Sony STR-K790 - Page 49

49
STR-K790
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< COIL >
L5013 1-400-862-11 BEAD, FERRITE
< RESISTOR >
R5001 1-218-861-11 METAL CHIP 3.9K 0.5% 1/10W
R5002 1-218-844-11 METAL CHIP 750 0.5% 1/10W
R5003 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5004 1-216-864-11 SHORT CHIP 0
R5005 1-216-864-11 SHORT CHIP 0
R5006 1-216-864-11 SHORT CHIP 0
R5007 1-216-864-11 SHORT CHIP 0
R5008 1-216-864-11 SHORT CHIP 0
R5009 1-216-864-11 SHORT CHIP 0
R5010 1-216-864-11 SHORT CHIP 0
R5011 1-216-864-11 SHORT CHIP 0
R5014 1-216-864-11 SHORT CHIP 0
R5015 1-216-821-11 METAL CHIP 1K 5% 1/10W
R5016 1-216-864-11 SHORT CHIP 0
R5017 1-216-864-11 SHORT CHIP 0
R5018 1-216-821-11 METAL CHIP 1K 5% 1/10W
R5019 1-216-864-11 SHORT CHIP 0
R5020 1-216-864-11 SHORT CHIP 0
R5022 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5024 1-216-864-11 SHORT CHIP 0
R5025 1-216-864-11 SHORT CHIP 0
R5026 1-216-809-11 METAL CHIP 100 5% 1/10W
R5027 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5028 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5029 1-216-841-11 METAL CHIP 47K 5% 1/10W
R5030 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5042 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R5043 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R5047 1-216-864-11 SHORT CHIP 0
R5048 1-216-864-11 SHORT CHIP 0
R5049 1-216-864-11 SHORT CHIP 0
R5050 1-216-821-11 METAL CHIP 1K 5% 1/10W
R5051 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R5052 1-216-841-11 METAL CHIP 47K 5% 1/10W
R5053 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R5054 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5055 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5056 1-216-821-11 METAL CHIP 1K 5% 1/10W
R5060 1-216-864-11 SHORT CHIP 0
R5061 1-216-864-11 SHORT CHIP 0
R5068 1-216-845-11 METAL CHIP 100K 5% 1/10W
R5069 1-216-845-11 METAL CHIP 100K 5% 1/10W
R5072 1-216-809-11 METAL CHIP 100 5% 1/10W
R5073 1-216-864-11 SHORT CHIP 0
R5074 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
*************************************************************
HDMI_BRIDGE BOARD (AEP, UK)
*******************
< CONNECTOR >
CNS199 1-784-774-11 CONNECTOR, FFC 13P
*************************************************************
HEADPHONE BOARD
*****************
< CONNECTOR >
* CNP790 1-564-507-11 PLUG, CONNECTOR 4P
< JACK >
J790 1-815-314-21 JACK (PHONES)
*************************************************************
A-1221-171-A MAIN BOARD, COMPLETE (US, CND)
A-1221-172-A MAIN BOARD, COMPLETE (AEP, UK)
*********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C402 1-126-964-11 ELECT 10uF 20% 50V
C403 1-162-294-31 CERAMIC 0.001uF 10% 50V
C404 1-162-294-31 CERAMIC 0.001uF 10% 50V
C421 1-126-963-11 ELECT 4.7uF 20% 50V
C422 1-126-963-11 ELECT 4.7uF 20% 50V
C423 1-126-963-11 ELECT 4.7uF 20% 50V
C424 1-126-963-11 ELECT 4.7uF 20% 50V
C425 1-126-963-11 ELECT 4.7uF 20% 50V
C426 1-126-963-11 ELECT 4.7uF 20% 50V
C431 1-126-964-11 ELECT 10uF 20% 50V
C432 1-126-964-11 ELECT 10uF 20% 50V
C433 1-126-964-11 ELECT 10uF 20% 50V
C434 1-126-964-11 ELECT 10uF 20% 50V
C435 1-126-964-11 ELECT 10uF 20% 50V
C436 1-126-964-11 ELECT 10uF 20% 50V
C446 1-126-963-11 ELECT 4.7uF 20% 50V
C452 1-126-964-11 ELECT 10uF 20% 50V
C471 1-104-658-91 ELECT 100uF 20% 10V
C472 1-127-888-11 CERAMIC 0.1uF 10% 50V
C482 1-127-888-11 CERAMIC 0.1uF 10% 50V
C484 1-127-888-11 CERAMIC 0.1uF 10% 50V
C500 1-128-579-11 ELECT 2.2uF 20% 100V
C501 1-126-963-11 ELECT 4.7uF 20% 50V
C502 1-128-809-11 CERAMIC 100PF 5% 50V
C503 1-128-809-11 CERAMIC 100PF 5% 50V
C504 1-101-810-00 CERAMIC 100PF 5% 500V
C506 1-107-583-11 CERAMIC 3PF 0.25PF 500V
C507 1-104-658-91 ELECT 100uF 20% 10V
C508 1-126-947-11 ELECT 47uF 20% 35V
C511 1-162-815-11 CERAMIC 47PF 5% 500V
C512 1-162-815-11 CERAMIC 47PF 5% 500V
C513 1-128-813-11 CERAMIC 220PF 5% 50V
C514 1-127-876-11 CERAMIC 0.01uF 10% 50V
C515 1-126-964-11 ELECT 10uF 20% 50V
C516 1-136-157-00 FILM 0.022uF 5% 50V
C529 1-127-876-11 CERAMIC 0.01uF 10% 50V
C549 1-127-876-11 CERAMIC 0.01uF 10% 50V
C551 1-126-963-11 ELECT 4.7uF 20% 50V
C552 1-128-809-11 CERAMIC 100PF 5% 50V
C553 1-128-809-11 CERAMIC 100PF 5% 50V
C554 1-101-810-00 CERAMIC 100PF 5% 500V
HEADPHONE
HDMI_BRIDGEHDMI SW
MAIN
