHIP 0
R5026 1-216-809-11 METAL CHIP 100 5% 1/10W
R5027 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5028 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5029 1-216-841-11 METAL CHIP 47K 5% 1/10W
R5030 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5042 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R5043 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R5047 1-216-864-11 SHORT CHIP 0
R5048 1-216-864-11 SHORT CHIP 0
R5049 1-216-864-11 SHORT CHIP 0
R5050 1-216-821-11 METAL CHIP 1K 5% 1/10W
R5051 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R5052 1-216-841-11 METAL CHIP 47K 5% 1/10W
R5053 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R5054 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5055 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5056 1-216-821-11 METAL CHIP 1K 5% 1/10W
R5060 1-216-864-11 SHORT CHIP 0
R5061 1-216-864-11 SHORT CHIP 0
R5068 1-216-845-11 METAL CHIP 100K 5% 1/10W
R5069 1-216-845-11 METAL CHIP 100K 5% 1/10W
R5072 1-216-809-11 METAL CHIP 100 5% 1/10W
R5073 1-216-864-11 SHORT CHIP 0
R5074 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
*************************************************************
HEADPHONE BOARD
*****************
< CAPACITOR >
C790 1-127-888-11 CERAMIC 0.1uF 10% 50V
C791 1-127-888-11 CERAMIC 0.1uF 10% 50V
< CONNECTOR >
CNP791 1-691-766-11 PLUG (MICRO CONNECTOR) 4P
< JACK >
J791 1-815-314-21 JACK (PHONES)
< LEAD WIRE >
* TP701 1-690-880-31 LEAD (WITH CONNECTOR)
*************************************************************
A-1161-218-A MAIN BOARD, COMPLETE
*********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C400 1-127-888-11 CERAMIC 0.1uF 10% 50V
C403 1-127-888-11 CERAMIC 0.1uF 10% 50V
C408 1-126-963-11 ELECT 4.7uF 20% 50V
C409 1-126-963-11 ELECT 4.7uF 20% 50V
C444 1-127-868-11 CERAMIC 0.0022uF 10% 50V
C445 1-127-888-11 CERAMIC 0.1uF 10% 50V
C453 1-162-286-31 CERAMIC 220PF 10% 50V
C458 1-126-963-11 ELECT 4.7uF 20% 50V
C459 1-126-963-11 ELECT 4.7uF 20% 50V
C463 1-162-286-31 CERAMIC 220PF 10% 50V
C464 1-127-888-11 CERAMIC 0.1uF 10% 50V
C468 1-162-282-31 CERAMIC 100PF 10% 50V
C469 1-162-282-31 CERAMIC 100PF 10% 50V
C471 1-126-963-11 ELECT 4.7uF 20% 50V
C472 1-126-963-11 ELECT 4.7uF 20% 50V
C481 1-126-964-11 ELECT 10uF 20% 50V
C484 1-126-964-11 ELECT 10uF 20% 50V
C485 1-126-964-11 ELECT 10uF 20% 50V
C488 1-127-888-11 CERAMIC 0.1uF 10% 50V
C492 1-126-964-11 ELECT 10uF 20% 50V
C493 1-126-964-11 ELECT 10uF 20% 50V
C495 1-126-964-11 ELECT 10uF 20% 50V
C499 1-162-286-31 CERAMIC 220PF 10% 50V
C501 1-126-963-11 ELECT 4.7uF 20% 50V
C503 1-104-658-11 ELECT 100uF 20% 10V
C504 1-107-585-11 CERAMIC 5PF 0.25PF 500V
C505 1-102-233-00 CERAMIC 33PF 10% 500V
C506 1-162-282-31 CERAMIC 100PF 10% 50V
C507 1-162-282-31 CERAMIC 100PF 10% 50V
C510 1-126-947-11 ELECT 47uF 20% 35V
C511 1-136-157-00 FILM 0.022uF 5% 50V
C516 1-162-815-11 CERAMIC 47PF 5% 500V
C517 1-162-815-11 CERAMIC 47PF 5% 500V
C519 1-162-286-31 CERAMIC 220PF 10% 50V
C529 1-127-876-11 CERAMIC 0.01uF 10% 50V
C540 1-126-964-11 ELECT 10uF 20% 50V
C541 1-127-876-11 CERAMIC 0.01uF 10% 50V
C601 1-126-963-11 ELECT 4.7uF 20% 50V
C603 1-104-658-11 ELECT 100uF 20% 10V
C604 1-107-583-11 CERAMIC 3PF 0.25PF 500V
C605 1-102-233-00 CERAMIC 33PF 10% 500V
C606 1-162-282-31 CERAMIC 100PF 10% 50V
C607 1-162-282-31 CERAMIC 100PF 10% 50V
C610 1-126-947-11 ELECT 47uF 20% 35V
C611 1-136-157-00 FILM 0.022uF 5% 50V
Ref. No. Part No. Description Remark
MAINHEADPHONEHDMI SW
