Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-KM22/KM55/KM77
7979
< FERRITE BEAD >
FB5000 1-400-862-11 BEAD, FERRITE
FB5085 1-400-862-11 BEAD, FERRITE
< FILTER >
FL5003 1-400-874-11 FILTER, EMI REMOVAL (SMD)
< IC >
IC5000 6-716-354-01 IC W9864G6JH-6-ER10
IC5001 (Not supplied) IC ADSST-AVR-305
IC5002 A-1989-261-A IC W25Q16DVSSIG (for SERVICE)
IC5003 6-716-471-01 IC SI-3010LLSL-TL
< RESISTOR >
R5001 1-216-811-11 METAL CHIP 150 5% 1/10W
R5002 1-216-801-11 METAL CHIP 22 5% 1/10W
R5003 1-216-811-11 METAL CHIP 150 5% 1/10W
R5004 1-216-811-11 METAL CHIP 150 5% 1/10W
R5005 1-216-811-11 METAL CHIP 150 5% 1/10W
R5006 1-216-811-11 METAL CHIP 150 5% 1/10W
R5007 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5008 1-216-811-11 METAL CHIP 150 5% 1/10W
R5009 1-216-811-11 METAL CHIP 150 5% 1/10W
R5010 1-216-811-11 METAL CHIP 150 5% 1/10W
R5011 1-216-811-11 METAL CHIP 150 5% 1/10W
R5012 1-218-943-11 METAL CHIP 150 5% 1/16W
R5013 1-218-943-11 METAL CHIP 150 5% 1/16W
R5014 1-216-807-11 METAL CHIP 68 5% 1/10W
R5015 1-216-811-11 METAL CHIP 150 5% 1/10W
R5016 1-216-811-11 METAL CHIP 150 5% 1/10W
R5017 1-216-811-11 METAL CHIP 150 5% 1/10W
R5018 1-218-943-11 METAL CHIP 150 5% 1/16W
R5019 1-218-943-11 METAL CHIP 150 5% 1/16W
R5020 1-218-943-11 METAL CHIP 150 5% 1/16W
R5021 1-218-943-11 METAL CHIP 150 5% 1/16W
R5022 1-218-943-11 METAL CHIP 150 5% 1/16W
R5023 1-216-811-11 METAL CHIP 150 5% 1/10W
R5024 1-216-801-11 METAL CHIP 22 5% 1/10W
R5025 1-216-801-11 METAL CHIP 22 5% 1/10W
R5026 1-216-801-11 METAL CHIP 22 5% 1/10W
R5029 1-216-801-11 METAL CHIP 22 5% 1/10W
R5031 1-216-801-11 METAL CHIP 22 5% 1/10W
R5032 1-216-801-11 METAL CHIP 22 5% 1/10W
R5034 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5035 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5036 1-216-801-11 METAL CHIP 22 5% 1/10W
R5037 1-216-801-11 METAL CHIP 22 5% 1/10W
R5038 1-216-801-11 METAL CHIP 22 5% 1/10W
R5039 1-216-801-11 METAL CHIP 22 5% 1/10W
R5040 1-216-801-11 METAL CHIP 22 5% 1/10W
R5041 1-216-801-11 METAL CHIP 22 5% 1/10W
R5042 1-216-801-11 METAL CHIP 22 5% 1/10W
R5043 1-216-801-11 METAL CHIP 22 5% 1/10W
R5044 1-216-801-11 METAL CHIP 22 5% 1/10W
R5046 1-216-801-11 METAL CHIP 22 5% 1/10W
R5047 1-216-801-11 METAL CHIP 22 5% 1/10W
R5048 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5049 1-216-801-11 METAL CHIP 22 5% 1/10W
R5050 1-216-801-11 METAL CHIP 22 5% 1/10W
R5051 1-216-801-11 METAL CHIP 22 5% 1/10W
R5052 1-216-801-11 METAL CHIP 22 5% 1/10W
R5053 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5054 1-216-864-11 SHORT CHIP 0
R5056 1-216-857-11 METAL CHIP 1M 5% 1/10W
R5061 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5063 1-216-801-11 METAL CHIP 22 5% 1/10W
R5064 1-216-801-11 METAL CHIP 22 5% 1/10W
R5065 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5066 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5067 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5068 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R5072 1-216-801-11 METAL CHIP 22 5% 1/10W
R5073 1-216-801-11 METAL CHIP 22 5% 1/10W
R5074 1-216-801-11 METAL CHIP 22 5% 1/10W
R5075 1-216-845-11 METAL CHIP 100K 5% 1/10W
R5076 1-216-821-11 METAL CHIP 1K 5% 1/10W
R5077 1-216-813-11 METAL CHIP 220 5% 1/10W
R5078 1-216-801-11 METAL CHIP 22 5% 1/10W
R5079 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5080 1-216-801-11 METAL CHIP 22 5% 1/10W
R5081 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R5082 1-216-801-11 METAL CHIP 22 5% 1/10W
R5085 1-216-864-11 SHORT CHIP 0
R5086 1-218-871-11 METAL CHIP 10K 0.50% 1/10W
R5087 1-218-871-11 METAL CHIP 10K 0.50% 1/10W
R5088 1-218-847-11 METAL CHIP 1K 0.50% 1/10W
R5089 1-218-831-11 METAL CHIP 220 0.50% 1/10W
R5092 1-216-864-11 SHORT CHIP 0
R5095 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5097 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5098 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5099 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5100 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5101 1-216-811-11 METAL CHIP 150 5% 1/10W
R5102 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5104 1-216-864-11 SHORT CHIP 0
R5105 1-216-864-11 SHORT CHIP 0
< COMPOSITION CIRCUIT BLOCK >
RB5000 1-200-051-21 RES, NETWORK 150 (1005X4)
RB5001 1-200-051-21 RES, NETWORK 150 (1005X4)
RB5002 1-200-051-21 RES, NETWORK 150 (1005X4)
RB5003 1-200-051-21 RES, NETWORK 150 (1005X4)
< VIBRATOR >
X5000 1-814-242-11 VIBRATOR, CRYSTAL (25MHz)
*************************************************************
9 A-1989-260-A HDMI RE PC BOARD, COMPLETE (for SERVICE)
**************************
< CAPACITOR >
* C3008 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C3014 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C3015 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C3021 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
* C3027 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C3028 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
* C3029 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
* C3030 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
DSP
Note: IC5001 on the DSP board cannot exchange with single.
When these parts on the DSP board are damaged, exchange
the entire mounted board.
Ver. 1.2
HDMI RE PC
