Sony STR-K7000 - Page 70

70
STR-K7000
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C165 1-162-910-11 CERAMIC CHIP 5PF 0.25PF 50V
C166 1-162-910-11 CERAMIC CHIP 5PF 0.25PF 50V
C167 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN101 1-568-828-11 CONNECTOR, FFC 9P
CN102 1-784-766-11 CONNECTOR, FFC 5P
CN103 1-779-978-11 PIN, CONNECTOR 3P
< DIODE >
D101 6-500-462-01 DIODE NSAD500F-T1B
D103 8-719-083-02 DIODE KDS160-RTK
D104 8-719-043-53 DIODE D2SBA20F03
< FERRITE BEAD >
FB101 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB104 1-469-152-11 FERRITE, EMI (SMD) (2012)
< IC >
IC101 6-705-468-01 IC BA33BC0FP-E2
IC102 6-709-251-01 IC F2602E-01-TR
IC103 8-759-524-50 IC TC74VHC541FT(EL)
IC104 8-759-710-97 IC NJM4565M-D
IC105 6-707-111-01 IC PCM1753DBQR
IC106 6-707-802-01 IC BA00CC0WT(-V5)
IC107 6-703-547-01 IC TA7805LS
< CONNECTOR >
J101 1-793-642-21 CONNECTOR (USB) (4P), SQUARE (XM)
< JUMPER RESISTOR >
L101 1-216-295-11 SHORT CHIP 0
L102 1-216-295-11 SHORT CHIP 0
< TRANSISTOR >
Q101 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q104 8-729-027-43 TRANSISTOR DTC114EKA-T146
< RESISTOR >
R101 1-216-833-11 METAL CHIP 10K 5% 1/10W
R102 1-216-833-11 METAL CHIP 10K 5% 1/10W
R103 1-216-833-11 METAL CHIP 10K 5% 1/10W
R104 1-216-833-11 METAL CHIP 10K 5% 1/10W
R105 1-216-809-11 METAL CHIP 100 5% 1/10W
R106 1-216-809-11 METAL CHIP 100 5% 1/10W
R107 1-216-809-11 METAL CHIP 100 5% 1/10W
R108 1-216-809-11 METAL CHIP 100 5% 1/10W
R109 1-216-841-11 METAL CHIP 47K 5% 1/10W
R111 1-216-821-11 METAL CHIP 1K 5% 1/10W
R112 1-216-833-11 METAL CHIP 10K 5% 1/10W
R115 1-216-833-11 METAL CHIP 10K 5% 1/10W
R116 1-216-833-11 METAL CHIP 10K 5% 1/10W
R117 1-216-809-11 METAL CHIP 100 5% 1/10W
R118 1-216-841-11 METAL CHIP 47K 5% 1/10W
R119 1-216-841-11 METAL CHIP 47K 5% 1/10W
R120 1-216-834-11 METAL CHIP 12K 5% 1/10W
R121 1-216-841-11 METAL CHIP 47K 5% 1/10W
R122 1-216-841-11 METAL CHIP 47K 5% 1/10W
R123 1-216-819-11 METAL CHIP 680 5% 1/10W
R124 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R125 1-216-813-11 METAL CHIP 220 5% 1/10W
R126 1-216-845-11 METAL CHIP 100K 5% 1/10W
R127 1-216-809-11 METAL CHIP 100 5% 1/10W
R128 1-216-845-11 METAL CHIP 100K 5% 1/10W
R129 1-216-809-11 METAL CHIP 100 5% 1/10W
R130 1-216-809-11 METAL CHIP 100 5% 1/10W
R131 1-216-809-11 METAL CHIP 100 5% 1/10W
R132 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R133 1-216-819-11 METAL CHIP 680 5% 1/10W
R134 1-216-809-11 METAL CHIP 100 5% 1/10W
R137 1-216-834-11 METAL CHIP 12K 5% 1/10W
R138 1-216-821-11 METAL CHIP 1K 5% 1/10W
R143 1-216-809-11 METAL CHIP 100 5% 1/10W
R144 1-216-821-11 METAL CHIP 1K 5% 1/10W
R145 1-216-841-11 METAL CHIP 47K 5% 1/10W
R146 1-216-841-11 METAL CHIP 47K 5% 1/10W
R147 1-216-833-11 METAL CHIP 10K 5% 1/10W
R152 1-216-809-11 METAL CHIP 100 5% 1/10W
R153 1-216-809-11 METAL CHIP 100 5% 1/10W
R154 1-216-809-11 METAL CHIP 100 5% 1/10W
R155 1-216-809-11 METAL CHIP 100 5% 1/10W
R156 1-216-811-11 METAL CHIP 150 5% 1/10W
R158 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R160 1-216-864-11 SHORT CHIP 0
R162 1-216-819-11 METAL CHIP 680 5% 1/10W
R163 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R164 1-216-841-11 METAL CHIP 47K 5% 1/10W
R165 1-216-864-11 SHORT CHIP 0
R166 1-216-864-11 SHORT CHIP 0
R167 1-216-864-11 SHORT CHIP 0
R168 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
R169 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
R172 1-216-864-11 SHORT CHIP 0
R173 1-216-864-11 SHORT CHIP 0
< VIBRATOR >
X101 1-760-841-11 VIBRATOR, CRYSTAL (45.158MHz)
*************************************************************
XM
