Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-KM22/KM55/KM77
84
* C1633 1-118-360-11 CERAMIC CHIP 0.1uF 10% 25V
C1634 1-104-665-11 ELECT 100uF 20% 25V
C1635 1-126-946-11 ELECT 6800uF 20% 25V
< CONNECTOR >
CN903 1-564-506-11 PLUG, CONNECTOR 3P (KM55/KM77)
CN904 1-770-469-21 PIN, CONNECTOR (PC BOARD) 2P (KM55/KM77)
* CN911 1-564-507-11 PLUG, CONNECTOR 4P
CN912 1-784-928-11 PIN, CONNECTOR 13P
* CNP901 1-793-660-11 PIN, CONNECTOR (PC BOARD) 3P
* CNP902 1-580-689-11 PIN, CONNECTOR (PC BOARD) 4P
* CNP903 1-564-687-11 PIN, CONNECTOR (3.96mm PITCH) 3P (E51, EA)
< DIODE >
D900 6-502-961-01 DI DA2J10100L (KM55/KM77)
D901 6-502-961-01 DI DA2J10100L
D902 6-503-670-01 DI GSIG
D903 6-503-670-01 DI GSIG
D904 6-503-670-01 DI GSIG
D905 6-503-670-01 DI GSIG
D960 6-500-514-01 DIODE BAV70
D1002 6-503-401-01 DI D3SBA60-7101
D1500 6-501-361-01 DIODE RB051LA-40TR
D1600 6-501-361-01 DIODE RB051LA-40TR
D1601 6-501-361-01 DIODE RB051LA-40TR
D1603 8-719-053-18 DIODE 1SR154-400TE-25 (KM55/KM77)
< EARTH TERMINAL >
* ET001 1-780-408-11 TERMINAL, LUG
< FUSE >
0 F921 1-523-086-11 FUSE (3.15A/250V)
0 F922 1-523-086-11 FUSE (3.15A/250V)
< FUSE HOLDER >
FH901 1-533-217-41 HOLDER, FUSE
FH902 1-533-217-41 HOLDER, FUSE
FH903 1-533-217-41 HOLDER, FUSE (E51, EA)
FH904 1-533-217-41 HOLDER, FUSE (E51, EA)
< IC >
IC900 6-713-034-01 IC KIA7812API-U/PF (KM55/KM77)
IC1500 6-716-575-01 IC TPS54331GDR
IC1600 6-716-575-01 IC TPS54331GDR
IC1601 6-716-575-01 IC TPS54331GDR
IC1602 6-717-138-01 IC KIA7805AF-RTF/PW (KM55/KM77)
IC1603 6-713-034-01 IC KIA7812API-U/PF
< JUMPER RESISTOR >
JS901 1-211-950-11 SHORT CHIP 0 (EXCEPT E51, EA)
JS903 1-211-950-11 SHORT CHIP 0 (E51, EA)
JS905 1-211-950-11 SHORT CHIP 0 (E51, EA)
< COIL >
L1500 1-424-918-21 INDUCTOR 10uH
L1501 1-424-918-21 INDUCTOR 10uH
L1600 1-424-918-21 INDUCTOR 10uH
L1601 1-424-918-21 INDUCTOR 10uH
L1602 1-424-918-21 INDUCTOR 10uH
L1603 1-424-918-21 INDUCTOR 10uH
< TRANSISTOR >
Q900 6-552-677-01 TR RT1N234M-T111-1
(KM55/KM77)
Q901 6-553-266-01 TR 2PD601ART (KM55/KM77)
Q902 8-729-037-13 TRANSISTOR KTA1271Y-AT (KM55/KM77)
Q903 6-553-266-01 TR 2PD601ART
Q904 6-553-266-01 TR 2PD601ART
< RESISTOR >
R907 1-250-568-11 METAL CHIP 10 1% 1/10W
(KM55/KM77)
R908 1-250-568-11 METAL CHIP 10 1% 1/10W
(KM55/KM77)
* R909 1-250-572-11 METAL CHIP 15 1% 1/10W
(KM55/KM77)
R911 1-216-833-11 METAL CHIP 10K 5% 1/10W
(KM55/KM77)
R912 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
(KM55/KM77)
R913 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
(KM55/KM77)
R914 1-216-821-11 METAL CHIP 1K 5% 1/10W
(KM55/KM77)
R916 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R917 1-216-841-11 METAL CHIP 47K 5% 1/10W
R918 1-218-867-11 METAL CHIP 6.8K 5% 1/10W
R919 1-216-835-11 METAL CHIP 15K 5% 1/10W
R1500 1-218-983-11 METAL CHIP 330K 5% 1/16W
R1501 1-218-977-11 METAL CHIP 100K 5% 1/16W
R1502 1-218-979-11 METAL CHIP 150K 5% 1/16W
R1503 1-208-671-11 METAL CHIP 330 0.50% 1/16W
R1504 1-208-911-11 METAL CHIP 10K 0.50% 1/16W
R1505 1-208-687-11 METAL CHIP 1.5K 0.50% 1/16W
R1506 1-218-990-81 SHORT CHIP 0
R1600 1-218-983-11 METAL CHIP 330K 5% 1/16W
R1601 1-218-977-11 METAL CHIP 100K 5% 1/16W
R1602 1-218-975-11 METAL CHIP 68K 5% 1/16W
R1603 1-218-990-81 SHORT CHIP 0
R1604 1-208-911-11 METAL CHIP 10K 0.50% 1/16W
R1605 1-208-683-11 METAL CHIP 1K 0.50% 1/16W
R1613 1-218-983-11 METAL CHIP 330K 5% 1/16W
R1614 1-218-977-11 METAL CHIP 100K 5% 1/16W
R1615 1-218-975-11 METAL CHIP 68K 5% 1/16W
R1616 1-218-990-81 SHORT CHIP 0
R1617 1-208-911-11 METAL CHIP 10K 0.50% 1/16W
R1618 1-208-683-11 METAL CHIP 1K 0.50% 1/16W
R1620 1-208-687-11 METAL CHIP 1.5K 0.50% 1/16W
R1621 1-208-895-81 METAL CHIP 2.2K 0.50% 1/16W
R1622 1-216-833-11 METAL CHIP 10K 5% 1/10W
< RELAY >
0 RY901 1-755-541-11 RELAY
< SWITCH >
0 S901 1-571-437-21 SWITCH, POWER VOLTAGE CHANGE
(VOLTAGE SELECTOR) (E51, EA)
STANDBY
Ver. 1.2
