Sony STR-KM77 - Page 85

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-KM22/KM55/KM77
8585
< TRANSFORMER >
0 T903 1-697-234-21 POWER TRANSFORMER (SUB)
(EXCEPT E51, EA)
0 T904 1-697-351-11 POWER TRANSFORMER (SUB) (E51, EA)
*************************************************************
SUB RECTIFIER BOARD (KM55, KM77)
*******************
7-685-646-71 SCREW +BVTP 3X8 TYPE2 IT-3 (KM55, KM77)
< CAPACITOR >
C941 1-118-118-91 CERAMIC CHIP 0.22uF 10% 100V
(KM55, KM77)
C942 1-118-118-91 CERAMIC CHIP 0.22uF 10% 100V
(KM55, KM77)
C943 1-116-372-11 ELECT (BLOCK) 4700uF 20% 80V
(KM55, KM77)
C944 1-116-372-11 ELECT (BLOCK) 4700uF 20% 80V
(KM55, KM77)
< CONNECTOR >
* CN931 1-564-509-11 PLUG, CONNECTOR 6P (KM55, KM77)
CN932 1-785-104-11 PIN, CONNECTOR (3.96mm PITCH) 6P
(KM55, KM77)
CNP931 1-785-103-11 PIN, CONNECTOR (3.96mm PITCH) 5P
(KM55, KM77)
< DIODE >
D931 6-502-961-01 DI DA2J10100L (KM55, KM77)
D932 8-719-061-07 DIODE D5SBA60-F (KM55, KM77)
< FUSE >
0 F931 1-523-080-11 FUSE (6.3A/250V) (KM55, KM77)
0 F932 1-523-080-11 FUSE (6.3A/250V) (KM55, KM77)
< TRANSISTOR >
Q931 6-553-266-01 TR 2PD601ART (KM55, KM77)
< RESISTOR >
R941 1-216-841-11 METAL CHIP 47K 5% 1/10W
(KM55, KM77)
R942 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(KM55, KM77)
R944 1-218-446-11 METAL CHIP 1 5% 1/10W
(KM55, KM77)
< RELAY >
0 RY931 1-755-593-11 RELAY (KM55, KM77)
*************************************************************
SURR BACK AMP BOARD (KM77)
********************
< CAPACITOR >
C401 1-118-695-91 CERAMIC CHIP 0.01uF 5% 50V
(KM77)
C402 1-163-037-11 CERAMIC CHIP 0.022uF 10% 50V
(KM77)
C404 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
(KM77)
C405 1-114-128-91 CERAMIC CHIP 47PF 5% 100V
(KM77)
C408 1-114-128-91 CERAMIC CHIP 47PF 5% 100V
(KM77)
C409 1-126-947-11 ELECT 47uF 20% 25V
(KM77)
C411 1-114-128-91 CERAMIC CHIP 47PF 5% 100V
(KM77)
C412 1-114-339-91 CERAMIC CHIP 3300PF 5% 50V
(KM77)
C413 1-114-128-91 CERAMIC CHIP 47PF 5% 100V
(KM77)
C414 1-116-138-11 CERAMIC CHIP 4PF 0.25PF 100V
(KM77)
C417 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(KM77)
C418 1-126-923-91 ELECT 220uF 20% 10V
(KM77)
C419 1-126-964-11 ELECT 10uF 20% 50V
(KM77)
C421 1-116-138-11 CERAMIC CHIP 4PF 0.25PF 100V
(KM77)
C451 1-118-695-91 CERAMIC CHIP 0.01uF 5% 50V
(KM77)
C452 1-163-037-11 CERAMIC CHIP 0.022uF 10% 50V
(KM77)
C454 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
(KM77)
C455 1-114-128-91 CERAMIC CHIP 47PF 5% 100V
(KM77)
C458 1-114-128-91 CERAMIC CHIP 47PF 5% 100V
(KM77)
C459 1-126-947-11 ELECT 47uF 20% 25V
(KM77)
C461 1-114-128-91 CERAMIC CHIP 47PF 5% 100V
(KM77)
C462 1-114-339-91 CERAMIC CHIP 3300PF 5% 50V
(KM77)
C463 1-114-128-91 CERAMIC CHIP 47PF 5% 100V
(KM77)
C464 1-116-138-11 CERAMIC CHIP 4PF 0.25PF 100V
(KM77)
C467 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(KM77)
C468 1-126-964-11 ELECT 10uF 20% 50V
(KM77)
C469 1-126-923-91 ELECT 220uF 20% 10V
(KM77)
C471 1-116-138-11 CERAMIC CHIP 4PF 0.25PF 100V
(KM77)
< CONNECTOR >
CN405 1-785-102-11 PIN, CONNECTOR (3.96mm PITCH) 4P (KM77)
CN406 1-691-773-11 PLUG (MICRO CONNECTOR) 11P (KM77)
< DIODE >
D401 6-502-961-01 DI DA2J10100L (KM77)
D402 6-502-961-01 DI DA2J10100L (KM77)
D403 6-502-961-01 DI DA2J10100L (KM77)
D404 6-502-961-01 DI DA2J10100L (KM77)
D405 6-502-961-01 DI DA2J10100L (KM77)
D451 6-502-961-01 DI DA2J10100L (KM77)
D452 6-502-961-01 DI DA2J10100L (KM77)
D453
6-502-961-01 DI DA2J10100L (KM77)
D454 6-502-961-01 DI DA2J10100L (KM77)
D455 6-502-961-01 DI DA2J10100L (KM77)
SUB RECTIFIER
SURR BACK AMP
STANDBY
