Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-KM2/KM3
69
C3568 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V (KM3)
C3569 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V (KM3)
C3570 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V (KM3)
C3571 1-116-737-11 CERAMIC CHIP 1uF 20% 10V (KM3)
C3572 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V (KM3)
C3573 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V (KM3)
C3574 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V (KM3)
C3575 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V (KM3)
C3576 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V (KM3)
C3585 1-116-737-11 CERAMIC CHIP 1uF 20% 10V (KM3)
C3588 1-116-737-11 CERAMIC CHIP 1uF 20% 10V (KM3)
C3592 1-116-717-11 CERAMIC CHIP 10uF 20% 10V (KM3)
C3593 1-116-737-11 CERAMIC CHIP 1uF 20% 10V (KM3)
C3651 1-116-717-11 CERAMIC CHIP 10uF 20% 10V (KM3)
C3662 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V (KM3)
C3663 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V (KM3)
C3664 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V (KM3)
C3665 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V (KM3)
C3666 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V (KM3)
C3667 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V (KM3)
C3668 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V (KM3)
C3676 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V (KM3)
C3689 1-116-737-11 CERAMIC CHIP 1uF 20% 10V (KM3)
C3690 1-116-737-11 CERAMIC CHIP 1uF 20% 10V (KM3)
C3696 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V (KM3)
C3697 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V (KM3)
C3700 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V (KM3)
C3702 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V (KM3)
C3708 1-116-713-11 CERAMIC CHIP 22uF 20% 10V (KM3)
C3709 1-116-713-11 CERAMIC CHIP 22uF 20% 10V (KM3)
C3710 1-116-717-11 CERAMIC CHIP 10uF 20% 10V (KM3)
C3711 1-116-717-11 CERAMIC CHIP 10uF 20% 10V (KM3)
C3712 1-116-717-11 CERAMIC CHIP 10uF 20% 10V (KM3)
C3713 1-116-717-11 CERAMIC CHIP 10uF 20% 10V (KM3)
C3714 1-116-717-11 CERAMIC CHIP 10uF 20% 10V (KM3)
C3715 1-116-717-11 CERAMIC CHIP 10uF 20% 10V (KM3)
C3718 1-116-717-11 CERAMIC CHIP 10uF 20% 10V (KM3)
C3719 1-116-717-11 CERAMIC CHIP 10uF 20% 10V (KM3)
C3720 1-116-717-11 CERAMIC CHIP 10uF 20% 10V (KM3)
C3722 1-116-717-11 CERAMIC CHIP 10uF 20% 10V (KM3)
C3726 1-116-737-11 CERAMIC CHIP 1uF 20% 10V (KM3)
C3727 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V (KM3)
C3729 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V (KM3)
C3730 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V (KM3)
C3731 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V (KM3)
C3735 1-116-717-11 CERAMIC CHIP 10uF 20% 10V (KM3)
C3736 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V (KM3)
C3737 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V (KM3)
C3738 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V (KM3)
C3739 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V (KM3)
C3740 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V (KM3)
