STR-KS2000
58
Pin No. Pin Name I/O Description
78 IOGND - Ground terminal
79 MCLK O Audio master clock signal output for the DSP and HDMI transceiver
80 CGND - Ground terminal
81 CVCC18 - Power supply terminal (+1.8V)
82 AUDPVCC18 - Power supply terminal (+1.8V)
83 AUDPGND - Ground terminal
84 XTALOUT O System clock output termnal (28.322 MHz)
85 XTALIN I System clock input terminal (28.322 MHz)
86 ZTALVCC - Power supply terminal (+3.3V)
87 REGVCC - Power supply terminal (+3.3V)
88 RSVDL - Not used
89 RESET I Reset signal input from the HDMI controller "L": Reset
90 SCDT - Not used
91 INT O Interrupt signal output for the HDMI controller
92 to 96 QE23 to QE19 O Serial data output for the HDMI transceiver
97 IOGND - Ground terminal
98 IOVCC - Power supply terminal (+3.3V)
99 to 105 QE18 to QE12 O Serial data output for the HDMI transceiver
106 IOGND - Ground terminal
107 IOVCC - Power supply terminal (+3.3V)
108 to 111 QE11 to QE8 O Serial data output for the HDMI transceiver
112 CVCC18 - Power supply terminal (+1.8V)
113 CGND - Ground terminal
114 to 117 QE7 to QE4 O Serial data output for the HDMI transceiver
118 IOGND - Ground terminal
119 ODCK O Output data clock signal output for the HDMI transceiver
120 IOVCC - Power supply terminal (+3.3V)
121 to 124 QE3 to QE0 O Serial data output for the HDMI transceiver
125 CVCC18 - Power supply terminal (+1.8V)
126 CGND - Ground terminal
127 DE O Data enable signal output for the HDMI transceiver
128 HSYNC O Horizontal synchronize signal output for the HDMI transceiver
