Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-KM22/KM55/KM77
80
* C3033 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
* C3037 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
* C3040 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
* C3048 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C3049 1-118-040-11 CERAMIC CHIP 2.2uF 10% 16V
C3054 1-100-354-21 ELECT CHIP 220uF 20% 6.3V
C3055 1-100-354-21 ELECT CHIP 220uF 20% 6.3V
* C3056 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C3057 1-118-040-11 CERAMIC CHIP 2.2uF 10% 16V
C3058 1-118-040-11 CERAMIC CHIP 2.2uF 10% 16V
* C3059 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C3060 1-118-040-11 CERAMIC CHIP 2.2uF 10% 16V
* C3061 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C3063 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
C3064 1-116-737-11 CERAMIC CHIP 1uF 20% 10V
* C3066 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C3067 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C3068 1-118-040-11 CERAMIC CHIP 2.2uF 10% 16V
C3069 1-118-040-11 CERAMIC CHIP 2.2uF 10% 16V
* C3073 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C3074 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C3075 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C3076 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C3077 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C3080 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C3081 1-116-724-11 CERAMIC CHIP 4.7uF 20% 6.3V
C3084 1-116-729-11 CERAMIC CHIP 2.2uF 20% 10V
C3085 1-116-729-11 CERAMIC CHIP 2.2uF 20% 10V
C3086 1-164-852-11 CERAMIC CHIP 12PF 5% 50V
C3087 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
* C3098 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
* C3099 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
* C3102 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C3106 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
* C3108 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
* C3109 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C3111 1-116-729-11 CERAMIC CHIP 2.2uF 20% 10V
* C3112 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
< CONNECTOR >
CN3000 1-821-398-41 HDMI CONNECTOR (HDMI IN 1 (4K))
CN3001 1-821-398-41 HDMI CONNECTOR (HDMI IN 2 (4K))
CN3002 1-821-398-41 HDMI CONNECTOR (HDMI IN 3 (4K))
CN3005 1-779-993-11 PIN, CONNECTOR (PWB) 5P
CN3006 1-821-398-41 HDMI CONNECTOR (HDMI TV OUT ARC)
CN3009 1-820-117-51 CONNECTOR, FFC/FPC 19P
< DIODE >
D3001 6-503-738-01 DI CES521
D3003 6-503-670-01 DI GSIG
D3004 6-503-670-01 DI GSIG
< EARTH TERMINAL >
* ET3000 1-780-991-11 LUG TERMINAL
* ET3001 1-780-991-11 LUG TERMINAL
< FERRITE BEAD >
FB3002 1-414-864-11 FERRITE, EMI (SMD) (1608)
FB3003 1-481-348-21 EMI FERRITE (SMD) (1608)
FB3004 1-400-921-21 FERRITE, EMI (SMD)
FB3005 1-481-348-21 EMI FERRITE (SMD) (1608)
< IC >
IC3002 6-719-139-01 IC MM3411A50NRE
IC3005 6-717-680-01 IC BD00IC0WEFJ-E2
IC3006 6-717-680-01 IC BD00IC0WEFJ-E2
IC3007 6-718-999-01 IC MM1839A50NRE
IC3009 (Not supplied) IC SII9535CTUC
< COIL >
L3000 1-469-525-91 INDUCTOR 10uH
L3006 1-412-977-41 INDUCTOR 0.68uH
< RESISTOR >
R3000 1-218-990-81 SHORT CHIP 0
R3001 1-218-990-81 SHORT CHIP 0
R3002 1-218-990-81 SHORT CHIP 0
R3003 1-218-933-11 METAL CHIP 22 5% 1/16W
R3004 1-218-933-11 METAL CHIP 22 5% 1/16W
R3005 1-218-933-11 METAL CHIP 22 5% 1/16W
R3006 1-218-933-11 METAL CHIP 22 5% 1/16W
R3007 1-218-933-11 METAL CHIP 22 5% 1/16W
R3008 1-218-933-11 METAL CHIP 22 5% 1/16W
R3009 1-218-973-11 METAL CHIP 47K 5% 1/16W
R3010 1-218-973-11 METAL CHIP 47K 5% 1/16W
R3011 1-216-864-11 SHORT CHIP 0
R3023 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R3034 1-218-969-11 METAL CHIP 22K 5% 1/16W
R3036 1-218-953-11 METAL CHIP 1K 5% 1/16W
R3037 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3055 1-216-864-11 SHORT CHIP 0
R3062 1-216-864-11 SHORT CHIP 0
R3076 1-216-864-11 SHORT CHIP 0
R3082 1-216-864-11 SHORT CHIP 0
R3087 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3088 1-218-941-81 METAL CHIP 100 5% 1/16W
* R3089 1-250-523-11 METAL CHIP 15K 1% 1/16W
R3090 1-250-535-11 METAL CHIP 47K 1% 1/16W
R3091 1-218-941-81 METAL CHIP 100 5% 1/16W
R3092 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3093 1-218-941-81 METAL CHIP 100 5% 1/16W
R3094 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3095 1-218-990-81 SHORT CHIP 0
R3098 1-218-990-81 SHORT CHIP 0
R3099 1-220-168-81 METAL CHIP 62 5% 1/16W
R3100 1-218-973-11 METAL CHIP 47K 5% 1/16W
R3101 1-218-973-11 METAL CHIP 47K 5% 1/16W
R3102 1-218-953-11 METAL CHIP 1K 5% 1/16W
R3103 1-218-933-11 METAL CHIP 22 5% 1/16W
R3104 1-218-933-11 METAL CHIP 22 5% 1/16W
R3105 1-218-956-11 METAL CHIP 1.8K 5% 1/16W
R3106 1-218-956-11 METAL CHIP 1.8K 5% 1/16W
R3112 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R3113 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R3114 1-218-937-11 METAL CHIP 47 5% 1/16W
R3115 1-218-959-11 METAL CHIP 3.3K 5% 1/16W
R3116 1-218-941-81 METAL CHIP 100 5% 1/16W
R3128 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R3129 1-216-797-11 METAL CHIP 10 5% 1/10W
HDMI RE PC
Note: IC3009 on the HDMI RE PC board cannot exchange with
single. When these parts on the HDMI RE PC board are
damaged, exchange the entire mounted board.
Ver. 1.2
