STR-KS2000
55
Pin No. Pin Name I/O Description
60 X0A I Low-speed clock signal input terminal Not used
61 X1A O Low-speed clock signal output terminal Not used
62 RST TRI O Reset signal output to the reset signal buffer
63 DIR DATA0 I Serial data input from the digital audio interface receiver
64
DSP SPDIF (LAT)
O Serial data latch pulse signal output to the DSP
65 DSP RESET O System reset signal output to the DSP
66 SF CPU CE O Chip enable signal output for the serial fl ash
67 SF DSP MAS I Master/slave selection signal input from the DSP "H": DSP is master
68 FL LAT O Strobe signal output to the fl uorescent indicator tube
69 TUNER CLK O PLL serial data transfer clock signal output to the tuner (FM/AM)
70, 71 NO USE - Not used
72 TUNER DATA O PLL serial data output to the tuner (FM/AM)
73 ADC RESET O System reset signal output to the A/D converter "L": reset
74 FL DATA O Serial data output to the fl uorescent indicator tube
75 FL CLK O Serial data transfer clock signal output to the fl uorescent indicator tube
76 VSS - Ground terminal
77 VCC - Power supply terminal (+3.3V)
78 EEPROM CLK O Serial data transfer clock signal output to the EEPROM
79 PCONT_3 O Power on/off control signal output terminal "H": power on
80 PCONT_2 O Power on/off control signal output terminal "H": power on
81 STOP I AC off detection signal input terminal "L": AC off
82 SIRCS IN I SIRCS signal input from the remote control receiver
83 DSP INT I Interrupt status input from the DSP
84 RDS CLK I
RDS serial data transfer clock signal input from the tuner (FM/AM)
(AEP and UK models only)
85 POWER KEY I Power key input terminal
86 RDS DATA I RDS serial data input from the tuner (FM/AM) (AEP and UK models only)
87 PCONT_1 O Power on/off control signal output terminal "H": power on
88 CEC IN I CEC serial data input from the HDMI OUT connector
89 DSP MISO I Serial data input from the DSP or serial fl ash
90 DSP MOSI O Serial data output to the DSP or serial fl ash
91 DSP SPI CLK O Serial data transfer clock signal output to the DSP
92
HDMI
(M-IN-HDMI-OUT)
I UART data input from the HDMI controller
93
HDMI
(M-OUT-HDMI-IN)
O UART data output to the HDMI controller
94 NO USE - Not used
95 VCC - Power supply terminal (+3.3V)
96 VSS(GND) - Ground terminal
97 SACD LED O LED rive signal output of the SA-CD/CD indicator "H": LED on Not used
98
EEPROM DATA
I/O Two-way data bus with the EEPROM
99
CLINK_TX
(M-IN-CLINK-OUT)
I Receive data input from the DMPORT connector
100
CLINK_RX
(M-OUT-CLINK-IN)
O Transmit data output to the DMPORT connector
101 CLINK_DET I Digital media port adapter connection detection signal input terminal
102 FLASH_SI I UART data input terminal
103 FLASH_SO O UART data output terminal
104 HDMI RESET O System reset signal output to the HDMI controller "L": reset
105 to 106 NO USE - Not used
107 DSVS - Ground terminal (for D/A converter)
108 DAVC - Power supply terminal (+3.3V) (for D/A converter) Not used
109 AVCC - Power supply terminal (+3.3V) (for A/D converter)
110 AVRH I Reference voltage input (+3.3V) terminal (for A/D converter)
111, 112
AVSS/AVRH, VSS
- Ground terminal
113 to 115 A/D 0 to A/D 2 I Front panel key input terminal (A/D input)
116 VERSION I Setting terminal for the destination
