48
STR-K790
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
DISPLAY
< NETWORK RESISTOR >
RB1500 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB1501 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB1502 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB1503 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB1504 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB1506 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB1507 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB1508 1-233-576-11 RES, CHIP NETWORK 100 (3216)
< VIBRATOR >
X1101 1-813-448-21 PIEZOELECTRIC OSCILLATOR (24MHz)
X1301 1-795-126-21 VIBRATOR, CRYSTAL (12.288MHz)
X1502 1-813-276-21 QUARTZ CRYSTAL (13.9MHz)
*************************************************************
A-1221-225-A DISPLAY BOARD, COMPLETE (US, CND)
A-1221-226-A DISPLAY BOARD, COMPLETE (AEP, UK)
************************
< CAPACITOR >
C100 1-127-888-11 CERAMIC 0.1uF 10% 50V
C101 1-127-888-11 CERAMIC 0.1uF 10% 50V
C106 1-127-868-11 CERAMIC 2200PF 10% 50V
C107 1-127-868-11 CERAMIC 2200PF 10% 50V
C110 1-162-286-31 CERAMIC 220PF 10% 50V
C111 1-162-286-31 CERAMIC 220PF 10% 50V
C112 1-162-286-31 CERAMIC 220PF 10% 50V
C144 1-127-888-11 CERAMIC 0.1uF 10% 50V
C145 1-127-888-11 CERAMIC 0.1uF 10% 50V
C146 1-126-964-11 ELECT 10uF 20% 50V
C147 1-162-286-31 CERAMIC 220PF 10% 50V
C148 1-162-286-31 CERAMIC 220PF 10% 50V
C149 1-162-286-31 CERAMIC 220PF 10% 50V
C150 1-127-888-11 CERAMIC 0.1uF 10% 50V
C151 1-127-888-11 CERAMIC 0.1uF 10% 50V
C152 1-127-888-11 CERAMIC 0.1uF 10% 50V
C161 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
CNP102 1-564-505-11 PLUG, CONNECTOR 2P
CNS102 1-784-778-11 CONNECTOR, FFC 17P
< FLUORESCENT INDICATOR TUBE >
FL101 1-519-927-11 VACUUM FLOURESCENT DISPLAY
< IC >
IC100 8-759-643-83 IC uPD16315GB-3BS
IC101 8-759-243-51 IC TC74ACT08P
IC102 6-600-174-01 IC RPM7240-H4
< RESISTOR >
R103 1-249-409-11 CARBON 220 5% 1/4W
R115 1-247-807-31 CARBON 100 5% 1/4W
R116 1-247-807-31 CARBON 100 5% 1/4W
R117 1-247-807-31 CARBON 100 5% 1/4W
R118 1-249-440-11 CARBON 82K 5% 1/4W
R119 1-247-807-31 CARBON 100 5% 1/4W
0 R121 1-249-393-11 CARBON 10 5% 1/4W F
0 R198 1-249-385-11 CARBON 2.2 5% 1/4W F
0 R199 1-249-385-11 CARBON 2.2 5% 1/4W F
< VARIABLE RESISTOR >
RV101 1-418-817-21 ENCODER, ROTARY
RV102 1-418-725-41 ENCODER, ROTARY (12 TYPE)
< SWITCH >
S103 1-771-410-21 SWITCH, TACTILE (AUTO CAL)
S104 1-771-410-21 SWITCH, TACTILE (DISPLAY)
*************************************************************
A-1158-394-A HDMI SW BOARD, COMPLETE (AEP, UK)
************************
< CAPACITOR >
C5001 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5002 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5003 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5004 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5005 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5006 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5007 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5008 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5009 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5010 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5011 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5012 1-112-788-11 ELECT CHIP 330uF 20% 6.3V
C5013 1-128-934-91 CERAMIC CHIP 0.33uF 20% 10V
C5014 1-112-788-11 ELECT CHIP 330uF 20% 6.3V
C5015 1-128-994-21 ELECT CHIP 47uF 20% 10V
C5016 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5017 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C5018 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C5019 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5020 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5021 1-117-681-11 ELECT CHIP 100uF 20% 16V
C5022 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5023 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5024 1-128-934-91 CERAMIC CHIP 0.33uF 20% 10V
C5027 1-128-994-21 ELECT CHIP 47uF 20% 10V
< CONNECTOR >
CN5001 1-820-735-11 HDMI CONNECTOR (HDMI/DVD IN)
CN5002 1-820-735-11 HDMI CONNECTOR (HDMI/VIDEO 2/BD IN)
CN5003 1-820-735-11 HDMI CONNECTOR (HDMI/OUT)
* CN5004 1-770-470-21 PIN, CONNECTOR (PC BOARD) 6P
< IC >
IC5001 6-709-221-01 IC TMDS341PFCR
IC5002 6-705-337-01 IC TK11150CSCL-G
IC5003 6-705-468-01 IC BA33BC0FP-E2
IC5004 6-704-099-01 IC TC7WZ08FK (TE85R)
IC5005 6-707-207-01 IC SN74LVC1G3157DCKR
IC5006 6-706-740-01 IC BA00BC0WFP-E2
DIGITAL
HDMI SW
To Next Page