C3741 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V (KM3)
C3742 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V (KM3)
C3743 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V (KM3)
C3744 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V (KM3)
C3745 1-116-737-11 CERAMIC CHIP 1uF 20% 10V (KM3)
C3746 1-116-737-11 CERAMIC CHIP 1uF 20% 10V (KM3)
C3747 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V (KM3)
* C3757 1-116-723-11 CERAMIC CHIP 4.7uF 10% 10V (KM3)
* C3758 1-116-723-11 CERAMIC CHIP 4.7uF 10% 10V (KM3)
* C3759 1-116-723-11 CERAMIC CHIP 4.7uF 10% 10V (KM3)
* C3760 1-116-723-11 CERAMIC CHIP 4.7uF 10% 10V (KM3)
C3761 1-116-717-11 CERAMIC CHIP 10uF 20% 10V (KM3)
C3762 1-116-737-11 CERAMIC CHIP 1uF 20% 10V (KM3)
C3763 1-116-737-11 CERAMIC CHIP 1uF 20% 10V (KM3)
C3764 1-116-737-11 CERAMIC CHIP 1uF 20% 10V (KM3)
C3765 1-116-737-11 CERAMIC CHIP 1uF 20% 10V (KM3)
C3766 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V (KM3)
C3767 1-116-717-11 CERAMIC CHIP 10uF 20% 10V (KM3)
C3768 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V (KM3)
C3770 1-116-737-11 CERAMIC CHIP 1uF 20% 10V (KM3)
C3771 1-116-737-11 CERAMIC CHIP 1uF 20% 10V (KM3)
C3773 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V (KM3)
< CONNECTOR >
CN3500 1-821-398-41 HDMI CONNECTOR (HDMI TV OUT ARC) (KM3)
CN3501 1-821-398-41 HDMI CONNECTOR (HDMI SAT/CATV IN) (KM3)
CN3502 1-821-398-41 HDMI CONNECTOR (HDMI GAME IN) (KM3)
CN3503 1-821-398-41 HDMI CONNECTOR (HDMI BD/DVD IN) (KM3)
CN3510 1-779-993-11 PIN, CONNECTOR (PWB) 5P (KM3)
CN3512 1-820-119-41 CONNECTOR, FFC/FPC 21P (KM3)
< DIODE >
D3515 8-719-053-18 DIODE 1SR154-400TE-25 (KM3)
D3529 6-503-782-01 DI USFB13L (KM3)
< EARTH TERMINAL >
* ET3500 1-780-408-11 TERMINAL, LUG (KM3)
* ET3503 1-780-408-11 TERMINAL, LUG (KM3)
< FERRITE BEAD >
FB3504 1-400-180-21 INDUCTOR, EMI FERRITE (1608) (KM3)
FB3505 1-400-180-21 INDUCTOR, EMI FERRITE (1608) (KM3)
FB3508 1-400-180-21 INDUCTOR, EMI FERRITE (1608) (KM3)
FB3509 1-414-760-21 FERRITE, EMI (SMD) (1608) (KM3)
FB3511 1-414-760-21 FERRITE, EMI (SMD) (1608) (KM3)
FB3512 1-414-760-21 FERRITE, EMI (SMD) (1608) (KM3)
FB3515 1-400-921-21 FERRITE, EMI (SMD) (KM3)
FB3516 1-400-921-21 FERRITE, EMI (SMD) (KM3)
FB3517 1-414-760-21 FERRITE, EMI (SMD) (1608) (KM3)
< IC >
IC3500 (Not supplied) IC SII9233ACTU-C (KM3)
IC3501
(Not supplied) IC SII9134CTU-C (KM3)
IC3507 6-707-853-01 IC TC74LCX541FT (EKJ) (KM3)
IC3509 6-711-116-01 IC NJM2878F3-05 (TE2) (KM3)
IC3527 6-709-888-01 IC TC7WHU04FK (KM3)
IC3530 6-717-680-01 IC BD00IC0WEFJ-E2 (KM3)
IC3531 6-717-680-01 IC BD00IC0WEFJ-E2 (KM3)
IC3532 6-716-573-01 IC S-1172B33-E6T1G (KM3)
IC3533 6-718-999-01 IC MM1839A50NRE (KM3)
< COIL >
L3503 1-481-524-1
1 INDUCTOR 10uH (KM3)
L3504 1-481-524-11 INDUCTOR 10uH (KM3)
L3505 1-481-524-11 INDUCTOR 10uH (KM3)
L3506 1-481-524-11 INDUCTOR 10uH (KM3)
L3507 1-481-521-11 INDUCTOR 1uH (KM3)
L3508 1-481-524-11 INDUCTOR 10uH (KM3)
L3509 1-481-524-11 INDUCTOR 10uH (KM3)
HDMI RE
Note: IC3500 and IC3501 on the HDMI RE board cannot ex-
change with single. When these parts on the HDMI RE
board are damaged, exchange the entire mounted board.
Ver. 1.3
