54
STR-K790
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
A-1221-175-A STANDBY BOARD, COMPLETE (US, CND)
A-1221-176-A STANDBY BOARD, COMPLETE (AEP, UK)
************************
< CAPACITOR >
C901 1-135-798-11 CERAMIC 0.22uF 50V
C902 1-135-798-11 CERAMIC 0.22uF 50V
C911 1-135-798-11 CERAMIC 0.22uF 50V
C912 1-135-798-11 CERAMIC 0.22uF 50V
C913 1-126-959-11 ELECT 0.47uF 20% 50V
C914 1-126-936-11 ELECT 3300uF 20% 16V
C915 1-126-943-11 ELECT 2200uF 20% 25V
C916 1-126-942-61 ELECT 1000uF 20% 25V
< CONNECTOR >
* CNP801 1-564-510-11 PLUG, CONNECTOR 7P
CNP900 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
* CNP903 1-564-506-11 PLUG, CONNECTOR 3P
* CNP904 1-565-792-11 PIN, CONNECTOR (3.96mm PITCH) 2P
* CNP906 1-691-406-11 CONNECTOR, BOARD TO BOARD 7P
< DIODE >
D901 8-719-991-33 DIODE 1SS133T-77
D910 6-500-522-11 DIODE 10EDB40-TA2B5
D911 6-500-522-11 DIODE 10EDB40-TA2B5
D912 6-500-522-11 DIODE 10EDB40-TA2B5
D913 6-500-522-11 DIODE 10EDB40-TA2B5
D914 8-719-991-33 DIODE 1SS133T-77
D915 8-719-991-33 DIODE 1SS133T-77
0 D920 6-500-522-11 DIODE 10EDB40-TA2B5
0 D921 6-500-522-11 DIODE 10EDB40-TA2B5
0 D922 6-500-522-11 DIODE 10EDB40-TA2B5
0 D923 6-500-522-11 DIODE 10EDB40-TA2B5
< FUSE HOLDER >
FH902 1-533-217-41 HOLDER, FUSE
FH952 1-533-217-41 HOLDER, FUSE
< GROUND TERMINAL >
G901 1-537-738-21 TERMINAL, GROUND
< TRANSISTOR >
Q901 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q911 8-729-119-78 TRANSISTOR 2SC2785-HFE
< RESISTOR >
0 R810 1-243-634-91 FUSIBLE 0.22 5% 1/2W
0 R812 1-243-634-91 FUSIBLE 0.22 5% 1/2W
0 R900 1-219-237-91 SOLID 3.3M 20% 1/2W
(US, CND)
R903 1-247-871-91 CARBON 47K 5% 1/4W
R904 1-247-847-91 CARBON 4.7K 5% 1/4W
0 R905 1-249-381-11 CARBON 1 5% 1/4W F
R911 1-247-871-91 CARBON 47K 5% 1/4W
R912 1-249-435-11 CARBON 33K 5% 1/4W
R913 1-249-429-11 CARBON 10K 5% 1/4W
< RELAY >
0 RY901 1-755-439-11 RELAY
< POWER TRANSFORMER >
0 T902 1-443-517-11 POWER TRANSFORMER (AEP, UK)
0 T902 1-443-516-11 POWER TRANSFORMER (US, CND)
*************************************************************
MISCELLANEOUS
**************
9 1-829-994-11 WIRE (FLAT TYPE) (17 CORE)
0 59 1-777-071-83 CORD, POWER (AEP, UK)
0 59 1-783-820-11 CORD, POWER (US, CND)
61 1-828-953-11 WIRE (FLAT TYPE) (9 CORE) (US, CND)
61 1-828-963-11 WIRE (FLAT TYPE) (11 CORE) (AEP, UK)
62 1-828-971-11 WIRE (FLAT TYPE) (13 CORE) (AEP, UK)
65 1-693-728-11 TUNER (FM/AM) (CND)
65 1-693-733-11 TUNER (FM/AM) (US)
65 1-693-737-11 TUNER (FM/AM) (AEP, UK)
0 F901 1-532-464-33 FUSE (T2.5AL/250V) (AEP, UK)
0 F901 1-533-452-12 FUSE, GLASS TUBE (DIA. 5) (4A/125V)
(US, CND)
0 Q503 6-702-390-01 IC MN2488-OPY-MK
0 Q504 6-702-391-01 IC MP1620-OPY-MK
0 Q553 6-702-390-01 IC MN2488-OPY-MK
0 Q554 6-702-391-01 IC MP1620-OPY-MK
0 Q603 6-702-390-01 IC MN2488-OPY-MK
0 Q604 6-702-391-01 IC MP1620-OPY-MK
0 Q653 6-702-390-01 IC MN2488-OPY-MK
0 Q654 6-702-391-01 IC MP1620-OPY-MK
0 Q703 6-702-390-01 IC MN2488-OPY-MK
0 Q704 6-702-391-01 IC MP1620-OPY-MK
0 Q753 6-702-390-01 IC MN2488-OPY-MK
0 Q754 6-702-391-01 IC MP1620-OPY-MK
0 T901 1-443-909-11 POWER TRANSFORMER (US, CND)
0 T901 1-443-916-11 POWER TRANSFORMER (AEP, UK)
STANDBY
Ver. 1.1
