Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-KM22/KM55/KM77
8383
D115 6-504-050-01 DI (LED 1L0353W61B3MKT02)
< ROTARY ENCODER >
EN100 1-418-725-41 ENCODER, ROTARY (12 TYPE)
(INPUT SELECTOR)
< JUMPER RESISTOR >
JR130 1-216-864-11 SHORT CHIP 0
< RESISTOR >
R126 1-216-833-11 METAL CHIP 10K 5% 1/10W
R127 1-216-837-11 METAL CHIP 22K 5% 1/10W
R128 1-216-810-11 METAL CHIP 120 5% 1/10W
R129 1-216-810-11 METAL CHIP 120 5% 1/10W
R130 1-216-811-11 METAL CHIP 150 5% 1/10W
R131 1-216-811-11 METAL CHIP 150 5% 1/10W
R132 1-216-811-11 METAL CHIP 150 5% 1/10W
R133 1-216-811-11 METAL CHIP 150 5% 1/10W
< SWITCH >
S100 1-762-875-21 SWITCH, TACTILE (:/1)
*************************************************************
A-1983-292-A FRONT USB BOARD, COMPLETE
(EXCEPT SAF, AR)
**************************
< CAPACITOR >
C180 1-118-036-11 CERAMIC CHIP 0.1uF 10% 50V
(EXCEPT SAF, AR)
C181 1-126-176-11 ELECT CHIP 220uF 20% 10V
(EXCEPT SAF, AR)
< CONNECTOR >
CN105 1-819-866-11 USB CONNECTOR (A) (
) (EXCEPT SAF, AR)
CN106 1-564-721-11 PIN, CONNECTOR (SMALL TYPE) 5P
(EXCEPT SAF, AR)
< DIODE >
D180 6-500-400-01 DIODE BAV99-215 (EXCEPT SAF, AR)
D181 6-500-400-01 DIODE BAV99-215 (EXCEPT SAF, AR)
< JUMPER RESISTOR >
JR001 1-216-296-11 SHORT CHIP 0 (EXCEPT SAF, AR)
JR002 1-216-296-11 SHORT CHIP 0 (EXCEPT SAF, AR)
*************************************************************
NFC CHAIN BOARD
***************
< CONNECTOR >
CN4000 1-820-112-51 CONNECTOR, FFC/FPC 9P
CN4001 1-820-384-31 CONNECTOR, FFC/FPC (LIF) 8P
*************************************************************
A-1987-672-A STANDBY BOARD, COMPLETE
(KM55: SAF, AR, TH, E12/KM77: SAF, SP, AR, AUS)
A-1987-690-A STANDBY BOARD, COMPLETE
(KM55: E51, EA/KM77: E51)
A-1992-605-A STANDBY BOARD, COMPLETE
(KM22: SAF, SP, AR, TH)
A-1992-606-A STANDBY BOARD, COMPLETE
(KM22: E51, EA)
****************************
7-685-646-71 SCREW +BVTP 3X8 TYPE2 IT-3 (KM55/KM77)
< CAPACITOR >
C901 1-126-947-11 ELECT 47uF 20% 10V
(KM55/KM77)
* C904 1-118-360-11 CERAMIC CHIP 0.1uF 10% 25V
(KM55/KM77)
C905 1-104-665-11 ELECT 100uF 20% 25V
(KM55/KM77)
C907 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C908 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
C909 1-118-289-11 CERAMIC CHIP 0.1uF 10% 16V
* C1500 1-118-360-11 CERAMIC CHIP 0.1uF 10% 25V
C1501 1-100-703-91 CERAMIC CHIP 10uF 10% 25V
C1502 1-100-703-91 CERAMIC CHIP 10uF 10% 25V
C1503 1-100-703-91 CERAMIC CHIP 10uF 10% 25V
C1504 1-118-459-11 CERAMIC CHIP 0.01uF 10% 25V
* C1505 1-118-360-11 CERAMIC CHIP 0.1uF 10% 25V
C1506 1-126-768-11 ELECT 2200uF 20% 16V
C1507 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
C1508 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
* C1509 1-118-360-11 CERAMIC CHIP 0.1uF 10% 25V
* C1600 1-118-360-11 CERAMIC CHIP 0.1uF 10% 25V
C1601 1-100-703-91 CERAMIC CHIP 10uF 10% 25V
C1602 1-100-703-91 CERAMIC CHIP 10uF 10% 25V
C1603 1-100-703-91 CERAMIC CHIP 10uF 10% 25V
C1604 1-118-459-11 CERAMIC CHIP 0.01uF 10% 25V
* C1605 1-118-360-11 CERAMIC CHIP 0.1uF 10% 25V
C1606 1-126-768-11 ELECT 2200uF 20% 16V
C1607 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C1608 1-162-925-11 CERAMIC CHIP 68PF 5% 50V
* C1609 1-118-360-11 CERAMIC CHIP 0.1uF 10% 25V
* C1613 1-118-360-11 CERAMIC CHIP 0.1uF 10% 25V
C1614 1-100-703-91 CERAMIC CHIP 10uF 10% 25V
C1615 1-100-703-91 CERAMIC CHIP 10uF 10% 25V
C1616 1-100-703-91 CERAMIC CHIP 10uF 10% 25V
C1617 1-118-459-11 CERAMIC CHIP 0.01uF 10% 25V
* C1618 1-118-360-11 CERAMIC CHIP 0.1uF 10% 25V
C1619 1-126-768-11 ELECT 2200uF 20% 16V
C1620 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C1621 1-162-925-11 CERAMIC CHIP 68PF 5% 50V
* C1622 1-118-360-11 CERAMIC CHIP 0.1uF 10% 25V
* C1624 1-118-360-11 CERAMIC CHIP 0.1uF 10% 25V
(KM55/KM77)
C1625 1-126-947-11 ELECT 47uF 20% 25V
(KM55/KM77)
* C1626 1-118-360-11 CERAMIC CHIP 0.1uF 10% 25V
(KM55/KM77)
C1627 1-126-936-11 ELECT 3300uF 20% 16V
C1628 1-126-960-11 ELECT 1uF 20% 50V
C1629 1-100-756-91 CERAMIC CHIP 0.047uF 10% 50V
C1630 1-100-756-91 CERAMIC CHIP 0.047uF 10% 50V
C1631 1-126-951-11 ELECT 470uF 20% 35V
FRONT USBPOWER KEY NFC CHAIN STANDBY
Ver. 1.1
